FORD MUSTANG 2003 Workshop Manual PINPOINT TEST S: THE SERVICE ENGINE SOON INDICATOR IS
NEVER/ALWAYS ON side and ground.
�z Key in ON position.
�z Does the ABS indicator illuminate? No
GO to
R3 .
R3 CHECK CIRCUIT 603 (DG) FOR

Page 3298 of 4378

FORD MUSTANG 2003 Workshop Manual PINPOINT TEST T: THE TURN/HAZARD INDICATOR IS
NEVER/ALWAYS ON CLUSTER SERVICE ENGINE SOON
INDICATOR ACTIVE COMMAND
�z
Connect the diagnostic tool.
�z Key in ON position.
�z Enter the following d

PINPOINT TEST T: THE TURN/HAZARD INDICATOR IS
NEVER/ALWAYS ON CLUSTER SERVICE ENGINE SOON
INDICATOR ACTIVE COMMAND
z
Connect the diagnostic tool.
z Key in ON position.
z Enter the following diagnostic mode
on the diagnostic tool: Instrument
Cluster Active Command.
z Trigger the instrument cluster active
command MIL.
z Did the SERVICE ENGINE SOON
indicator illuminate? Yes
REFER to the Powertrain Control/Emissions
Diagnosis (PC/ED) manual.
No
GO to
S2 .
S2 CHECK FOR CORRECT
INSTRUMENT CLUSTER OPERATION z
Disconnect all instrument cluster
connectors.
z Check for:
zcorrosion
z pushed- out pins
z Connect all instrument cluster
connectors and make sure they seat
correctly.
z Operate the system and verify the
concern is still present.
z Is the concern still present? Yes
INSTALL a new instrument cluster. REFER to
Instrument Cluster
in this section. TEST the
system for normal operation.
No
The system is operating correctly at this time.
Concern may have been caused by a loose or
corroded connector. CLEAR the DTCs. REPEAT
the self- test. Test Step Result / Action to
Take T1 CHECK THE TURN SIGNAL AND HAZARD LAMPS OPERATION
CAUTION: Use the correct probe adapter(s) when making
measurements. Failure to use the correct probe adapter(s) may
damage the connector.
z Key in ON position.
z Operate the left and right turn signals.
z Operate the hazard lamps.
z Do the turn signals and hazard lamps operate correctly? Yes
GO to
T2 .
No
REFER to Section 417 - 01 .
T2 CHECK THE CIRCUIT IN QUESTION —
CIRCUIT 2 (WH/LB) (RH)
OR CIRCUIT 3 (LG/WH) (LH) z
Key in OFF position.
z Disconnect: Instrument Cluster C220a (RH) or C220b (LH).
z Key in ON position.
z Measure the voltage between the instrument cluster C220a pin 3,
circuit 3 (LG/WH), harness side and ground, while the steering
column multifunction switch is placed in the left turn position (LH); or
between the instrument cluster C220b pin 3, circuit 2 (WH/LB),
harness side and ground, while the steering column multifunction
switch is placed in the right turn position (RH). Yes
GO to
T3 .
No
REPAIR the circuit
(s) in question.
TEST the system for
normal operation. Klj . 36 ba
412003 Mustang Workshop Manual
18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_5108/S3B~us~en~ ...

Page 3299 of 4378

FORD MUSTANG 2003 Workshop Manual PINPOINT TEST U: THE TRACTION CONTROL INDICATOR IS
NEVER/ALWAYS ON �z
Does the voltage alternate between 0 volts and 10 volts with
the turn signal on? T3 CHECK FOR CORRECT INSTRUMENT CLUSTER OPERA

Page 3300 of 4378

FORD MUSTANG 2003 Workshop Manual PINPOINT TEST V: THE INSTRUMENT CLUSTER IS INOPERATIVE GO to
U2 .
U2 DETERMINE IF INSTRUMENT
CLUSTER IS AT FAULT �z
Connect the diagnostic tool.
�z Key in ON position.
�z Enter the following d

Page 3301 of 4378

FORD MUSTANG 2003 Workshop Manual �z
Is the voltage greater than 10 volts? No
REPAIR the circuit. TEST
the system for normal
operation.
V3 CHECK RUN/START POWER SUPPLY TO THE
INSTRUMENT CLUSTER �z
Key in OFF position.
�z Disco

Page 3302 of 4378

FORD MUSTANG 2003 Workshop Manual PINPOINT TEST W: NO COMMUNICATION WITH THE GENERIC
ELECTRONIC MODULE (GEM) �z
Is the resistance less than 5 ohms? V6 CHECK FOR CORRECT INSTRUMENT CLUSTER
OPERATION �z
Disconnect all instrument cl

Page 3303 of 4378

FORD MUSTANG 2003 Workshop Manual OPEN
�z
Key in OFF position.
�z Measure the resistance between the GEM C201b pin 4,
circuit 397 (BK/WH), harness side and ground.
�z Is the resistance less than 5 ohms? Yes
GO to
W3 .
No
REP

Page 3304 of 4378

FORD MUSTANG 2003 Workshop Manual REMOVAL AND INSTALLATION
Instrument Cluster
Removal and Installation
All vehicles
1. CAUTION: Electronic modules are sensitive to electrical charges. If exposed to
these charges, damage may resu
