Page 4489 of 5883

NISSAN TIIDA 2007 Service Repair Manual PWC-28 < COMPONENT DIAGNOSIS > POWER WINDOW MOTOR 1. Turn ignition switch OFF. 2. Disconnect rear power window switch RH. 3. Check continuity between rear power window switch RH con- nector (A) and re

Page 4490 of 5883

NISSAN TIIDA 2007 Service Repair Manual ENCODER PWC-29 < COMPONENT DIAGNOSIS > C D E F G H I J L MA B PWC N O P ENCODER DRIVER SIDE DRIVER SIDE : DescriptionINFOID:0000000001696333 Detects condition of the front power window motor (driver s

Page 4491 of 5883

NISSAN TIIDA 2007 Service Repair Manual PWC-30 < COMPONENT DIAGNOSIS > ENCODER 1. Turn ignition switch ON. 2. Check voltage between front power window motor (driver side) connector and ground. Is the measurement value within the specificati

Page 4492 of 5883

NISSAN TIIDA 2007 Service Repair Manual ENCODER PWC-31 < COMPONENT DIAGNOSIS > C D E F G H I J L MA B PWC N O P 1. Disconnect main power window and door lock/unlock switch. 2. Check continuity between main power window and door lock/ unlock

Page 4493 of 5883

NISSAN TIIDA 2007 Service Repair Manual PWC-32 < COMPONENT DIAGNOSIS > DOOR SWITCH DOOR SWITCH DescriptionINFOID:0000000001696337 Detects door open/close condition and transmits the signal to BCM. Component Function CheckINFOID:000000000169

Page 4494 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR SWITCH PWC-33 < COMPONENT DIAGNOSIS > C D E F G H I J L MA B PWC N O P Is the inspection result normal? YES >> GO TO 3 NO >> Repair or replace harness. 3. CHECK FRONT DOOR SWITCH Check front door

Page 4495 of 5883

NISSAN TIIDA 2007 Service Repair Manual PWC-34 < COMPONENT DIAGNOSIS > POWER WINDOW LOCK SWITCH POWER WINDOW LOCK SWITCH DescriptionINFOID:0000000001696341 Ground circuit of main power window and door lock/unlock switch shuts off if power w

Page 4496 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCM (BODY CONTROL MODULE) PWC-35 < ECU DIAGNOSIS > C D E F G H I J L MA B PWC N O P ECU DIAGNOSIS BCM (BODY CONTROL MODULE) Reference ValueINFOID:0000000001696344 VALUES ON THE DIAGNOSIS TOOL CONSULT-
