Page 4425 of 5883
PCS
DIAGNOSIS SYSTEM (IPDM E/R)
PCS-11
< FUNCTION DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
When auto active test mode is actuated, the following 7 steps are repeated 3 times.
Concept of auto active test
Operation
sequenceInspection Location Operation
1 Rear window defogger 10 seconds
2 Front wipers LO for 5 seconds → HI for 5 seconds
3 Tail, license and parking lamps 10 seconds
3 Front fog lamps 10 seconds
4 Headlamps LO for 10 seconds → HI on-off for 5 seconds
5 A/C compressor (magnet clutch) ON ⇔ OFF 5 times
6 Cooling fan 10 seconds
WKIA5988E
WKIA5163E
Page 4426 of 5883
![NISSAN TIIDA 2007 Service Repair Manual PCS-12
< FUNCTION DIAGNOSIS >[IPDM E/R]
DIAGNOSIS SYSTEM (IPDM E/R)
IPDM E/R starts the auto active test with the door switch signals transmitted by BCM via CAN communica-
tion. Therefore, the CAN c NISSAN TIIDA 2007 Service Repair Manual PCS-12
< FUNCTION DIAGNOSIS >[IPDM E/R]
DIAGNOSIS SYSTEM (IPDM E/R)
IPDM E/R starts the auto active test with the door switch signals transmitted by BCM via CAN communica-
tion. Therefore, the CAN c](/manual-img/5/57395/w960_57395-4425.png)
PCS-12
< FUNCTION DIAGNOSIS >[IPDM E/R]
DIAGNOSIS SYSTEM (IPDM E/R)
IPDM E/R starts the auto active test with the door switch signals transmitted by BCM via CAN communica-
tion. Therefore, the CAN communication line between IPDM E/R and BCM is considered normal if the auto
active test starts successfully.
The auto active test facilitates troubleshooting if any systems controlled by IPDM E/R cannot be operated.
Diagnosis chart in auto active test mode
Symptom Inspection contents Possible cause
Oil pressure low warning indicator does not operatePerform auto active test.
Does the oil pressure low/
coolant temperature high
warning indicator operate?YES IPDM E/R signal input cir-
cuit
ECM signal input circuit
CAN communication signal
between ECM and combi-
nation meter
NO CAN communication signal
between IPDM E/R, BCM
and combination meter
Rear window defogger does not operatePerform auto active test.
Does the rear window defog-
ger operate?YES BCM signal input circuit
NO Harness or connector be-
tween A/C and AV switch
assembly and AV control
unit
CAN communication signal
between BCM and IPDM E/
R
Any of the following components do not operate
Front wipers
Tail lamps
License plate lamps
Parking lamps
Front fog lamps
Headlamps (Hi, Lo)Perform auto active test.
Does the applicable system
operate?YES BCM signal input system
NO Lamp or front wiper motor
malfunction
Lamp or front wiper motor
ground circuit
Harness or connector be-
tween IPDM E/R and appli-
cable system
IPDM E/R (integrated relay
malfunction)
A/C compressor does not operatePerform auto active test.
Does the A/C compressor op-
erate?YES BCM signal input circuit
CAN communication signal
between BCM and ECM
CAN communication signal
between ECM and IPDM E/
R
NO Magnetic clutch malfunction
Harness or connector be-
tween IPDM E/R and mag-
netic clutch
IPDM E/R (integrated relay
malfunction)
Cooling fan does not operatePerform auto active test.
Does the cooling fan operate?YES ECM signal input circuit
CAN communication signal
between ECM and IPDM E/
R
NO Cooling fan motor malfunc-
tion
Harness or connector be-
tween IPDM E/R and cool-
ing fan
IPDM E/R (integrated relay
malfunction)
Page 4427 of 5883
![NISSAN TIIDA 2007 Service Repair Manual PCS
DIAGNOSIS SYSTEM (IPDM E/R)
PCS-13
< FUNCTION DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
CONSULT - III Function (IPDM E/R)INFOID:0000000001697590
APPLICATION ITEM
CONSULT-III performs the NISSAN TIIDA 2007 Service Repair Manual PCS
DIAGNOSIS SYSTEM (IPDM E/R)
PCS-13
< FUNCTION DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
CONSULT - III Function (IPDM E/R)INFOID:0000000001697590
APPLICATION ITEM
CONSULT-III performs the](/manual-img/5/57395/w960_57395-4426.png)
PCS
DIAGNOSIS SYSTEM (IPDM E/R)
PCS-13
< FUNCTION DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
CONSULT - III Function (IPDM E/R)INFOID:0000000001697590
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with IPDM E/R.
SELF DIAGNOSTIC
Refer to PCS-28, "DTCIndex".
DATA MONITOR
Monitor item
Diagnosis mode Description
ECU Identification Allows confirmation of IPDM E/R part number.
Self Diagnostic Result Displays the diagnosis results judged by IPDM E/R.
Data Monitor Displays the real-time input/output data from IPDM E/R input/output data.
Active Test IPDM E/R can provide a drive signal to electronic components to check their operations.
CAN Diag Support Monitor The results of transmit/receive diagnosis of CAN communication can be read.
Monitor Item
[Unit]MAIN SIG-
NALSDescription
MOTOR FAN REQ
[1/2/3/4]×Displays the status of the cooling fan speed request signal received from ECM via
CAN communication.
A/C COMP REQ
[OFF/ON]×Displays the status of the A/C request signal received from AV control unit via
CAN communication.
TAIL&CLR REQ
[OFF/ON]×Displays the status of the position light request signal received from BCM via CAN
communication.
HL LO REQ
[OFF/ON]×Displays the status of the low beam request signal received from BCM via CAN
communication.
HL HI REQ
[OFF/ON]×Displays the status of the high beam request signal received from BCM via CAN
communication.
FR FOG REQ
[OFF/ON]×Displays the status of the front fog lamp request signal received from BCM via
CAN communication.
HL WASHER REQ
[OFF/ON]NOTE:
This item is displayed, but cannot be monitored.
FR WIP REQ
[STOP/1LOW/LOW/HI]×Displays the status of the front wiper request signal received from BCM via CAN
communication.
WIP AUTO STOP
[STOP P/ACT P]×Displays the status of the front wiper auto stop signal judged by IPDM E/R.
WIP PROT
[OFF/Block]×Displays the status of the front wiper fail-safe operation judged by IPDM E/R.
ST RLY REQ
[OFF/ON]Displays the status of the starter request signal received from ECM via CAN com-
munication.
IGN RLY
[OFF/ON]×Displays the status of the ignition relay judged by IPDM E/R.
RR DEF REQ
[OFF/ON]×Displays the status of the rear defogger request signal received from AV control
unit via CAN communication.
OIL P SW
[OPEN/CLOSE]Displays the status of the oil pressure switch judged by IPDM E/R.
DTRL REQ
[OFF]NOTE:
This item is displayed, but cannot be monitored.
HOOD SW
[OPEN/CLOSE]NOTE:
This item is displayed, but cannot be monitored.
Page 4428 of 5883
PCS-14
< FUNCTION DIAGNOSIS >[IPDM E/R]
DIAGNOSIS SYSTEM (IPDM E/R)
ACTIVE TEST
Te s t i t e m
THFT HRN REQ
[OFF/ON]Displays the status of the theft warning horn request signal received from BCM
via CAN communication.
HORN CHIRP
[OFF/ON]Displays the status of the horn reminder signal received from BCM via CAN com-
munication. Monitor Item
[Unit]MAIN SIG-
NALSDescription
Test item Operation Description
REAR DEFOGGEROFF OFF
ON Operates rear window defogger relay.
FRONT WIPEROFF OFF
LO Operates the front wiper relay.
HI Operates the front wiper relay and front wiper high relay.
HEAD LAMP WASHER ON —
MOTOR FAN1OFF
2OFF
3 Operates the cooling fan relay.
4 Operates the cooling fan relay.
EXTERNAL LAMPSOFF OFF
TAIL Operates the tail lamp relay.
LO Operates the headlamp low relay.
HIOperates the headlamp low relay and the headlamp high relay ON/OFF at 1
second intervals.
FOG Operates the front fog lamp relay
HORN ON Operates horn relay for 20 ms.
Page 4429 of 5883
PCS
U1000 CAN COMM CIRCUIT
PCS-15
< COMPONENT DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001697591
Refer to LAN-13, "System Description".
DTC LogicINFOID:0000000001697592
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
Diagnosis ProcedureINFOID:0000000001697593
1. PERFORM SELF DIAGNOSTIC
1. Turn ignition switch ON and wait for 2 seconds or more.
2. Check “SELF-DIAG RESULTS” of IPDM E/R.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Refer to LAN-14, "CAN Communication Control Circuit".
NO >> Refer to GI-55, "
Intermittent Incident".
DTCCONSULT-III display
descriptionDTC Detection Condition Possible cause
U1000 CAN COMM CIRCUITWhen IPDM E/R cannot communicate CAN
communication signal continuously for 2
seconds or moreIn CAN communication system, any item (or items)
of the following listed below is malfunctioning.
Receiving (TCM)
Receiving (ECM)
Receiving (BCM)
Receiving (Combination meter)
Page 4430 of 5883
![NISSAN TIIDA 2007 Service Repair Manual PCS-16
< COMPONENT DIAGNOSIS >[IPDM E/R]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001697594
1. CHECK FUSES AND FUSIBLE LINK
Check that the follo NISSAN TIIDA 2007 Service Repair Manual PCS-16
< COMPONENT DIAGNOSIS >[IPDM E/R]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001697594
1. CHECK FUSES AND FUSIBLE LINK
Check that the follo](/manual-img/5/57395/w960_57395-4429.png)
PCS-16
< COMPONENT DIAGNOSIS >[IPDM E/R]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
Diagnosis ProcedureINFOID:0000000001697594
1. CHECK FUSES AND FUSIBLE LINK
Check that the following IPDM E/R fuses or fusible link are not blown.
Is the fuse blown?
YES >> Replace the blown fuse or fusible link after repairing the affected circuit.
NO >> GO TO 2
2. CHECK BATTERY POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect IPDM E/R.
3. Check voltage between IPDM E/R harness connectors and
ground.
Is the measurement value normal?
YES >> GO TO 3
NO >> Repair or replace harness.
3. CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Check continuity between IPDM E/R harness connectors and
ground.
Does continuity exist?
YES >> Inspection End.
NO >> Repair or replace harness.
Terminal No. Signal name Fusible link No.
1 Battery A, D
2 Battery C
12 Ignition switch ON or START H
Terminals Ignition switch position
(+)
(−) OFF ON START
Connector Terminal
E42 (A)1
GroundBattery
voltageBattery
voltageBattery
voltage
2Battery
voltageBattery
voltageBattery
voltage
E43 (B) 12 0VBattery
voltageBattery
voltage
AWMIA0023ZZ
IPDM E/R
GroundContinuity
Connector Terminal
E46 (A) 38
Ye s
E48 (B) 59
AWMIA0024ZZ
Page 4431 of 5883
![NISSAN TIIDA 2007 Service Repair Manual PCS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
PCS-17
< ECU DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ECU DIAGNOSIS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
R NISSAN TIIDA 2007 Service Repair Manual PCS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
PCS-17
< ECU DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ECU DIAGNOSIS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
R](/manual-img/5/57395/w960_57395-4430.png)
PCS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
PCS-17
< ECU DIAGNOSIS >[IPDM E/R]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ECU DIAGNOSIS
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE
ROOM)
Reference ValueINFOID:0000000001697595
VALUES ON THE DIAGNOSIS TOOL
Monitor Item Condition Value/Status
MOTOR FAN REQ Engine idle speedChanges depending on engine
coolant temperature, air conditioner
operation status, vehicle speed,
etc.0 - 100 %
A/C COMP REQA/C switch OFF OFF
A/C switch ON ON
TA I L & C L R R E QLighting switch OFF OFF
Lighting switch 1ST, 2ND, HI or AUTO (Light is illuminated) ON
HL LO REQLighting switch OFF OFF
Lighting switch 2ND HI or AUTO (Light is illuminated) ON
HL HI REQLighting switch OFF OFF
Lighting switch HI ON
FR FOG REQLighting switch 2ND or AUTO (Light
is illuminated)Front fog lamp switch OFF OFF
Front fog lamp switch ON
Daytime light activated ON
HL WASHER REQNOTE:
This item is displayed, but cannot be monitored.OFF
FR WIP REQ Ignition switch ONFront wiper switch OFF STOP
Front wiper switch INT 1LOW
Front wiper switch LO LOW
Front wiper switch HI HI
WIP AUTO STOP Ignition switch ONFront wiper stop position STOP P
Any position other than front wiper
stop positionACT P
WIP PROT Ignition switch ONFront wiper operates normally OFF
Front wiper stops at fail-safe opera-
tionBLOCK
ST RLY REQIgnition switch OFF or ACC OFF
Ignition switch START ON
IGN RLYIgnition switch OFF or ACC OFF
Ignition switch ON ON
RR DEF REQRear defogger switch OFF OFF
Rear defogger switch ON ON
OIL P SWIgnition switch OFF, ACC or engine running OPEN
Ignition switch ON CLOSE
DTRL REQNOTE:
This item is displayed, but cannot be monitored.OFF
HOOD SWNOTE:
This item is displayed, but cannot be monitored.OFF
Page 4432 of 5883
PCS-18
< ECU DIAGNOSIS >[IPDM E/R]
IPDM E/R (INTELLIGENT POWER DISTRIBUTION MODULE ENGINE ROOM)
THFT HRN REQNot operated OFF
Panic alarm is activated
Horn is activated with VEHICLE SECURITY (THEFT WARNING) SYS-
TEMON
HORN CHIRPNot operated OFF
Door locking with keyfob or Intelligent Key (if equipped) (horn chirp mode) ON Monitor Item Condition Value/Status
