TIMING CHAIN
7. Hold crankshaft pulley (1) using suitable tool (A) loosen crank-
shaft pulley bolt, and locate bolt seating surface at 10 mm (0.39
in) from its original position.
CAUTION:
Never remove the crankshaft pulley bolt as it will be used as
a supporting point for the pulley puller.
8. Attach a pulley puller (A) in the M6 thread hole on crankshaft
pulley (1), and remove crankshaft pulley.
9. Remove oil pan (lower). Refer to EM-166
.
NOTE:
When crankshaft sprocket, oil pump sprocket and other related parts are not removed, this step is unnec-
essary.
10. Remove intake valve timing control solenoid valve.
11. Remove drive belt auto-tensioner.
12. Loosen bolts in reverse order as shown.
PBIC3961E
Tool number : KV11103000 ( — )
PBIC3962E
PBIC3164J
Page 2826 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-179
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
13. Cut liquid gasket by prying the position ( ) shown, and then
remove the front cover.
CAUTION:
Be careful not to NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-179
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
13. Cut liquid gasket by prying the position ( ) shown, and then
remove the front cover.
CAUTION:
Be careful not to](/manual-img/5/57395/w960_57395-2825.png)
TIMING CHAIN
EM-179
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
13. Cut liquid gasket by prying the position ( ) shown, and then
remove the front cover.
CAUTION:
Be careful not to damage the mating surface.
A more adhesive liquid gasket is applied compared to pre-
vious types when shipped, so it should not be forced off
the position not specified.
14. Remove front oil seal from front cover.
Lift up front oil seal using a suitable tool.
CAUTION:
Be careful not to damage front cover.
15. Push in timing chain tensioner plunger.
16. Insert a stopper pin (A) into the body hole to retain the plunger in
collapsed position.
NOTE:
Use approximately 1.5 mm (0.059 in) diameter. hard metal pin
as a stopper pin.
17. Remove timing chain tensioner (1).
18. Remove timing chain slack guide (2), timing chain tension guide
(3) and timing chain (1).
CAUTION:
Never rotate each crankshaft and camshaft individually
while timing chain is removed. It causes interference
between valve and piston.
PBIC3357J
PBIC3165J
AWBIA0138ZZ
Page 2827 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-180
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
19. Press stopper tab (A) in the direction shown to push the timing
chain slack guide (B) toward timing chain tensioner (for oil
pump) (1).
The slac NISSAN TIIDA 2007 Service Repair Manual EM-180
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
19. Press stopper tab (A) in the direction shown to push the timing
chain slack guide (B) toward timing chain tensioner (for oil
pump) (1).
The slac](/manual-img/5/57395/w960_57395-2826.png)
EM-180
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
19. Press stopper tab (A) in the direction shown to push the timing
chain slack guide (B) toward timing chain tensioner (for oil
pump) (1).
The slack guide (B) is released by pressing the stopper tab
(A). As a result, the slack guide (B) can be moved.
20. Insert stopper pin (D) into tensioner body hole (C) to secure tim-
ing chain slack guide (B).
NOTE:
Use a hard metal pin with a diameter of approximately 1.2 mm
(0.047 in) as a stopper pin.
21. Remove timing chain tensioner (for oil pump).
22. Hold the WAF part of oil pump shaft (A), and then loosen the oil pump sprocket bolt and remove them.
CAUTION:
Secure the oil pump shaft with the WAF part.
Never loosen the oil pump sprocket bolt by tightening the
oil pump drive chain.
23. Remove crankshaft sprocket, oil pump sprocket and oil pump drive chain as a set.
24. Remove timing chain tension guide (front cover side) from front cover if necessary.
INSPECTION AFTER REMOVAL
Timing Chain
PBIC5314E
1 : Oil pan (upper)
2 : Oil pump
: Engine front
PBIC3539J
Page 2828 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-181
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Check timing chain and oil pump drive chain for cracks (A) and any
excessive wear (B) at the roller links of timing NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-181
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Check timing chain and oil pump drive chain for cracks (A) and any
excessive wear (B) at the roller links of timing](/manual-img/5/57395/w960_57395-2827.png)
TIMING CHAIN
EM-181
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Check timing chain and oil pump drive chain for cracks (A) and any
excessive wear (B) at the roller links of timing chain.
Replace timing chain and/or oil pump drive chain if necessary.
INSTALLATION
NOTE:
The figure shows the relationship between the matching mark on
each timing chain and that on the corresponding sprocket, with the
components installed.
1. Make sure that crankshaft key points straight up.
NOTE:
*: There are two outer grooves in camshaft sprocket (INT). The wider one is a matching mark.
2. If the timing chain tension guide (front cover side) is removed, install it to the front cover.
CAUTION:
Check the joint condition by sound or feeling.
3. Install crankshaft sprocket (2), oil pump sprocket (3) and oil
pump drive chain (1).
Install it by aligning matching marks on each sprocket and oil
pump drive chain.
If these matching marks are not aligned, rotate the oil pump
shaft slightly to correct the position.
CAUTION:
Check matching mark position of each sprocket after
installing the oil pump drive chain.
PBIC3169J
1 : Timing chain
2 : Camshaft sprocket (EXH)
3 : Timing chain slack guide
4 : Timing chain tensioner
5 : Oil pump sprocket
6 : Oil pump drive chain
7 : Chain tensioner (for oil pump)
8 : Crankshaft sprocket
9 : Timing chain tension guide
10 : Camshaft sprocket (INT)
A : Matching mark (dark blue link)
B : Matching mark (stamping)
C : Crankshaft key position (straight up)
D : Matching mark (orange link)
E : Matching mark (orange link)
F : Matching mark (outer groove*)
A : Matching mark (stamping)
B : Matching mark (orange link)
C : Matching mark (dark blue link)
AWBIA0140ZZ
PBIC3171J
Page 2829 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-182
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
4. Hold the WAF part of oil pump shaft (A), and then tighten the oil
pump sprocket bolt.
CAUTION:
Secure the oil pump shaft with the WAF part.
Nev NISSAN TIIDA 2007 Service Repair Manual EM-182
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
4. Hold the WAF part of oil pump shaft (A), and then tighten the oil
pump sprocket bolt.
CAUTION:
Secure the oil pump shaft with the WAF part.
Nev](/manual-img/5/57395/w960_57395-2828.png)
EM-182
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
4. Hold the WAF part of oil pump shaft (A), and then tighten the oil
pump sprocket bolt.
CAUTION:
Secure the oil pump shaft with the WAF part.
Never loosen the oil pump sprocket bolt by tightening the
oil pump drive chain.
5. Install chain tensioner (for oil pump) (1).
Fix the plunger at the most compressed position using a stop-
per pin (A), and then install it.
Securely pull out ( ) the stopper pin after installing the chain
tensioner (for oil pump).
Check matching mark position of oil pump drive chain and
each sprocket again.
6. Align the matching marks of each sprocket with the matching
marks of timing chain.
NOTE:
*: There are 2 outer grooves in camshaft sprocket (INT). The
wider one is a matching mark.
If these matching marks are not aligned, rotate the camshaft
slightly by holding the hexagonal portion to correct the posi-
tion.
CAUTION:
Check matching mark position of each sprocket and timing
chain again after installing the timing chain.
1 : Oil pan (upper)
2: Oil pump
: Engine front
PBIC3539J
AWBIA0139ZZ
1 : Camshaft sprocket (EXH)
2 : Camshaft sprocket (INT)
3 : Timing chain
A : Matching mark (dark blue link)
B : Matching mark (stamping)
C : Matching mark (outer groove*)
D : Matching mark (orange link)
E : Matching mark (stamping)
PBIC3172J
Page 2830 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-183
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
7. Install the timing chain tension guide (3) and the timing chain
slack guide (2).
8. Install timing chain tensioner NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-183
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
7. Install the timing chain tension guide (3) and the timing chain
slack guide (2).
8. Install timing chain tensioner](/manual-img/5/57395/w960_57395-2829.png)
TIMING CHAIN
EM-183
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
7. Install the timing chain tension guide (3) and the timing chain
slack guide (2).
8. Install timing chain tensioner (1).
Fix the plunger at the most compressed position using a stop-
per pin (A), and then install it.
Securely pull out the stopper pin after installing the timing
chain tensioner.
9. Check matching mark position of timing chain and each sprocket again.
10. Apply new engine oil to new front oil seal joint surface.
11. Using a suitable tool install front oil seal so that each seal lip is oriented as shown.
Press-fit front oil seal until it is flush with front end surface of
front cover as shown below with a suitable tool.
CAUTION:
Be careful not to damage front cover and crankshaft.
Press-fit oil seal straight to avoid causing burrs or tilting.
Never touch grease applied onto oil seal lip.
12. Install new O-ring to cylinder block.
CAUTION:
1 : Timing chain
AWBIA0138ZZ
PBIC3165J
A : Dust seal lip
B: Oil seal lip
: Engine front
: Engine rear
Within 0.3 mm (0.012 in) toward engine front
Within 0.5 mm (0.020 in) toward engine rear
PBIC3485J
Page 2831 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-184
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
Be sure O-rings a aligned properly.
13. Apply the sealant without breaks to the specified location using
Tool.
Use Genuine Silicone RTV Sealant or eq NISSAN TIIDA 2007 Service Repair Manual EM-184
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
Be sure O-rings a aligned properly.
13. Apply the sealant without breaks to the specified location using
Tool.
Use Genuine Silicone RTV Sealant or eq](/manual-img/5/57395/w960_57395-2830.png)
EM-184
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
Be sure O-rings a aligned properly.
13. Apply the sealant without breaks to the specified location using
Tool.
Use Genuine Silicone RTV Sealant or equivalent. Refer to
GI-27, "
Recommended Chemical Products and Sealants".
14. Make sure that matching marks of timing chain and each sprocket are still aligned.
CAUTION:
Make sure O-ring on cylinder block is correctly installed.
Be careful not to damage front oil seal by interference with front end of crankshaft.
15. Install front cover, and tighten bolts in numerical order as shown.
CAUTION:
Attaching should be done within 5 minutes after liquid gas-
ket application.
NOTE:
Follow the installation position of bolts as shown.
16. Tighten all bolts are in two stages to specified torque in numeri-
cal order as shown.
CAUTION:
Be sure to wipe off any excessive liquid gasket leaking.
17. Install crankshaft pulley.
CAUTION:
Never damage front oil seal lip section.
If needed use a plastic hammer, tap on its center portion (not circumference) to seat crankshaft
pulley.Tool number WS39930000 ( – )
A : Liquid gasket application area
: Engine outside
PBIC3959E
M6 bolts : No. 1
M10 bolts : No. 6, 7, 10, 11, 14
M12 bolts : No. 2, 4, 8, 12
M8 bolts : Except the above
PBIC3164J
Page 2832 of 5883
TIMING CHAIN
EM-185
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
18. Secure crankshaft pulley (1) using tool (A).
19. Apply new engine oil to thread and seat surfaces of crankshaft
pulley bolt.
20. Tighten crankshaft pulley bolt in three steps.
21. Put a paint mark (B) on crankshaft pulley (2), matching with any
one of six easy to recognize angle marks (A) on crankshaft pul-
ley bolt (1) flange.
22. Turn another 60 degrees clockwise (angle tightening) using
Tool.
Check the tightening angle with movement of one angle mark.
23. Make sure that crankshaft rotates clockwise smoothly.
24. Installation of the remaining components is in the reverse order of removal.Step 1 : 68.6 N·m (7.0 kg-m, 51 ft-lb)
Step 2 : 0 N·m (0 kg-m, 0 ft-lb)
Step 3 : 29.4 N·m (3.0 kg-m, 22 ft-lb)
PBIC3961E
Tool number : KV10112100 (BT-8653-A)
PBIC3963E
