EC-620
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
HO2S2 HEATER
HO2S2 HEATER
DescriptionINFOID:0000000001697503
SYSTEM DESCRIPTION
The ECM performs ON/OFF control of the heated oxygen sensor 2 heater corresponding to the engine speed,
amount of intake air and engine coolant temperature.
OPERATION
Component Function CheckINFOID:0000000001697504
1.CHECK HEATED OXYGEN SENSOR 2 HRATER FUNCTION
1. Start engine and warm it up to the normal operating temperature.
2. Turn ignition switch OFF and wait at least 10 seconds.
3. Start engine and let it idle.
4. Check the voltage between ECM harness connector and ground under the following condition.
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-620, "
Diagnosis Procedure"
Diagnosis ProcedureINFOID:0000000001697505
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E21. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
Sensor Input signal to ECM ECM function Actuator
Camshaft position sensor (PHASE)
Crankshaft position sensor (POS)Engine speed
Heated oxygen sensor 2
heater controlHeated oxygen sensor 2 heater
Engine coolant temperature sensor Engine coolant temperature
Mass air flow sensor Amount of intake air
Engine speed rpm Heated oxygen sensor 2 heater
Above 3,900OFF
Below 3,900 rpm after the following conditions are met.
Engine: After warming up
Keeping the engine speed between 3,500 and 4,000 rpm for 1
minute and at idle for 1 minute under no loadON
ECM
Ground Condition Voltage signal
Connector Terminal
F75
(HO2S2 heater signal)GroundAt idleApprox. 10V
Engine speed: Above 3,900 rpmBATTERY VOLTAGE
(11 - 14V)
JMBIA0325GB
