Page 3121 of 5883
REAR BUMPER
EXT-17
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
Removal and Installation - SedanINFOID:0000000001568928
Sedan Models
REMOVAL
1. Open trunk lid.
2. Remove rear combination lamp RH/LH. Refer to EXL-93, "
Removal and Installation".
3. Remove rear bumper fascia spring nuts and screws RH/LH.
4. Remove rear fender protector. Refer to EXT-22, "
Removal and Installation".
5. Pull the rear bumper fascia side outward and release the bumper side bracket.
6. Remove rear bumper fascia upper clips and screws.
AWKIA0103ZZ
1. Rear bumper upper retainer 2. Rear fender protector 3. Spring nut
4. Bumper side bracket 5. Lower panel 6. Bumper reinforcement bracket
7. Rear bumper reinforcement 8. Energy absorbing foam 9. Rear bumper molding RH,LH
10. Rear bumper fascia 11. Rear bumper fog lamp (if equipped) A. Clip C205
Page 3122 of 5883
EXT-18
< ON-VEHICLE REPAIR >
REAR BUMPER
7. Release rear bumper upper retainer (1), then pull rear bumper
fascia outward away from rear of vehicle.
8. Disconnect the rear fog lamp harness and remove the rear fog lamp.
9. Remove energy absorbing foam and rear bumper reinforcement.
10. Remove the bumper side bracket (1) RH/LH.
INSTALLATION
Installation is in the reverse order of removal.
LIIA2580E
LIIA2921E
Page 3123 of 5883
FRONT GRILLE
EXT-19
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
FRONT GRILLE
Removal and InstallationINFOID:0000000001568929
REMOVAL
1. Open hood assembly.
2. Remove the clips, then remove upper radiator cover.
3. Remove the upper clips and release the lower pawls, then pull outward to remove the front grille.
INSTALLATION
Installation is in the reverse order of removal.
LIIA2564E
1. Upper radiator cover 2. Front grille 3. Front bumper fascia
4. Clip C205 Pawl
Page 3124 of 5883
EXT-20
< ON-VEHICLE REPAIR >
COWL TOP
COWL TOP
Removal and InstallationINFOID:0000000001568930
REMOVAL
1. Remove the front wiper arm RH/LH from vehicle. Refer to WW-70, "Removal and Installation".
2. Disconnect the washer tube.
3. Remove the fender seal and fender cover RH/LH.
4. Release the cowl top seal clips, then remove the cowl top seal.
LIIA2565E
1. Fender cover 2. Fender seal 3. Washer tube
4. Cowl top seal 5. Cowl extension panel 6. Dual lock fastener
7. Double-faced adhesive tape 8. Cowl top cover 9. Clip C205
10. EPT sealer 11. Cowl extension clip 12. Cover
Clip CE103⇐Vehicle front
PIIB2555J
Page 3125 of 5883
COWL TOP
EXT-21
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
5. Release the cowl extension clip (1) by prying the center pawls
apart and pulling clip outward. Remove the remaining clips, then
remove the cowl top cover (2).
6. Disconnect and remove the front wiper motor and linkage
assembly. Refer to WW-73, "
Removal and Installation".
CAUTION:
To avoid damage, make sure to cover the lower edge of
windshield with suitable protection material.
7. Remove the cowl extension panel bolts, then remove the cowl extension panel.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
For wiper arm RH/LH installation and adjustment, Refer to WW-70, "
Removal and Installation".
Always replace EPT sealer and double-faced adhesive tape when installing cowl top cover.
LIIA2566E
PIIB6038E
Page 3126 of 5883
EXT-22
< ON-VEHICLE REPAIR >
FENDER PROTECTOR
FENDER PROTECTOR
ComponentINFOID:0000000001568931
Removal and InstallationINFOID:0000000001568932
FRONT FENDER PROTECTOR
Removal
1. Remove the front fender protector bolts and clips.
2. Remove the front fender protector.
Installation
Installation is in the reverse order of removal.
REAR FENDER PROTECTOR
Removal
1. Remove the rear fender protector bolt (B) and clips (A) (C205).
2. Remove the rear fender protector (1).
: Front
Installation
Installation is in the reverse order of removal.
1. Front fender protector 2. Clip C205 Clip C103
⇐Vehicle front
AWKIA0101ZZ
AWKIA0100ZZ
Page 3127 of 5883
ROOF SIDE MOLDING
EXT-23
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
L
MA
B
EXT
N
O
P
ROOF SIDE MOLDING
ComponentINFOID:0000000001568933
Hatchback Models
Sedan Models
Removal and InstallationINFOID:0000000001568934
REMOVAL
1. Using a suitable tool, release the rear roof side molding clip and remove.
2. Lift up rear edge of roof side molding working forward.
3. Release front roof side molding clip, then remove roof side molding.
INSTALLATION
Installation is in the reverse order of removal.
NOTE:
WIIA1408E
1. Roof side molding A. Front roof side molding clip B. Rear roof side molding clip
WIIA1409E
1. Roof side molding A. Front roof side molding clip B. Rear roof side molding clip
Page 3128 of 5883
EXT-24
< ON-VEHICLE REPAIR >
ROOF SIDE MOLDING
Make sure front edge of roof side molding contacts windshield mold-
ing with no gap.
NOTE:
For Setting the new clip A or B, use EPoxy Adhesive DP-100C made
by 3M. For adhesive DP-100C application use an applicator 9170
EPX W 1:1 and mixer nozzle 9742 EPX 50ML made by 3M.
PIIB2599J
