Page 1681 of 4378

FORD MUSTANG 2003 Workshop Manual 7. CAUTION: The bolts are different lengths and must be returned to their original location. NOTE: RH shown; LH similar. Remove the bolts and the timing chain guides. Installation 1. CAUTION:

Page 1682 of 4378

FORD MUSTANG 2003 Workshop Manual 3. If the copper links are not visible, mark one link on one end and one link on the other end, and use as timing marks. 4. Install the timing chain guides. 5. Rotate the LH camshaft sprocket until

Page 1683 of 4378

FORD MUSTANG 2003 Workshop Manual removed and the cylinder heads are installed is the crankshaft or the camshaft to be rotated. Severe piston and valve damage will occur. CAUTION: Rotate the crankshaft counterclockwise only. Do not

Page 1684 of 4378

FORD MUSTANG 2003 Workshop Manual 11. NOTE: LH shown; RH similar. Position the tensioner arms and tensioners, and install the bolts. 12. Remove the retaining clips from the timing chain tensioners. 13. Position the crankshaft sens

Page 1685 of 4378

FORD MUSTANG 2003 Workshop Manual Klj . 7 ba 72003 Mustang Workshop Manual 17. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_4464/S3B~us~en~ ...

Page 1686 of 4378

FORD MUSTANG 2003 Workshop Manual IN- VEHICLE REPAIR Valve — Springs, Retainer and Valve Stem Seal Removal 1. Remove the roller followers. For additional information, refer to Roller Followers in this section. 2. Remove the sp

Page 1687 of 4378

FORD MUSTANG 2003 Workshop Manual 5. Using the special tool, compress the intake valve spring. 6. NOTE: Valve stem seals should be visually inspected if new seals are not installed. Remove the valve spring retainer keys, the valve

Page 1688 of 4378

FORD MUSTANG 2003 Workshop Manual Remove the valve spring retainer keys, the valve spring retainer, the valve spring and the valve stem seal. Installation 1. Using the special tools, install the new intake valve stem seals. 2. Usi
