Page 3049 of 5883

EXL-48
< COMPONENT DIAGNOSIS >
PARKING LAMP CIRCUIT
2. Disconnect the front combination lamp connectors, rear combination lamp connectors or license plate
lamp connectors.
3. Check continuity between the front combination lamp harness
connector terminal and ground.
4. Check continuity between the license plate lamp harness con-
nector terminal and ground.
5. Check continuity between the rear combination lamp harness
connector terminal and ground.
Does continuity exist?
YES >> Inspect the parking lamp bulb.
NO >> Repair the harness.
WITHOUT DAYTIME LIGHT SYSTEM
WITHOUT DAYTIME LIGHT SYSTEM : DescriptionINFOID:0000000001527574
The IPDM E/R (Intelligent Power Distribution Module Engine Room) controls the tail lamp relay based on
inputs from the BCM via the CAN communication lines. When the tail lamp relay is energized, power flows
through fuse 37, located in the IPDM E/R. Power then flows to the front and rear combination lamps.
WITHOUT DAYTIME LIGHT SYSTEM : Component Function CheckINFOID:0000000001527575
1.CHECK PARKING LAMP OPERATION
CONSULT-III
1. Select "TAIL LAMP" of IPDM E/R active test item.
2. With test items operating, check that the parking lamp is turned ON.
Is the parking lamp turned ON?
YES >> Parking lamp circuit is normal.
NO >> Refer to EXL-49, "
WITHOUT DAYTIME LIGHT SYSTEM : Diagnosis Procedure".
Front combination lamp connector Terminal — Continuity
LH E53
7GroundYes
RH E54
WKIA5509E
License plate lamp connector Terminal — Continuity
LHA: B87 (hatchback)
B: B62 (sedan)
2GroundYes
RHA: B88 (hatchback)
B: B63 (sedan)
WKIA6035E
Connector Terminal — Continuity
LH B80
1Ground Yes
RH B59
PKIC1029E
ON : Parking lamp ON
OFF : Parking lamp OFF
Page 3050 of 5883

PARKING LAMP CIRCUIT
EXL-49
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
WITHOUT DAYTIME LIGHT SYSTEM : Diagnosis ProcedureINFOID:0000000001527577
1.CHECK PARKING LAMP FUSE
1. Turn the ignition switch OFF.
2. Check that the following fuse is not open.
Is the fuse open?
YES >> Repair the harness and replace the fuse.
NO >> GO TO 2
2.CHECK TAIL LIGHT RELAY OUTPUT (VOLTAGE)
CONSULT-III
1. Turn the ignition switch OFF.
2. Disconnect the front or rear combination lamp connectors.
3. Turn the ignition switch ON.
4. Select "TAIL LAMP" of IPDM E/R active test item.
5. With TAIL LAMP ON, check the voltage between the front and rear combination lamps connectors and
license plate lamp connector and ground.
Is battery voltage present?
YES >> GO TO 4
NO >> GO TO 3
3.CHECK PARKING LAMP CIRCUIT (OPEN)
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R connector.
Unit Location Fuse No. Capacity
Parking lamps IPDM E/R 37 10A
(+)
(−)Voltage
Front combination lamp
connectorTe r m i n a l
LH E53
6 Ground Battery voltage
RH E54
WKIA5502E
(+)
(−)Voltage
License plate lamp connector Terminal
LHA: B87 (hatchback)
B: B62 (sedan)
1 Ground Battery voltage
RHA: B88 (hatchback)
B: B63 (sedan)
(+)
(−)Voltage
Front combination lamp
connectorTe r m i n a l
LH B80
4 Ground Battery voltage
RH B59
P K I C 111 8 E
Page 3051 of 5883

EXL-50
< COMPONENT DIAGNOSIS >
PARKING LAMP CIRCUIT
3. Check continuity between the IPDM E/R harness connector (A) and the front combination lamp harness
connector (B).
4. Check continuity between the IPDM E/R harness connector (A) and the license plate lamp harness con-
nector (B)(hatchback) or (C)(sedan).
5. Check continuity between the IPDM E/R harness connector (A) and the rear combination lamp harness
connector (B).
Does continuity exist?
YES >> GO TO 4
NO >> Repair the daytime light relay, harness or connectors.
4.CHECK PARKING LAMP GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect the front combination lamp connectors, rear combination lamp connectors or license plate
lamp connectors.
3. Check continuity between the front combination lamp harness
connector terminal and ground.
4. Check continuity between the license plate lamp harness con-
nector terminal and ground.
AB
Continuity
Connector Terminal Connector Terminal
E45 27LH E53
6Yes
RH B54
Connector Terminal Connector Terminal Continuity
A: E45 29LHB: B87 (hatchback)
C: B62 (sedan)
1Yes
RHB: B88 (hatchback)
C: B63 (sedan)
AB
Continuity
Connector Terminal Connector Terminal
E45 29LH B80
4Yes
RH B59
Front combination lamp connector Terminal — Continuity
LH E53
7GroundYes
RH E54
WKIA5509E
License plate lamp connector Terminal — Continuity
LHA: B87 (hatchback)
B: B62 (sedan)
2GroundYes
RHA: B88 (hatchback)
B: B63 (sedan)
WKIA6035E
Page 3052 of 5883
PARKING LAMP CIRCUIT
EXL-51
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
5. Check continuity between the rear combination lamp harness
connector terminal and ground.
Does continuity exist?
YES >> Inspect the parking lamp bulb.
NO >> Repair the harness.
Connector Terminal — Continuity
LH B80
1 Ground Yes
RH B59
PKIC1029E
Page 3053 of 5883

EXL-52
< COMPONENT DIAGNOSIS >
TURN SIGNAL LAMP CIRCUIT
TURN SIGNAL LAMP CIRCUIT
DescriptionINFOID:0000000001523271
The BCM monitors inputs from the combination switch to determine when to activate the turn signals. The
BCM outputs voltage directly to the left and right turn signals during turn signal operation or both during hazard
warning operation. The BCM sends a turn signal indicator request to the combination meter via the CAN com-
munication lines.
The BCM performs the fast flasher operation (fail-safe) if any bulb or harness of the turn signal lamp circuit is
open.
NOTE:
Turn signal lamps blink at normal speed when using the hazard warning lamp.
Component Function CheckINFOID:0000000001523272
1.CHECK TURN SIGNAL LAMP
CONSULT-III
1. Select "FLASHER" of BCM (FLASHER) active test item.
2. With test items operating, check that the turn signal lamp blinks.
Does the turn signal lamp blink?
YES >> Turn signal lamp circuit is normal.
NO >> Refer to EXL-52, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001523273
1.CHECK TURN SIGNAL LAMP BULB
Check the applicable lamp bulb to be sure the proper bulb standard is in use and the bulb is not open.
Is the bulb OK?
YES >> GO TO 2
NO >> Replace the bulb.
2.CHECK TURN SIGNAL LAMP OUTPUT VOLTAGE
1. Turn the ignition switch OFF.
2. Disconnect the front combination lamp connector, the rear combination lamp connector and the side turn
signals.
3. Turn the ignition switch ON.
4. With the turn signal switch operating, check voltage between the BCM harness connector M20 and
ground.
Is the measurement value normal?
YES >> GO TO 3
NO >> Replace BCM.LH : Turn signal lamp LH blinking
RH : Turn signal lamp RH blinking
OFF : The turn signal lamp OFF
(+)
(−) Voltage
Connector Terminal
M20 LH 65
Ground
RH 66
PKID0926E
Page 3054 of 5883

TURN SIGNAL LAMP CIRCUIT
EXL-53
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
3.CHECK TURN SIGNAL LAMP CIRCUIT FOR OPEN
1. Turn the ignition switch OFF.
2. Disconnect BCM connector.
3. Check the continuity between the BCM harness connector M20 and the front combination lamps.
4. Check the continuity between the BCM harness connector M20 and the side turn signals.
5. Check the continuity between the BCM harness connector M20 and the rear combination lamps.
Does continuity exist?
YES >> GO TO 4
NO >> Repair the harnesses or connectors.
4.CHECK TURN SIGNAL LAMP SHORT CIRCUIT
Check continuity between the BCM harness connector M20 and ground.
Does continuity exist?
YES >> Repair the harnesses or connectors.
NO >> GO TO 5
5.CHECK TURN SIGNAL LAMP GROUND CIRCUIT
Check continuity between the front combination lamp, the rear combination lamp or the side turn signal and
ground.
AB
Continuity
Connector Terminal Connector Terminal
Front LH
M2065E29 (hallogen headlamps) 4
Ye s E25 (xenon headlamps) 5
Front RH 66E30 (hallogen headlamps) 4
E26 (xenon headlamps) 5
AB
Continuity
Connector Terminal Connector Terminal
Side LH
M2065 E56
1Yes
Side RH 66 E57
AB
Continuity
Connector Terminal Connector Terminal
Rear LH
M2065 B80
6Yes
Rear RH 66 B59
Connector Terminal — Continuity
LH
M2065
Ground No
RH 66
Connector Terminal — Continuity
Page 3055 of 5883
EXL-54
< COMPONENT DIAGNOSIS >
TURN SIGNAL LAMP CIRCUIT
Does continuity exist?
YES >> Replace the front combination lamp, side turn signal lamp or the rear combination lamp.
NO >> Repair the harnesses or connectors.
Front LHE29 (halogen headlamps) 5
Ground Yes E25 (xenon headlamps) 2
Rear LH B80 1
Side LH E56 2
Front RHE30 (halogen headlamps) 5
E26 (xenon headlamps) 2
Rear RH B59 1
Side RH E57 2
Page 3056 of 5883

LIGHT & RAIN SENSOR
EXL-55
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
LIGHT & RAIN SENSOR
DescriptionINFOID:0000000001523274
The light and rain sensor converts outside light (lux) to voltage and transmits the light and rain sensor signal to
the BCM.
Component Function CheckINFOID:0000000001523275
1.CHECK LIGHT AND RAIN SENSOR SIGNAL BY CONSULT-III
CONSULT-III
1. Turn the ignition switch ON.
2. Select "LIT-SEN FAIL" of BCM (HEAD LAMP) DATA MONITOR item.
3. Check the monitor status.
Is the item status OK?
YES >> Light and rain sensor is OK.
NO >> Refer to EXL-55, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001523276
1.CHECK LIGHT AND RAIN SENSOR POWER SUPPLY
1. Turn the ignition switch ON.
2. Check the voltage between the light and rain sensor harness connector and ground.
Is the voltage as specified?
YES >> GO TO 2
NO >> GO TO 4
2.CHECK LIGHT AND RAIN SENSOR GROUND CIRCUIT
Check the voltage between the light and rain sensor harness connector R11 terminal 3 and ground.
Is the voltage as specified?
YES >> GO TO 3
NO >> Repair the harness or connector.
3.CHECK LIGHT AND RAIN SENSOR SIGNAL FOR OPEN OR SHORT CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect the light and rain sensor connector R11 and BCM connector M19.
3. Check continuity between the light and rain sensor harness connector R11 (A) terminal 2 and the BCM
harness connector M19 (B) terminal 63.
Monitor item Condition
L I T- S E N FA I LOK
NOT OK
(+)
(−) Voltage
Connector Terminal
R11 1 Ground 12V
(+)
(−) Voltage
Connector Terminal
R11 3 Ground Less than 0.2 V
