Page 2033 of 4378

FORD MUSTANG 2003 Workshop Manual Klj . 2 ba 22003 Mustang Workshop Manual 18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

Page 2034 of 4378

FORD MUSTANG 2003 Workshop Manual SPECIFICATIONS SECTION 303- 06: Starting System 2003 Mustang Workshop Manual General Specifications Item Specification Normal engine cranking speed rpm 100- 140 rpm Starter motor no load curren

Page 2035 of 4378

FORD MUSTANG 2003 Workshop Manual DESCRIPTION AND OPERATION Starting System Starter Motor The starter motor is a 12- volt unit that has the starter solenoid mounted on the drive end housing and functions as follows: �zThe current

Page 2036 of 4378

FORD MUSTANG 2003 Workshop Manual Klj . 2 ba 22003 Mustang Workshop Manual 18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

Page 2037 of 4378

FORD MUSTANG 2003 Workshop Manual DIAGNOSIS AND TESTING Starting System Refer to Wiring Diagrams Cell 20 , Starting System for schematic and connector information. Inspection and Verification WARNING: When servicing starter mot

Page 2038 of 4378

FORD MUSTANG 2003 Workshop Manual Symptom Chart Pinpoint Tests PINPOINT TEST A: THE ENGINE DOES NOT CRANK AND THE RELAY DOES CLICK SYMPTOM CHART Condition Possible Sources Action �z The engine does not crank and the relay do

Page 2039 of 4378

FORD MUSTANG 2003 Workshop Manual �z Is the voltage greater than 12.5 volts? for an open. TEST the system for normal operation. A2 CHECK THE VOLTAGE TO THE STARTER MOTOR SOLENOID �z Measure the voltage between the starter motor s

Page 2040 of 4378

FORD MUSTANG 2003 Workshop Manual PINPOINT TEST B: THE ENGINE DOES NOT CRANK AND THE RELAY DOES NOT CLICK Test Step Result / Action to Take B1 CHECK CIRCUIT 33 (WH/PK) FOR VOLTAGE �z Disconnect: Starter Motor Relay. �z Key in ST
