Page 921 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Valve — Seat Inspection Valve and Seat Refacing Measurements CAUTION: After grinding valves or valve seats, check valve clearance. 1. Check the valve head and seat. �zCheck

Page 922 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Valve — Seat Width 1. Measure the valve seat width. If necessary, grind the valve seat to specification. �zMeasure the intake valve seat width. �z Measure the exhaust valve se

Page 923 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Valve — Seat Runout 1. Use the Valve Seat Runout Gauge to check valve seat runout. SECTION 303- 00: Engine System — General Information 2003 Mustang Workshop Manual Klj

Page 924 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Cylinder Head — Distortion 1. Use a straight edge and a feeler gauge to inspect the cylinder head for flatness. If the cylinder head is distorted, install a new cylinder head.

Page 925 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Cylinder Bore — Cleaning 1. CAUTION: If these procedures are not followed, rusting of the cylinder bores may occur. Clean the cylinder bores with soap or detergent and water.

Page 926 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Cylinder Block Core Plug Replacement 1. Use a slide hammer or tools suitable to remove the cylinder block core plug. 2. Inspect the cylinder block plug bore for any damage that w

Page 927 of 4378

FORD MUSTANG 2003 Workshop Manual Expansion- Type 1. CAUTION: Do not contact the crown when installing an expansion- type cylinder block core plug. This could expand the plug before seating and result in leakage. Use tool suitable

Page 928 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Spark Plug Hole Thread Repair 1. There is no authorized repair for spark plug hole threads. If the threads are damaged, install a new cylinder head. SECTION 303- 00: Engine Syst
