Page 305 of 5883
BRC-72
< ECU DIAGNOSIS >[ABS]
ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)
C1145 YAW RATE SENSOR
XX-XX, "*****"
C1146 SIDE G-SEN CIRCUIT
C1155 BR FLUID LEVEL LOWBRC-56, "
Description"
C1156 ST ANG SEN COM CIRXX-XX, "*****"
C1160 DECEL G SEN SETXX-XX, "*****"
C1163 ST ANGL SEN SAFEXX-XX, "*****"
C1164 CV1
XX-XX, "*****"
C1165 CV2
C1166 SV1
C1167 SV2
C1170 VARIANT CORDINGBRC-38, "
DTC Logic"
C1178 ABS ACTIVE BOOSTER SV NGXX-XX, "*****"
C1179 ABS DELTA S SEN NGXX-XX, "*****"
C1181 ABS ACTIVE BOOSTER RESPONSE NG
XX-XX, "*****"
C1184 ABS BRAKE RELEASE SW NG
C1189 ABS BRAKE BOOSTER DEFECT
U1000 CAN COMM CIRCUITBRC-59, "
Description"
DTC Items (CONSULT screen terms) Reference
Page 306 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ABS
BRC-73
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SYMPTOM DIAGNOSIS
ABS
Symptom TableINFOID:0000000001731343
If ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp tu NISSAN TIIDA 2007 Service Repair Manual ABS
BRC-73
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SYMPTOM DIAGNOSIS
ABS
Symptom TableINFOID:0000000001731343
If ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp tu](/manual-img/5/57395/w960_57395-305.png)
ABS
BRC-73
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
SYMPTOM DIAGNOSIS
ABS
Symptom TableINFOID:0000000001731343
If ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp turn ON, perform self-diagnosis.
NOTE:
1: The ABS does not operate when the speed is 10 km/h (6 MPH) or less.
2: Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly depressed. However, this is normal.
- When shifting gears
- When driving on slippery road
- During cornering at high speed
- When passing over bumps or grooves [at approximately 50 mm (1.97 in) or more]
- When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]Symptom Check item Reference
Excessive ABS function operation fre-
quencyBrake force distribution
BRC-74, "
Diagno-
sis Procedure"Looseness of front and rear axle
Wheel sensor and rotor system
Unexpected pedal reactionBrake pedal stroke
BRC-75, "
Diagno-
sis Procedure"Make sure the braking force is sufficient when the ABS is not operating.
The braking distance is long Check stopping distance when the ABS is not operating.BRC-76, "
Diagno-
sis Procedure"
ABS function does not operate (Note 1) ABS actuator and electric unit (control unit)BRC-77, "Diagno-
sis Procedure"
Pedal vibration or ABS operation sound
occurs (Note 2)Brake pedal
BRC-78, "Diagno-
sis Procedure"ABS actuator and electric unit (control unit)
Page 307 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BRC-74
< SYMPTOM DIAGNOSIS >[ABS]
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
Diagnosis ProcedureINFOID:0000000001731344
1.CHECK START
Check front and rear br NISSAN TIIDA 2007 Service Repair Manual BRC-74
< SYMPTOM DIAGNOSIS >[ABS]
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
Diagnosis ProcedureINFOID:0000000001731344
1.CHECK START
Check front and rear br](/manual-img/5/57395/w960_57395-306.png)
BRC-74
< SYMPTOM DIAGNOSIS >[ABS]
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
EXCESSIVE ABS FUNCTION OPERATION FREQUENCY
Diagnosis ProcedureINFOID:0000000001731344
1.CHECK START
Check front and rear brake force distribution using a brake tester.
Is the inspection result normal?
YES >> GO TO 2
NO >> Check brake system.
2.CHECK FRONT AND REAR AXLE
Make sure that there is no excessive play in the front and rear axles. Refer to front: FA X - 6 , "
On-Vehicle
Inspection and Service", Rear: RAX-5, "On-Vehicle Inspection and Service".
Is the inspection result normal?
YES >> GO TO 3
NO >> Repair or replace malfunctioning components.
3.CHECK WHEEL SENSOR AND SENSOR ROTOR
Check the following.
Wheel sensor installation for damage.
Sensor rotor installation for damage.
Wheel sensor connector connection.
Wheel sensor harness inspection.
Is the inspection result normal?
YES >> GO TO 4
NO >> Replace wheel sensor or sensor rotor. Refer to BRC-83, "
Removal and Installation".
Repair harness.
4.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp is turned off after the ignition switch is turned ON or when driving.
Is the ABS warning lamp illuminated?
YES >> Perform self-diagnosis. Refer to BRC-25, "CONSULT-III Function (ABS)".
NO >> Normal
Page 308 of 5883
UNEXPECTED PEDAL REACTION
BRC-75
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
UNEXPECTED PEDAL REACTION
Diagnosis ProcedureINFOID:0000000001731345
1.CHECK BRAKE PEDAL STROKE
Check brake pedal stroke. Refer to BR-6, "
Inspection and Adjustment".
Is the stroke too large?
YES >> Bleed air from brake tube and hose. Refer to BR-8, "Bleeding Brake System".
Check brake pedal, brake booster, and master cylinder for mount play, looseness, brake system
fluid leakage, etc. Refer to BR-18, "
On-Board Inspection" (master cylinder), BR-19, "On Board
Inspection" (brake booster).
NO >> GO TO 2
2.CHECK FUNCTION
Disconnect ABS actuator and electric unit (control unit) connector to deactivate ABS. Check if braking force is
normal in this condition. Connect connector after inspection.
Is the inspection result normal?
YES >> Normal
NO >> Check brake system.
Page 309 of 5883
BRC-76
< SYMPTOM DIAGNOSIS >[ABS]
THE BRAKING DISTANCE IS LONG
THE BRAKING DISTANCE IS LONG
Diagnosis ProcedureINFOID:0000000001731346
CAUTION:
The stopping distance on slippery road surfaces might be longer with the ABS operating than when
the ABS is not operating.
1.CHECK FUNCTION
Turn ignition switch OFF and disconnect ABS actuator and electric unit (control unit) connector to deactivate
ABS. In this condition, check stopping distance. After inspection, connect connector.
Is the inspection result normal?
YES >> Normal
NO >> Check brake system.
Page 310 of 5883
ABS FUNCTION DOES NOT OPERATE
BRC-77
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
ABS FUNCTION DOES NOT OPERATE
Diagnosis ProcedureINFOID:0000000001731347
CAUTION:
ABS does not operate when speed is 10 km/h (6 MPH) or lower.
1.CHECK ABS WARNING LAMP DISPLAY
Make sure that the ABS warning lamp turns OFF after ignition switch is turned ON or when driving.
Is the inspection result normal?
YES >> Normal
NO >> Perform self-diagnosis. Refer to BRC-25, "
CONSULT-III Function (ABS)".
Page 311 of 5883
![NISSAN TIIDA 2007 Service Repair Manual BRC-78
< SYMPTOM DIAGNOSIS >[ABS]
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
Diagnosis ProcedureINFOID:0000000001731348
CAUTION:
Under the following co NISSAN TIIDA 2007 Service Repair Manual BRC-78
< SYMPTOM DIAGNOSIS >[ABS]
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
Diagnosis ProcedureINFOID:0000000001731348
CAUTION:
Under the following co](/manual-img/5/57395/w960_57395-310.png)
BRC-78
< SYMPTOM DIAGNOSIS >[ABS]
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
PEDAL VIBRATION OR ABS OPERATION SOUND OCCURS
Diagnosis ProcedureINFOID:0000000001731348
CAUTION:
Under the following conditions, ABS is activated and vibration is felt when brake pedal is lightly
depressed. However, this is normal.
When shifting gears
When driving on slippery road
During cornering at high speed
When passing over bumps or grooves [at approximately 50 mm (1.97 in) or more]
When pulling away just after starting engine [at approximately 10 km/h (6 MPH) or higher]
1.SYMPTOM CHECK 1
Check that there are pedal vibrations when the engine is started.
Do vibrations occur?
YES >> GO TO 2
NO >> Inspect the brake pedal.
2.SYMPTOM CHECK 2
Check that there are ABS operation noises when the engine is started.
Do the operation noises occur?
YES >> GO TO 3
NO >> Perform self -diagnosis. Refer to BRC-25, "
CONSULT-III Function (ABS)".
3.SYMPTOM CHECK 3
Check symptoms when electrical component (headlamps, etc.) switches are operated.
Do symptoms occur?
YES >> Check if there is a radio, antenna, antenna lead wire, or wiring close to the control unit. If there is,
move it farther away.
NO >> Normal
Page 312 of 5883
![NISSAN TIIDA 2007 Service Repair Manual NORMAL OPERATING CONDITION
BRC-79
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000001731350
Symptom Result
Slight vibrations are felt on NISSAN TIIDA 2007 Service Repair Manual NORMAL OPERATING CONDITION
BRC-79
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000001731350
Symptom Result
Slight vibrations are felt on](/manual-img/5/57395/w960_57395-311.png)
NORMAL OPERATING CONDITION
BRC-79
< SYMPTOM DIAGNOSIS >[ABS]
C
D
E
G
H
I
J
K
L
MA
B
BRC
N
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000001731350
Symptom Result
Slight vibrations are felt on the brake pedal and the operation noises occur, when VDC, TCS or ABS is acti-
vated.
This is a normal condi-
tion due to the VDC,
TCS or ABS activation. Stopping distance is longer than that of vehicles without ABS when the vehicle drives on rough, gravel, or
snow-covered (fresh, deep snow) roads.
The brake pedal moves and generates noises, when TCS or VDC is activated due to rapid acceleration or
sharp turn.
The brake pedal vibrates and motor operation noises occur from the engine room, after the engine starts and
just after the vehicle starts.This is normal, and it is
caused by the ABS op-
eration check.
Depending on the road conditions, the driver may experience a sluggish feel. This is normal, because
TCS places the highest
priority on the optimum
traction (stability). TCS may activate momentarily if wheel speed changes when driving over location where friction coefficient
varies, when downshifting, or when fully depressing accelerator pedal.
The ABS warning lamp, VDC OFF indicator lamp and SLIP indicator lamp may turn ON when the vehicle is
subject to strong shaking or large vibration, such as when the vehicle is rotating on a turntable or located on
a ship while the engine is running. In this case, restart the
engine on a normal
road. If the normal con-
dition is restored, there
is no malfunction. At
that time, erase the self-
diagnosis memory. VDC may not operate normally or the ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp
may illuminate, when running on a special road that is extremely slanted (e.g. bank in a circuit course).
A malfunction may occur in the yaw rate/side/decel G sensor system, when the vehicle turns sharply, such
as during a spin turn, axle turn, or drift driving, while the VDC function is off (VDC OFF indicator lamp illumi-
nated).
The vehicle speed will not increase even though the accelerator pedal is depressed, when inspecting the
speedometer on a 2-wheel chassis dynamometer. Normal (Deactivate the
VDC/TCS function be-
fore performing an in-
spection on a chassis
dynamometer.)
VDC OFF indicator lamp and SLIP indicator lamp may simultaneously turn on when low tire pressure warn-
ing lamp turns on.This is not a VDC sys-
tem error but results
from characteristic
change of tire.
