Page 4697 of 5883
SEC-72
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
INTELLIGENT KEY UNIT
B2552: INTELLIGENT KEY Intelligent Key unit internal malfunction.×Replace Intelligent Key
unit.
B2590: NATS MALFUNCTIONThe ID verification result between Intelligent key
unit and BCM are NG. Or Intelligent Key unit cannot
communicate with BCM.×Check NATS
Refer to SEC-35
CONSULT display Detection condition Fail-safe Diagnosis
Page 4698 of 5883
![NISSAN TIIDA 2007 Service Repair Manual IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
SEC-73
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGI NISSAN TIIDA 2007 Service Repair Manual IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
SEC-73
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGI](/manual-img/5/57395/w960_57395-4697.png)
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
SEC-73
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)
Reference ValueINFOID:0000000001404135
Refer to IPDM E/R.
Fail SafeINFOID:0000000001404139
CAN communication control
When CAN communication with ECM and BCM is impossible, IPDM E/R performs fail-safe control. After CAN
communication recovers normally, it also returns to normal control.
If no CAN communication is available with ECM
*1: HR engine models
*2: MR engine and K9K engine models
If no CAN communication is available with BCM
Ignition relay malfunction detection function
IPDM E/R monitors the voltage at the contact circuit and excitation coil circuit of the ignition relay inside it.
IPDM E/R judges the ignition relay error if the voltage differs between the contact circuit and the excitation
coil circuit.
If the ignition relay cannot turn OFF due to contact seizure, it activates the tail lamp relay for 10 minutes to
alert the user to the ignition relay malfunction when the ignition switch is turned OFF.
Control part Fail-safe in operation
Cooling fan The cooling fan relay-2*
1 or the cooling fan relay-3*2 turns ON when the ignition switch
is turned ON
Turns off the fan motor low relay when the ignition switch is turned OFF
A/C compressor A/C relay OFF
Control part Fail-safe in operation
Headlamp The headlamp low relay turns ON when the ignition switch is turned ON
The headlamp low relay turns OFF when the ignition switch is turned OFF
Headlamp high relay OFF
Parking lamps
License plate lamps
Tail lamps
Illuminations The tail lamp relay turns ON when the ignition switch is turned ON
The tail lamp relay turns OFF when the ignition switch is turned OFF
Front wiper The status just before activation of fail-safe control is maintained until the ignition
switch is turned OFF while the front wiper is operating at LO or HI speed.
The front wiper is operated at LO speed until the ignition switch is turned OFF if the
fail-safe control is activated while the front wiper is set in the INT mode and the front
wiper motor is operating.
Front fog lamps Front fog lamp relay OFF
Starter motor Inhibit relay OFF
Rear window defogger Rear window defogger relay OFF
Headlamp washer Headlamp washer relay OFF
PTC heater PTC heater relay OFF
DTC Ignition switch Ignition relay Tail lamp relay
—ONON—
—OFFOFF—
B2098: IGN RLY ON OFF ON ON (10 minutes)
B2099: IGN RLY OFF ON OFF —
Page 4699 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SEC-74
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
NOTE:
The tail lamp relay is turned OFF when the ignition switch is turned ON.
Front NISSAN TIIDA 2007 Service Repair Manual SEC-74
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
NOTE:
The tail lamp relay is turned OFF when the ignition switch is turned ON.
Front](/manual-img/5/57395/w960_57395-4698.png)
SEC-74
< ECU DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
NOTE:
The tail lamp relay is turned OFF when the ignition switch is turned ON.
Front wiper control
IPDM E/R detects the front wiper stop position with the front wiper auto stop signal.
When the front wiper auto stop signal is in the conditions listed below, IPDM E/R repeats a front wiper 10 sec-
onds operation and 20 seconds stop five times.
NOTE:
This operation status can be confirmed on the IPDM E/R “Data Monitor” that displays “BLOCK” for the item
“WIP PROT” while the wiper is stopped.
DTC IndexINFOID:0000000001404140
NOTE:
The details of time display are as follows.
CRNT: The malfunctions that are detected now.
PAST: The number is indicated when it is normal at present and a malfunction was detected in the past.Ignition switch Front wiper switch Front wiper auto stop signal
ONOFFThe front wiper auto stop signal (stop posi-
tion) cannot be input for 10 seconds.
ONThe front wiper auto stop signal does not
change for 10 seconds.
CONSULT display Fail-safe
TimingNOTEReference page
No DTC is detected.
further testing
may be required.————
U1000: CAN COMM CIRCUIT×CRNT PASTXX-XX, "*****"
B2098: IGN RELAY ON×CRNT PASTXX-XX, "*****"
B2099: IGN RELAY OFF — CRNT PASTXX-XX, "*****"
B2100: EEPROM — CRNT PASTXX-XX, "*****"
Page 4700 of 5883
![NISSAN TIIDA 2007 Service Repair Manual INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION SYMPTOMS
SEC-75
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
SYMPTOM DIAGNOSIS
INTELLIGENT KEY SYSTEM/ENGINE START F NISSAN TIIDA 2007 Service Repair Manual INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION SYMPTOMS
SEC-75
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
SYMPTOM DIAGNOSIS
INTELLIGENT KEY SYSTEM/ENGINE START F](/manual-img/5/57395/w960_57395-4699.png)
INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION SYMPTOMS
SEC-75
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
SYMPTOM DIAGNOSIS
INTELLIGENT KEY SYSTEM/ENGINE START FUNCTION SYMPTOMS
Symptom TableINFOID:0000000001404141
NOTE:
Before performing the diagnosis in the following table, check “XX-XX, "*****"
”.
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
Engine start function is ON when setting on CONSULT-III.
Mechanical key is not inserted in key cylinder.
One or more of Intelligent Keys with registered Intelligent Key ID is in the vehicle.
Symptom Diagnosis/service procedureReference
page
Ignition switch does not turn on with Intelligent Key.
[KEY warning lamp (green) illuminates.]1. Check steering lock unit.SEC-23
2. Replace Intelligent Key unit.XX-XX, "*****"
Ignition switch does not turn on with Intelligent Key.
[KEY warning lamp does not illuminate.]1.Check Intelligent Key unit power supply and ground cir-
cuit.XX-XX,
"*****"
2. Check ignition knob switch.XX-XX, "*****"
3. Check key switch.XX-XX, "*****"
4. Replace Intelligent Key unit.XX-XX, "*****"
Ignition switch does not turn on with Intelligent Key.
[KEY warning lamp (red) illuminates.]1. Check inside key antenna.XX-XX, "*****"
2. Replace Intelligent Key unit.XX-XX, "*****"
Ignition switch does not turn on with mechanical key Check key switch.XX-XX, "*****"
Engine cannot start1. Check key switch.XX-XX,
"*****"
2. Check stop lamp switch (A/T).XX-XX, "*****"
3. Check stop lamp switch (M/T).XX-XX, "*****"
Page 4701 of 5883
SEC-76
< SYMPTOM DIAGNOSIS >[WITH INTELLIGENT KEY SYSTEM]
NATS (NISSAN ANTI-THEFT SYSTEM) SYMPTOMS
NATS (NISSAN ANTI-THEFT SYSTEM) SYMPTOMS
Symptom TableINFOID:0000000001404143
NOTE:
Before performing the diagnosis in the following table, check “SEC-4, "
Work Flow"”.
Check that vehicle is under the condition shown in “Conditions of vehicle” before starting diagnosis, and
check each symptom.
If the following symptoms are detected, check systems shown in the “Diagnosis/service procedure” column
in this order.
CONDITIONS OF VEHICLE (OPERATING CONDITIONS)
Mechanical key is not inserted into key cylinder.
Ignition knob switch is not depressed.
Symptom Diagnosis/service procedure Reference page
Engine cannot start.1. Check stop lamp switchXX-XX, "*****"
2. Check Intermittent IncidentXX-XX, "*****"
Security indicator does not turn ON or flash.1. Check vehicle security indicatorSEC-492. Check Intermittent IncidentXX-XX, "*****"
Page 4702 of 5883
![NISSAN TIIDA 2007 Service Repair Manual PRE-INSPECTION FOR DIAGNOSTIC
SEC-77
< ON-VEHICLE MAINTENANCE >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ON-VEHICLE MAINTENANCE
PRE-INSPECTION FOR DIAGNOSTIC
Basic InspectionINFOI NISSAN TIIDA 2007 Service Repair Manual PRE-INSPECTION FOR DIAGNOSTIC
SEC-77
< ON-VEHICLE MAINTENANCE >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ON-VEHICLE MAINTENANCE
PRE-INSPECTION FOR DIAGNOSTIC
Basic InspectionINFOI](/manual-img/5/57395/w960_57395-4701.png)
PRE-INSPECTION FOR DIAGNOSTIC
SEC-77
< ON-VEHICLE MAINTENANCE >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ON-VEHICLE MAINTENANCE
PRE-INSPECTION FOR DIAGNOSTIC
Basic InspectionINFOID:0000000001404144
The engine start function, door lock function, and NATS in the Intelligent Key system are closely related to
each other regarding control. Narrow down the functional area in question by performing basic inspection to
identify which function is malfunctioning. The vehicle security function can operate only when the door lock is
operating normally. Therefore, it is easy to identify any factor unique to the vehicle security system by perform-
ing the vehicle security operation check after basic inspection.
1.CHECK DOOR LOCK OPERATION
Check the door lock for normal operation with the Intelligent Key and door request switch.
Successful door lock operation with the Intelligent Key and request switch indicates that the remote keyless
entry receiver and inside key antenna required for engine start are functioning normally.
Identify the malfunctioning point by referring to the DLK section if the door cannot be unlocked.
Can the door be locked with the Intelligent Key and door request switch?
YES >> GO TO 2.
NO >> Refer to XX-XX, "*****"
.
2.CHECK IGNITION KNOB SWITCH OPERATION-1
With all registered Intelligent Keys, check if ignition knob can rotate when carrying Intelligent Key inside the
vehicle.
Does ignition knob rotate?
YES >> GO TO 3.
NO >> Refer to SEC-76, "
Symptom Table".
3.CHECK IGNITION KNOB SWITCH OPERATION-2
Insert registered mechanical key into key cylinder, and check if ignition knob can rotate. Check for all regis-
tered mechanical keys.
Does ignition knob rotate?
YES >> GO TO 4.
NO (Does not rotate with some of mechanical keys)>>Perform mechanical key registration.
NO (Does not rotate with all mechanical keys)>>Refer to SEC-76, "
Symptom Table".
4.CHECK VEHICLE SECURITY SYSTEM
Check the vehicle security system for normal operation.
The vehicle security function can operate only when the door lock function is operating normally.
Therefore, it is easy to identify any factor unique to the vehicle security by performing the vehicle security
operation check after this basic inspection.
>> Go to SEC-77, "
Vehicle Security Operation Check".
Vehicle Security Operation CheckINFOID:0000000001404145
1.INSPECTION START
Turn ignition switch “OFF” and pull out mechanical key from key cylinder.
NOTE:
Before starting operation check, open front windows.
>> GO TO 2.
2.CHECK SECURITY INDICATOR LAMP
1. Lock doors using Intelligent Key.
2. Check that security indicator lamp illuminates for 30 seconds.
Security indicator lamp should illuminate.
OK >> GO TO 3.
Page 4703 of 5883
SEC-78
< ON-VEHICLE MAINTENANCE >[WITH INTELLIGENT KEY SYSTEM]
PRE-INSPECTION FOR DIAGNOSTIC
NG >> Perform diagnosis and repair. Refer to XX-XX, "*****".
3.CHECK ALARM FUNCTION
1. After 30 seconds, security indicator lamp will start to blink.
2. Open any door or hood before unlocking with Intelligent Key or open back door without Intelligent Key.
Does alarm function properly.
OK >> GO TO 4.
NG >> Check the following.
The vehicle security system does not phase in alarm mode. Refer to XX-XX, "*****"
.
Alarm does not operate. Refer to XX-XX, "*****"
.
4.CHECK ALARM CANCEL OPERATION
Unlock any door or open back door using Intelligent Key.
Alarm (horn and headlamp) should stop.
OK >> INSPECTION END.
NG >> Check door lock function. Refer to XX-XX, "*****"
.
Page 4704 of 5883
INTELLIGENT KEY UNIT
SEC-79
< ON-VEHICLE REPAIR >[WITH INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
ON-VEHICLE REPAIR
INTELLIGENT KEY UNIT
Removal and InstallationINFOID:0000000001350478
INTELLIGENT KEY UNIT RH DRIVE
Removal
1. Remove the lower driver instrument cover. Refer to IP-10, "Component Parts".
2. Remove the screw (A), disconnect the electrical connector (1),
and remove the intelligent key unit and bracket(2).
Installation
Installation is in the reverse order of removal.
INTELLIGENT KEY UNIT LH DRIVE
Removal
1. Remove the glove box assembly. Refer to IP-10, "Component Parts".
2. Remove the screw (A), disconnect the electrical connector (1),
and remove the intelligent key unit and bracket(2).
Installation
Installation is in the reverse order of removal.
ALKIA0682GB
ALKIA0683GB
