Page 1769 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-420 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] AIR CONDITIONING CUT CONTROL 1. ECM harness connectors 2. ECM 3. IPDM E/R 4. Fuel pump fuse (15A) 5. Intake valve timing control solenoid valv

Page 1770 of 5883

NISSAN TIIDA 2007 Service Repair Manual AIR CONDITIONING CUT CONTROL EC-421 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O 1. Exhaust manifold 2. Heated oxygen sensor 1 3. Heated oxygen sensor 2 4. Heated

Page 1771 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-422 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] AIR CONDITIONING CUT CONTROL 1. Cooling fan motor harness connec- tor2. Crankshaft position sensor 3. Stop lamp switch 4. Brake pedal 5. Accele

Page 1772 of 5883

NISSAN TIIDA 2007 Service Repair Manual AIR CONDITIONING CUT CONTROL EC-423 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O Component DescriptionINFOID:0000000001693474 1. ASCD steering switch 2. MAIN switc

Page 1773 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-424 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] AUTOMATIC SPEED CONTROL DEVICE (ASCD) AUTOMATIC SPEED CONTROL DEVICE (ASCD) System DiagramINFOID:0000000001693475 System DescriptionINFOID:0000

Page 1774 of 5883

NISSAN TIIDA 2007 Service Repair Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD) EC-425 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O When any of following conditions exist, cruise operation will be canceled

Page 1775 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-426 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] AUTOMATIC SPEED CONTROL DEVICE (ASCD) Component Parts Location INFOID:0000000001693477 1. Ignition coil (with power transistor) and spark plug

Page 1776 of 5883

NISSAN TIIDA 2007 Service Repair Manual AUTOMATIC SPEED CONTROL DEVICE (ASCD) EC-427 < FUNCTION DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)] C D E F G H I J K L MA EC N P O 1. Mass air flow sensor (with intake air temperature sensor)2. Engine coo
