EM-170
< ON-VEHICLE REPAIR >[MR18DE]
OIL PAN
c. Press-fit the rear oil seal using a drift with outer diameter 115
mm (4.53 in) and inner diameter 90 mm (3.54 in) (A) (commer-
cial service tool).
Press-fit to the specified dimensions as shown.
CAUTION:
Never touch the grease applied to the oil seal lip.
Be careful not to damage the rear oil seal mounting part of
oil pan (upper) and cylinder block or the crankshaft.
Press-fit straight, making sure that rear oil seal does not
curl or tilt.
NOTE:
The standard surface of the dimension is the rear end surface of
cylinder block.
6. Install oil pump.
Tighten bolts in numerical order as shown.
7. Install oil pump sprocket, oil pump drive chain and other related
parts if removed.
8. Use a scraper (A) to remove old liquid gasket from mating sur-
faces.
Also remove old liquid gasket from mating surface of oil pan
(upper).
Remove old liquid gasket from the bolt holes and threads.
PBIC3951E
1 : Rear oil seal
A : Cylinder block rear end surface
1 : Oil pump
2 : Oil pan (upper)
: Engine front
PBIC3952E
PBIC3532J
PBIC3953E
Page 2818 of 5883
OIL PAN
EM-171
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
9. Apply the sealant without breaks to the specified location using
Tool.
Use Genuine Silicone RTV Sealant or equivalent. Refer to
GI-27, "
Recommended Chemical Products and Sealants".
10. Tighten bolts in numerical order as shown.
11. Install oil filter with the following procedure:
a. Remove foreign materials adhering to the oil filter installation
surface.
b. Apply new engine oil to the oil seal contact surface of new oil fil-
ter.
c. Screw oil filter manually until it touches the installation surface,
then tighten it by 2/3 turn. Or tighten to specification.
12. Installation of the remaining components is in the reverse order of removal.Tool number WS39930000 ( – )
1 : Oil pan (lower)
: Engine outside
PBIC4590E
: Engine front
PBIC3146J
Oil filter: : 17.7 N·m (1.8 kg-m, 13 ft-lb)
SMA229B
Page 2819 of 5883
EM-172
< ON-VEHICLE REPAIR >[MR18DE]
IGNITION COIL
IGNITION COIL
ComponentINFOID:0000000001346465
Removal and InstallationINFOID:0000000001346466
REMOVAL
1. Remove intake manifold. Refer to EM-156, "Removal and Installation".
2. Remove ignition coil.
CAUTION:
Handle it carefully and avoid impacts.
Never disassemble.
INSTALLATION
1. Install ignition coil.
CAUTION:
Handle it carefully and avoid impacts.
Never disassemble.
2. Install intake manifold. Refer to EM-156, "
Removal and Installation".
1. PCV hose 2. Rocker cover 3. Spark plug
4. Ignition coil 5. PCV hose 6. PCV valve
7. O-ring 8. Gasket
A. To air duct B. Refer to EM-173
. C. To intake manifold
PBIC3536J
Page 2820 of 5883
ROCKER COVER
EM-173
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
ROCKER COVER
ComponentINFOID:0000000001346467
Removal and InstallationINFOID:0000000001346468
REMOVAL
1. Remove intake manifold. Refer to EM-156, "Removal and Installation".
2. Remove ignition coil.
CAUTION:
Handle it carefully and avoid impacts.
Never disassemble.
1. PCV hose 2. Rocker cover 3. Spark plug
4. Ignition coil 5. PCV hose 6. PCV valve
7. O-ring 8. Gasket
A. To air duct B. Refer to EM-173
. C. To intake manifold
PBIC3536J
Page 2821 of 5883
EM-174
< ON-VEHICLE REPAIR >[MR18DE]
ROCKER COVER
3. Remove spark plug using suitable tool.
CAUTION:
Never drop or shock it.
4. Remove rocker cover.
Loosen bolts in reverse order as shown.
Engine front
INSPECTION AFTER REMOVAL
CAUTION:
Never drop or shock spark plug.
Checking and adjusting spark plug gap is not required
between change intervals.
If spark plug tip is covered with carbon, a spark plug cleaner may be used.
Never use wire brush for cleaning spark plug.
INSTALLATION
1. Install rocker cover gasket to rocker cover.
PBIC3871E
PBIC3151J
SMA806CA
Cleaner air pressure
: Less than 588 kPa (5.88 bar, 6 kg/cm2, 85 psi)
Cleaning time : Less than 20 seconds
SMA773C
Page 2822 of 5883
ROCKER COVER
EM-175
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
2. Install rocker cover.
Tighten bolts in two steps separately in numerical order as
shown.
Engine front
CAUTION:
Check if rocker cover gasket is not dropped from the instal-
lation groove of rocker cover.
3. Install spark plug using suitable tool.
CAUTION:
Never drop or shock it.
4. Install ignition coil.
CAUTION:
Handle it carefully and avoid impacts.
Never disassemble.
5. Install intake manifold. Refer to EM-156, "
Removal and Installation". 1st step : 1.96 N·m (0.20 kg-m, 17 in-lb)
2nd step : 8.33 N·m (0.85 kg-m, 73 in-lb)
PBIC3151J
PBIC3871E
Page 2823 of 5883
EM-176
< ON-VEHICLE REPAIR >[MR18DE]
TIMING CHAIN
TIMING CHAIN
ComponentINFOID:0000000001337795
1. Timing chain slack guide 2. Timing chain tensioner 3. Camshaft sprocket (EXH)
4. Timing chain 5. Oil filler cap 6. Front cover
7. O-ring 8.Intake valve timing control solenoid
valve9. Crankshaft pulley bolt
10. Crankshaft pulley 11. Front oil seal 12. Drive belt auto-tensioner
13.Timing chain tension guide (front cov-
er side)14. Crankshaft sprocket 15. Oil pump sprocket
PBIC3538J
Page 2824 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-177
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P ORemoval and InstallationINFOID:0000000001337796
CAUTION:
The rotating direction indicated in the text indicates all dir NISSAN TIIDA 2007 Service Repair Manual TIMING CHAIN
EM-177
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P ORemoval and InstallationINFOID:0000000001337796
CAUTION:
The rotating direction indicated in the text indicates all dir](/manual-img/5/57395/w960_57395-2823.png)
TIMING CHAIN
EM-177
< ON-VEHICLE REPAIR >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P ORemoval and InstallationINFOID:0000000001337796
CAUTION:
The rotating direction indicated in the text indicates all directions seen from the engine front.
REMOVAL
1. Remove front RH wheel. Refer to WT-6, "Rotation".
2. Remove front fender protector (RH). Refer to EXT-22, "
Removal and Installation".
3. Drain engine oil. Refer to LU-16, "
Changing Engine Oil".
NOTE:
Perform this step when engine is cold.
4. Remove the following parts.
Rocker cover: Refer to EM-173, "
Removal and Installation".
Drive belt: Refer to EM-142, "
Component".
Water pump pulley: Refer to CO-44, "
Component".
Ground cable (between engine bracket (RH) and radiator core support)
5. Support the bottom surface of engine using a transmission jack, and then remove the engine bracket and
insulator (RH). Refer to EM-207
.
6. Set No. 1 cylinder at TDC on its compression stroke with the following procedure:
a. Rotate crankshaft pulley (1) clockwise and align TDC mark (no paint) (B) to timing indicator (A) on front
cover.
b. At the same time, make sure that the cam noses of the No.1 cyl-
inder are located ( ) as shown.
If not, rotate crankshaft pulley one revolution (360 degrees)
and align as shown.
16. Oil pump drive chain 17. Camshaft sprocket (INT) 18. Timing chain tension guide
19. O-ring 20. Chain tensioner (for oil pump)
A. Refer to EM-177
B. Refer to EM-186
C : White paint mark (Not use for service)
PBIC3960E
1 : Camshaft (INT)
2 : Camshaft (EXH)
: Engine front
PBIC3359J
