Page 2457 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1108
< COMPONENT DIAGNOSIS >[K9K]
POWER SUPPLY AND GROUND CIRCUIT
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 11.
11

Page 2458 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0001 FUEL PUMP
EC-1109
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0001 FUEL PUMP
DTC LogicINFOID:0000000001162549
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic

P0001 FUEL PUMP
EC-1109
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0001 FUEL PUMP
DTC LogicINFOID:0000000001162549
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC becomes present after the engine is started.
If the DTC is present:
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162550
1.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE) POWER SUPPLY
1. Turn ignition switch OFF.
2. Disconnect high pressure supply pump (volumetric control valve) harness connector.
3. Turn ignition switch ON.
4. Check the voltage between high pressure supply pump (volumetric control valve) harness connector and
ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between ECM and high pressure supply pump (volumetric control valve)
Harness for open or short between IPDM E/R and high pressure supply pump (volumetric control valve)
>> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE) OUTPUT SIGNAL CIR-
CUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between high pressure supply pump (volumetric control valve) harness connector
and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
DTC No. Trouble diagnosis name Possible cause
P0001HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
CIRCUIT
CO: Open circuit
CO.0: Short circuit to ground
CC.1: Short circuit to +12V
1.DEF: Parameter at maximum level Harness or connectors
[High pressure supply pump (volumetric
control valve) circuit is open or shorted.]
High pressure supply pump (volumetric
control valve)
Fuel line
High pressure supply pump
(volumetric control valve)
Ground Voltage
Connector Terminal
F54 1 Ground Battery voltage
High pressure supply pump
(volumetric control valve)ECM
Continuity
Connector Terminal Connector Terminal
F54 2 F11 50 Existed

Page 2459 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1110
< COMPONENT DIAGNOSIS >[K9K]
P0001 FUEL PUMP
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMET

Page 2460 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0002 FUEL PUMP
EC-1111
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0002 FUEL PUMP
DTC LogicINFOID:0000000001162552
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic

P0002 FUEL PUMP
EC-1111
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0002 FUEL PUMP
DTC LogicINFOID:0000000001162552
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present when after the engine is started or following a load test.
Diagnosis ProcedureINFOID:0000000001162553
1.CHECK LOW PRESSURE FUEL SUPPLY SYSTEM
Refer to EC-1043, "
BASIC INSPECTION : Special Repair Requirement (TEST 1: Low Pressure Fuel Supply
System Check)".
Is the inspection result normal?
OK >> GO TO 2.
NG >> Replace or replace. Then GO TO 9.
2.CHECK INTERNAL FUEL TRANSFER PUMP
Refer to EC-1044, "
BASIC INSPECTION : Special Repair Requirement (TEST 2: Internal Fuel Transfer Pump
Check)".
Is the inspection result normal?
OK >> GO TO 3.
NG >> Replace or replace. Then GO TO 9.
3.CHECK HIGH PRESSURE SUPPLY PUMP (PRESSURE CONTROL VALVE)
Refer to EC-1044, "
BASIC INSPECTION : Special Repair Requirement [TEST 3: High Pressure Supply Pump
(Pressure Control Valve) Check]".
Is the inspection result normal?
OK >> GO TO 4.
NG >> Replace or replace. Then GO TO 9.
4.CHECK HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
Refer to EC-1045, "
BASIC INSPECTION : Special Repair Requirement [TEST 4: High Pressure Supply Pump
(Volumetric Control Valve) Check]".
Is the inspection result normal?
OK >> GO TO 5.
NG >> Replace or replace. Then GO TO 9.
5.CHECK RAIL HIGH PRESSURE REGULATION
Refer to EC-1048, "
BASIC INSPECTION : Special Repair Requirement (TEST 5: Rail High Pressure Regula-
tion Check)".
Is the inspection result normal?
OK >> GO TO 6.
NG >> Replace or replace. Then GO TO 9.
6.CHECK MAJOR LEAK IN FUEL INJECTORS/FUEL INJECTORS OPEN
DTC No. Trouble diagnosis name Possible cause
P0002HIGH PRESSURE SUPPLY PUMP (VOLUMETRIC CONTROL VALVE)
ADAPTIVE
1.DEF: Parameter at maximum stop
2.DEF: Parameter at maximum level Harness or connectors
[High pressure supply pump (volumetric
control valve) circuit is open or shorted.]
(Fuel rail pressure sensor circuit is open or
shorted.)
High pressure supply pump (volumetric
control valve)
Fuel rail pressure sensor

Page 2461 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1112
< COMPONENT DIAGNOSIS >[K9K]
P0002 FUEL PUMP
Refer to EC-1052, "BASIC INSPECTION : Special Repair Requirement (TEST 6: Major Leak in Fuel Injectors/
Fuel Injectors Open)".
Is the inspection re

Page 2462 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0016 CKP - CMP CORRELATION
EC-1113
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0016 CKP - CMP CORRELATION
DTC LogicINFOID:0000000001162555
DTC DETECTION LOGIC
NOTE:
Conditions for

Page 2463 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1114
< COMPONENT DIAGNOSIS >[K9K]
P0016 CKP - CMP CORRELATION
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circu

Page 2464 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0016 CKP - CMP CORRELATION
EC-1115
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >>INSPECTION END
NO >> Replace CMP sensor.
+–
Condition Voltage
