Page 849 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-260
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
BACK DOOR OPENER FUNCTION
BACK DOOR OPENER FUNCTION
BACK DOOR OPENER SWITCH
BACK DOOR OPENER SWITCH : System DiagramINFOID:0000000001396698
BACK

Page 850 of 5883

NISSAN TIIDA 2007 Service Repair Manual BACK DOOR OPENER FUNCTION
DLK-261
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
BACK DOOR OPENER SWITCH : Component DescriptionINFOID:0000000001396701
Item Function

Page 851 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-262
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
TRUNK LID OPENER
TRUNK LID OPENER
TRUNK LID OPENER SWITCH
TRUNK LID OPENER SWITCH : System DiagramINFOID:0000000001500106
TRUNK LID OPENER OPERA

Page 852 of 5883

NISSAN TIIDA 2007 Service Repair Manual TRUNK LID OPENER
DLK-263
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
TRUNK LID OPENER SWITCH : Component DescriptionINFOID:0000000001500109
Item Function
BCM Contr

Page 853 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-264
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
WARNING FUNCTION
WARNING FUNCTION
System DiagramINFOID:0000000001396702
INTELLIGENT KEY WARNING OPERATION
BACK DOOR OPEN WARNING OPERATION
Syste

Page 854 of 5883

NISSAN TIIDA 2007 Service Repair Manual WARNING FUNCTION
DLK-265
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Warning/Information functions Operation conditions Warning lampWarning chime
Combination
mete

WARNING FUNCTION
DLK-265
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Warning/Information functions Operation conditions Warning lampWarning chime
Combination
meter buzzerIntelligent Key
warning buzz-
er(s)
Ignition knob return forgotten
warningWhen all the conditions below are met.
Ignition knob: OFF or LOCK (knob is
pressed).
Door switch (driver side): ON (Door is
open).—Active
for 5 seconds
(pipipipi,
pipipipi···)—
Ignition key warning
(when mechanical key is used)When all the conditions below are met.
Ignition switch: OFF position.
Key switch: ON (inserted)
Door switch (driver side): ON (Door is
open).—Active
for 5 seconds
(pipipipi,
pipipipi···)—
OFF position warningWhen all the conditions below are met.
Ignition switch is between ACC and
OFF position or ignition knob is
pressed in while ignition switch is in
LOCK position.
3 seconds in the above state have
passed. “LOCK”
(RED blinking)Active
for 1 second
(pipi, pipi···)—
Ta k e a w a y
warningAny door
open to all
doors closedWhen all the conditions below are met.
Ignition switch: Except LOCK position.
Door switch: ON to OFF (Door is open
to closed).
Intelligent Key cannot be detected in-
side the vehicle.“KEY”
(RED blinking)—Active
(pi, pi, pi)
Door is openWhen all the conditions below are met.
Door switch: ON (Door is open)
Key ID verification every 5 seconds
when registered Intelligent Key can
not be detected inside the vehicle.“KEY”
(RED blinking)——
Ta k e a w a y
through win-
dowWhen all the conditions below are met.
Key ID verification: OK
Every 30 seconds when registered In-
telligent Key cannot be detected in-
side the vehicle or result of vehicle
speed verification is NG. (The regis-
tered Intelligent Key cannot be detect-
ed inside the vehicle when ignition
switch is ON.)
Key switch: OFF (Key is removed
from ignition key cylinder.)“KEY”
(RED blinking)Active for 3 sec-
onds
(pipipi···—

Page 855 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-266
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
WARNING FUNCTION
KEY WARNING LAMP & LOCK WARNING LAMP
The key indicator and lock indicator indicates Intelligent Key system status.
Operation Co

DLK-266
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
WARNING FUNCTION
KEY WARNING LAMP & LOCK WARNING LAMP
The key indicator and lock indicator indicates Intelligent Key system status.
Operation Condition
BACK DOOR OPEN WARNING OPERATION
When back door opener switch is operated, when door lock is locked with door lock and unlock switch, speed
sensing lock or only driver side is unlocked with anti-hijack function, the buzzer (built in combination meter) will
sound.
KEY REMINDER OPERATION
The buzzer (combination meter) will sound and the doors will not lock if the door lock and unlock switch is
pressed while the driver door is open and mechanical key is inserted ignition key cylinder.
The buzzer (combination meter) will sound and the doors will not lock if the door lock and unlock switch is
pressed while any door other than the driver door is open.
Door lock op-
eration warn-
ingRequest
switch opera-
tionWhen request switch is pushed (lock op-
eration) under the following conditions.
Door switch: ON (Any door is open).
Ignition switch is in ACC or OFF posi-
tion or ignition knob is pressed in
LOCK position or mechanical key is
inserted into ignition key cylinder.
Intelligent Key is inside vehicle.——Active for 2
seconds
(pipipi···)
Intelligent Key
button opera-
tionWhen Intelligent Key button is pushed
(lock operation) under the following con-
ditions.
Door switch: ON (Any door is open).
Ignition switch is in ACC or OFF posi-
tion or ignition knob is pressed in
LOCK position or mechanical key is
inserted into ignition key cylinder.——Active for 2
seconds
(pipipi···)
Intelligent Key low battery
warningWhen Intelligent Key battery voltage is
low, Intelligent Key unit is detected after
ignition switch is turned ON.“KEY”
(GREEN blink-
ing for 30 sec-
onds)—— Warning/Information functions Operation conditions Warning lampWarning chime
Combination
meter buzzerIntelligent Key
warning buzz-
er(s)
Behavior of lamps Operation condition
KEYGREENLightingAll the following conditions are satisfied.
Ignition knob is pushed in LOCK position. (Ignition knob switch is ON)
Ignition key is removed from ignition key cylinder. (Key switch is OFF)
Intelligent Key is detected inside of the vehicle.
KEY RED lighting/blinking conditions are not satisfied.
Blinking while Intelligent Key low battery warning is operating.
REDLightingAll the following conditions are satisfied.
Ignition knob is pushed. (Ignition knob switch is ON)
Ignition key is removed from ignition key cylinder. (Key switch is OFF)
Intelligent Key is not detected inside of the vehicle.
BlinkingAll the following conditions are satisfied.
Take away warning is operating.
KEY RED lighting condition is not satisfied.
LOCK Blinking While OFF position warning is operating.
KEY(RED) and LOCK lightingAll the following conditions are satisfied.
Ignition switch is ON.
Steering lock ID is NG.

Page 856 of 5883

NISSAN TIIDA 2007 Service Repair Manual WARNING FUNCTION
DLK-267
< FUNCTION DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
Component Parts LocationINFOID:0000000001396704
ALKIA0816ZZ
