Page 5865 of 5883
HEADLAMP WASHER NOZZLE AND TUBE
WW-63
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
2. Remove headlamp washer tube from headlamp washer nozzle
assembly (2).
3. Detach headlamp washer nozzle cover pawl (A), and remove
headlamp washer nozzle cover (1).
4. Push pawl, and remove headlamp washer nozzle assembly (2)
from the front bumper fascia.
:Front
INSTALLATION
Installation is in the reverse order of removal.
InspectionINFOID:0000000001366651
HEADLAMP WASHER NOZZLE SPRAY POSITION INSPECTION
Check that the headlamp washer injection is centered on the headlamp (LO) illuminating area. If the injection
is out of the area, check the headlamp washer tube and headlamp washer nozzle for leaks or damage.
ALLIA0267ZZ
JPLIA0295ZZ
Page 5866 of 5883
WW-64
< ON-VEHICLE REPAIR >
WASHER TANK
WASHER TANK
Removal and InstallationINFOID:0000000001366653
REMOVAL
1. Remove the upper radiator cover. Refer to EXT-19, "Removal and Installation".
2. Remove the clip (A), then pull the washer tank inlet (1) out of the
washer tank.
:Front
3. Remove the front bumper fascia. Refer to EXT-13, "
Removal and Installation".
4. Disconnect the washer pump connector (1).
5. Disconnect the washer tube (2) from the washer pump.
6. Disconnect the headlamp washer pump connector (3).
7. Remove the washer tank bolts (A).
8. Remove the washer tank (4).
INSTALLATION
Installation is in the reverse order of removal.
Add the specified washer fluid up to the top of the washer tank inlet after installation. Check that there are no
leaks.
SKIB5667E
ALLIA0275ZZ
Page 5867 of 5883
WASHER PUMP
WW-65
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
WASHER PUMP
Removal and InstallationINFOID:0000000001366655
REMOVAL
1. Remove the front bumper fascia. Refer to EXT-13, "Removal and Installation".
2. Disconnect the washer pump connector (A).
3. Disconnect the washer tube (2) from the washer pump.
4. Remove the washer pump (1) from the washer tank.
INSTALLATION
Installation is in the reverse order of removal.
Add the specified washer fluid up to the top of the washer tank inlet after installation. Check that there are no
leaks.
CAUTION:
Never twist the grommet when installing the washer pump.
ALLIA0276ZZ
Page 5868 of 5883
WW-66
< ON-VEHICLE REPAIR >
HEADLAMP WASHER PUMP
HEADLAMP WASHER PUMP
Removal and InstallationINFOID:0000000001366657
REMOVAL
1. Remove the front bumper fascia. Refer to EXT-13, "Removal and Installation".
2. Disconnect the headlamp washer pump connector (A).
3. Disconnect the headlamp washer pump hose (2) from the head-
lamp washer pump.
4. Remove the headlamp washer pump (1).
INSTALLATION
Installation is in the reverse order of removal.
Add the specified washer fluid up to the top of the washer tank inlet after installation. Check that there are no
leaks.
CAUTION:
Never twist the grommet when installing the washer pump.
ALLIA0277ZZ
Page 5869 of 5883

FRONT WASHER NOZZLE AND TUBE
WW-67
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
FRONT WASHER NOZZLE AND TUBE
Washer Tube LayoutINFOID:0000000001396458
Removal and InstallationINFOID:0000000001404271
REMOVAL
1. Remove the cowl top cover. Refer to EXT-20, "Removal and Installation" .
2. Disconnect the washer tube from the front washer nozzle.
3. While pressing pawl (A) on the reverse side of front washer noz-
zle (1), remove front washer nozzle (1) from cowl top cover.
INSTALLATION
1. Attach the washer tube to the front washer nozzle.
2. Install the front washer nozzle in the cowl top cover.
3. Install the cowl top cover. Refer to EXT-20, "
Removal and Installation" .
4. Adjust the front washer nozzle spray pattern. Refer to WW-68, "
Adjustment" .
CAUTION:
The spray points are different from side to side, so install the left and right front washer nozzles in
the correct positions.
InspectionINFOID:0000000001404272
CHECK VALVE INSPECTION
1. Front washer nozzle (LH) 2. Front washer nozzle (RH) 3. Joint washer tube
4. Washer tube 5. Clip 6. Clamp
7. Washer tank
SKIB5664E
LKIA0939E
Page 5870 of 5883
WW-68
< ON-VEHICLE REPAIR >
FRONT WASHER NOZZLE AND TUBE
Blow air in the injection direction, and make sure that air flows only
one way. Make sure that the reverse direction is not possible.
AdjustmentINFOID:0000000001404273
Adjust spray positions to match the positions as shown.
Insert a suitable tool into the nozzle hole and move up/down and left/right to adjust to the specified spray
position.
SKIB5665E
1. Windshield A. 395 mm (15.55 in) B. 216 mm (8.50 in)
C. 100 mm (3.94 in) D. 85 mm (3.35 in) E. Black mask
F. 303 mm (11.93 in) G. 212 mm (8.35 in) H. 249 mm (9.80 in)
I. Center of windsheild J. Spray pattern area K. 286 mm (11.26 in)
LKIA0938E
Page 5871 of 5883
FRONT WIPER ARM
WW-69
< ON-VEHICLE REPAIR >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
FRONT WIPER ARM
Exploded ViewINFOID:0000000001366661
LHD Models
LKIA0786E
1. Front RH wiper blade 2. Front RH wiper arm 3. Wiper arm cap
4. Front wiper drive assembly 5. Front LH wiper arm 6. Wiper arm cap
7. Front LH wiper blade
Page 5872 of 5883
WW-70
< ON-VEHICLE REPAIR >
FRONT WIPER ARM
RHD Models
Removal and InstallationINFOID:0000000001449632
REMOVAL
1. Operate the front wiper to move it to the auto stop position.
2. Open the hood.
3. Remove the front wiper arm caps.
4. Remove the front wiper arm nuts.
5. Raise the front wiper arms, and remove the front wiper arms.
INSTALLATION
1. Clean up the pivot area as shown. This will reduce possibility of
wiper arm looseness.
2. Prior to wiper arm installation, turn on wiper switch to operate
wiper motor and then turn it off (auto stop).
3. Push wiper arm onto pivot shaft, make sure it is correctly
meshed and fully seated on the spline.
ALLIA0278ZZ
1. Wiper arm cap 2. Front RH wiper arm 3. Wiper arm cap
4. Front LH wiper arm 5. Front wiper drive assembly 6. Front LH wiper blade
7. Front RH wiper blade Front
SEL024J
