Page 3097 of 4378

FORD MUSTANG 2003 Workshop Manual 3. CAUTION: Use only the new O- ring seals. The use of any O-ring seals other than those specified in the Ford Master Parts Catalog may result in intermittent leakage during vehicle operation. Ins

Page 3098 of 4378

FORD MUSTANG 2003 Workshop Manual Klj . 6 ba 62003 Mustang Workshop Manual 18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_2308/S3B~us~en~ ...

Page 3099 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Heater Hose Coupling Disconnect CAUTION: Do not attempt to install a new bushing, spacer or O- rings in the heater hose coupling; damage to the heater hose coupling can result.

Page 3100 of 4378

FORD MUSTANG 2003 Workshop Manual 4. NOTE: A slight twisting motion while pulling on the heater water hose may be necessary to assist in the removal. Pull the heater hose away from the heater core tube. 5. Spread the retainer tabs

Page 3101 of 4378

FORD MUSTANG 2003 Workshop Manual 3. Push the heater hose coupling onto the tube. 4. Make sure the heater hose coupling is fully engaged by lightly pulling on the heater hose. Klj . 3 ba 32003 Mustang Workshop Manual 18. 11.

Page 3102 of 4378

FORD MUSTANG 2003 Workshop Manual GENERAL PROCEDURES Air Conditioning Line (Peanut) Fitting Disconnect 1. CAUTION: Support the female fitting with a wrench to prevent the tubes from twisting. Remove the nut from the peanut fitti

Page 3103 of 4378

FORD MUSTANG 2003 Workshop Manual Connect 1. Clean all dirt or foreign material from the fittings. 2. CAUTION: Use only the new O- ring seals. The use of any O-ring seals other than those specified in the Ford Master Parts Catalog

Page 3104 of 4378

FORD MUSTANG 2003 Workshop Manual Klj . 3 ba 32003 Mustang Workshop Manual 18. 11. 2011file:///C:/Ford/2000 - 2004/tsocache/SHEF_2308/S3B~us~en~ ...
