Page 5737 of 5883

WCS-22
< COMPONENT DIAGNOSIS >
POWER SUPPLY AND GROUND CIRCUIT
Check that the following fuses and fusible link are not fusing.
Is the fuse fusing?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit if a fuse or fusible link is
blown.
NO >> GO TO 2.
2. CHECK POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM.
3. Check voltage between BCM harness connector and ground.
Is the measurement value normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK GROUND CIRCUIT
Check continuity between BCM harness connector and ground.
Does continuity exist?
YES >> INSPECTION END
NO >> Repair or replace harness.
Terminal No. Signal name Fuses and fusible link No.
22
Battery power supply9 (10A)
728 (10A)
74
G (40A)
79
24 Ignition power supply 55 (10A)
Te r m i n a l s
Ignition switch position
(+)
(−) BCM
OFF ACC ON
Connector Terminal
M1822
GroundBattery
voltageBattery
voltageBattery
voltage
24Approx.
0 VApprox.
0 VBattery
voltage
M2072
Battery
voltageBattery
voltageBattery
voltage 74
79
ALMIA0188ZZ
BCM
GroundContinuity
Connector Terminal
M18 2
Ye s
M20 70
ALMIA0189ZZ
Page 5738 of 5883
WCS
METER BUZZER CIRCUIT
WCS-23
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
METER BUZZER CIRCUIT
DescriptionINFOID:0000000001722929
The buzzer for warning chime system is installed in the combination meter.
The combination meter sounds the alarm buzzer based on the signals transmitted from various units.
Component Function CheckINFOID:0000000001722930
1.CHECK OPERATION OF METER BUZZER
1. Select “BUZZER” of “BCM” on CONSULT-III.
2. Perform “LIGHT WARN ALM” of “ACTIVE TEST”.
Does meter buzzer activate?
YES >> Inspection End.
NO >> Replace combination meter. Refer to MWI-94, "
Removal and Installation".
Diagnosis ProcedureINFOID:0000000001722931
1.CHECK POWER SUPPLY OF COMBINATION METER
Check power supply of combination meter. Refer to WCS-21, "
COMBINATION METER : Diagnosis Proce-
dure".
Is the inspection result normal?
YES >> Inspection End.
NO >> Repair power supply circuit of combination meter.
Page 5739 of 5883

WCS-24
< COMPONENT DIAGNOSIS >
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
DescriptionINFOID:0000000001722932
Transmits a seat belt buckle switch signal to the combination meter.
Component Function CheckINFOID:0000000001722933
1.CHECK COMBINATION METER INPUT SIGNAL
Select “DATA MONITOR” for “METER/M&A” and check the “SEAT BELT W/L” monitor value.
>> Inspection End.
Diagnosis ProcedureINFOID:0000000001722934
1.CHECK COMBINATION METER INPUT SIGNAL
1. Turn ignition switch ON.
2. Check voltage between combination meter harness connector
M24 terminal 3 and ground.
Is the inspection result normal?
YES >> Replace combination meter. Refer to MWI-94, "Removal
and Installation".
NO >> GO TO 2
2.CHECK SEAT BELT BUCKLE SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect combination meter connector and seat belt warning
lamp control unit connector.
3. Check continuity between combination meter harness connector
M24 (A) terminal 3 and seat belt warning lamp control unit har-
ness connector B51 (B) terminal 36.
4. Check continuity between combination meter harness connector
M24 (A) terminal 3 and ground.
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair harness or connector.
3.CHECK SEAT BELT BUCKLE SWITCH CIRCUITSEAT BELT W/L
When seat belt is fastened : OFF
When seat belt is unfastened : ON
3 - Ground
When driver seat belt is fastened : Approx. 12V
When driver seat belt is unfastened : Approx. 0V
AWNIA0264ZZ
3 - 36 : Continuity should exist.
3 - Ground : Continuity should not exist.
AWNIA0265ZZ
Page 5740 of 5883

WCS
SEAT BELT BUCKLE SWITCH SIGNAL CIRCUIT
WCS-25
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
1. Disconnect seat belt buckle switch (driver side) connector.
2. Check continuity between seat belt warning lamp control unit
harness connector B51 (A) terminal 21 and seat belt buckle
switch (driver side) harness connector B9 (B) terminal 1.
3. Check continuity between seat belt warning lamp control unit
harness connector B51 (B) terminal 21 and ground.
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair harness or connector.
4.CHECK SEAT BELT BUCKLE SWITCH GROUND CIRCUIT
Check continuity between seat belt buckle switch (driver side) har-
ness connector B9 terminal 2 and ground.
Is the inspection result normal?
YES >> GO TO 5
NO >> Repair harness or connector.
5.CHECK SEAT BELT BUCKLE SWITCH
Perform a unit inspection for the seat belt buckle switch (driver side). Refer to WCS-25, "
Component Inspec-
tion".
Is the inspection result normal?
YES >> Replace the seat belt warning lamp control unit.
NO >> Replace the seat belt buckle switch (driver side).
Component InspectionINFOID:0000000001722935
1.CHECK SEAT BELT BUCKLE SWITCH
1. Turn ignition switch OFF.
2. Disconnect the seat belt buckle switch (driver side) connector.
3. Check continuity between terminals 1 and 2.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace the seat belt buckle switch (driver side).21 - 1 : Continuity should exist.
21 - Ground : Continuity should not exist.
AWNIA0266ZZ
2 - Ground : Continuity should exist.
AWNIA0267ZZ
1 – 2
When seat belt is
fastened: Continuity should not exist.
When seat belt is
unfastened: Continuity should exist.
AWNIA0268ZZ
Page 5741 of 5883

WCS-26
< COMPONENT DIAGNOSIS >
KEY SWITCH SIGNAL CIRCUIT (WITH INTELLIGENT KEY)
KEY SWITCH SIGNAL CIRCUIT (WITH INTELLIGENT KEY)
DescriptionINFOID:0000000001722936
Transmits a key switch signal to the BCM.
Component Function CheckINFOID:0000000001722937
1.CHECK BCM INPUT SIGNAL
Select “DATA MONITOR” for “BCM” and check the “KEY IN SW” monitor value.
>> Inspection End.
Diagnosis ProcedureINFOID:0000000001722938
1.CHECK FUSE
Check if the key switch and ignition knob switch 10A fuse (No. 31, located in the fuse and relay box) is blown.
Is the fuse blown?
YES >> Be sure to repair the cause of malfunction before installing new fuse.
NO >> GO TO 2
2.CHECK BCM INPUT SIGNAL
Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 3
3.CHECK KEY SWITCH CIRCUIT
1. Disconnect BCM and key switch and ignition knob switch con-
nectors.
2. Check continuity between BCM harness connector M18 (A) and
key switch and ignition knob switch harness connector M32 (B).
3. Check continuity between BCM harness connector M18 (A) and
ground.KEY IN SW
When key is inserted into key cylinder : ON
When key is removed from key cylinder : OFF
Te r m i n a l s
ConditionVo l ta g e
(Approx.) (+)
(−)
BCM
connectorTe r m i n a l
M18 3 GroundKey is inserted Battery voltage
Key is removed 0
AWNIA0269ZZ
AB
Continuity
Connector Terminal Connector Terminal
M183M321 Yes
A
GroundContinuity
Connector Terminal
M18 3 No
AWNIA0270ZZ
Page 5742 of 5883

WCS
KEY SWITCH SIGNAL CIRCUIT (WITH INTELLIGENT KEY)
WCS-27
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair harness or connector.
4.CHECK KEY SWITCH POWER SUPPLY CIRCUIT
Check voltage between key switch and ignition knob switch harness
connector and ground.
Is the inspection result normal?
YES >> Replace key switch and ignition knob switch.
NO >> Repair harness or connector.
Component InspectionINFOID:0000000001722939
1.CHECK KEY SWITCH
1. Turn ignition switch OFF.
2. Disconnect key switch and ignition knob switch connector.
3. Check continuity between key switch and ignition knob switch
terminals 1 and 2.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace key switch and ignition knob switch.
Te r m i n a l s
Vo l ta g e
(Approx.) (+)
(−) Key switch and ignition
knob switch connector Te r m i n a l
M32 2 Ground Battery voltage
AWNIA0271ZZ
1 – 2
When key is inserted
into key cylinder: Continuity should exist.
When key is removed
from key cylinder: Continuity should not exist.
AWNIA0272ZZ
Page 5743 of 5883

WCS-28
< COMPONENT DIAGNOSIS >
KEY SWITCH SIGNAL CIRCUIT (WITHOUT INTELLIGENT KEY)
KEY SWITCH SIGNAL CIRCUIT (WITHOUT INTELLIGENT KEY)
DescriptionINFOID:0000000001722940
Transmits a key switch signal to the BCM.
Component Function CheckINFOID:0000000001722941
1.CHECK BCM INPUT SIGNAL
Select “DATA MONITOR” for “BCM” and check the “KEY IN SW” monitor value.
>> Inspection End.
Diagnosis ProcedureINFOID:0000000001722942
1.CHECK FUSE
Check if the key switch and key lock solenoid 10A fuse [No. 14, located in the fuse block (J/B)] is blown.
Is the fuse blown?
YES >> Be sure to repair the cause of malfunction before installing new fuse.
NO >> GO TO 2
2.CHECK BCM INPUT SIGNAL
Check voltage between BCM harness connector and ground.
Is the inspection result normal?
YES >> Inspection End.
NO >> GO TO 3
3.CHECK KEY SWITCH CIRCUIT
1. Disconnect BCM and key switch and key lock solenoid connec-
tors.
2. Check continuity between BCM harness connector M18 (A) and
key switch and key lock solenoid harness connector M27 (B).
3. Check continuity between BCM harness connector M18 (A) and
ground.KEY IN SW
When key is inserted into key cylinder : ON
When key is removed from key cylinder : OFF
Te r m i n a l s
ConditionVo l ta g e
(Approx.) (+)
(−)
BCM
connectorTe r m i n a l
M18 3 GroundKey is inserted Battery voltage
Key is removed 0
AWNIA0269ZZ
AB
Continuity
Connector Terminal Connector Terminal
M183M271 Yes
A
GroundContinuity
Connector Terminal
M18 3 No
AWNIA0270ZZ
Page 5744 of 5883

WCS
KEY SWITCH SIGNAL CIRCUIT (WITHOUT INTELLIGENT KEY)
WCS-29
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
L
MB A
O
P
Is the inspection result normal?
YES >> GO TO 4
NO >> Repair harness or connector.
4.CHECK KEY SWITCH POWER SUPPLY CIRCUIT
Check voltage between key switch and key lock solenoid harness
connector and ground.
Is the inspection result normal?
YES >> Replace key switch and key lock solenoid.
NO >> Repair harness or connector.
Component InspectionINFOID:0000000001722943
1.CHECK KEY SWITCH
1. Turn ignition switch OFF.
2. Disconnect key switch and key lock solenoid connector.
3. Check continuity between key switch and key lock solenoid ter-
minals 1 and 2.
Is the inspection result normal?
YES >> Inspection End.
NO >> Replace key switch and key lock solenoid.
Te r m i n a l s
Vo l ta g e
(Approx.) (+)
(−) Key switch and key lock
solenoid Te r m i n a l
M27 2 Ground Battery voltage
AWNIA0271ZZ
1 – 2
When key is inserted
into key cylinder: Continuity should exist.
When key is removed
from key cylinder: Continuity should not exist.
AWNIA0272ZZ
