DLK-492
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
U1000 CAN COMM CIRCUIT
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001397024
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control unit, and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less
wiring. Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart, refer to XX-XX, "*****"
.
DTC LogicINFOID:0000000001397025
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000001397026
1.PERFORM SELF DIAGNOSTIC
1. Turn ignition switch ON and wait for 2 seconds or more.
2. Check “Self Diagnostic Result”.
Is
“CAN COMM CIRCUIT” displayed?
YES >> Refer to XX-XX, "*****".
NO >> Refer to XX-XX, "*****"
.
DTCCONSULT-III display
descriptionDTC Detection Condition Possible cause
U1000 CAN COMM CIRCUITWhen Intelligent Key unit cannot communi-
cate CAN communication signal continuous-
ly for 2 seconds or more.In CAN communication system, any item (or items)
of the following listed below is malfunctioning.
Transmission
Receiving (BCM)
Receiving (ECM)
Receiving (METER/M&A)
Page 1082 of 5883
![NISSAN TIIDA 2007 Service Repair Manual U1010 CONTROL UNIT (CAN)
DLK-493
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000001397027
CAN (Controller Area N NISSAN TIIDA 2007 Service Repair Manual U1010 CONTROL UNIT (CAN)
DLK-493
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000001397027
CAN (Controller Area N](/manual-img/5/57395/w960_57395-1081.png)
U1010 CONTROL UNIT (CAN)
DLK-493
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
U1010 CONTROL UNIT (CAN)
DescriptionINFOID:0000000001397027
CAN (Controller Area Network) is a serial communication line for real time applications. It is an on-vehicle mul-
tiplex communication line with high data communication speed and excellent error detection ability. Modern
vehicle is equipped with many electronic control unit, and each control unit shares information and links with
other control units during operation (not independent). In CAN communication, control units are connected
with 2 communication lines (CAN-H line, CAN-L line) allowing a high rate of information transmission with less
wiring. Each control unit transmits/receives data but selectively reads required data only.
CAN Communication Signal Chart, refer to XX-XX, "*****"
.
DTC LogicINFOID:0000000001397028
DTC DETECTION LOGIC
Diagnosis ProcedureINFOID:0000000001397029
1.REPLACE BCM
When DTC [U1010] is detected, replace BCM.
>> Replace BCM. Refer to BCS-57, "
Removal and Installation of BCM".
Special Repair RequirementINFOID:0000000001397030
1.REQUIRED WORK WHEN REPLACING INTELLIGENT KEY UNIT
Configure BCM. Refer to CONSULT-III operation manual.
>> Work end.
DTCCONSULT-III display de-
scriptionDTC Detection Condition Possible cause
U1010 CONTROL UNIT (CAN)When detecting error during the initial diagnosis of CAN control-
ler of BCMBCM
Page 1083 of 5883
DLK-494
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
POWER SUPPLY AND GROUND CIRCUIT
POWER SUPPLY AND GROUND CIRCUIT
BCM
BCM : Diagnosis ProcedureINFOID:0000000001530617
Refer to BCS-30, "Diagnosis Procedure".
Page 1084 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK AND UNLOCK SWITCH
DLK-495
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR LOCK AND UNLOCK SWITCH
DescriptionINFOID:0000000001530618
Transmits door l NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK AND UNLOCK SWITCH
DLK-495
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR LOCK AND UNLOCK SWITCH
DescriptionINFOID:0000000001530618
Transmits door l](/manual-img/5/57395/w960_57395-1083.png)
DOOR LOCK AND UNLOCK SWITCH
DLK-495
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR LOCK AND UNLOCK SWITCH
DescriptionINFOID:0000000001530618
Transmits door lock/unlock operation to BCM.
Component Function CheckINFOID:0000000001530619
1.CHECK FUNCTION
With CONSULT-III
Check “CDL LOCK SW ”and “CDL UNLOCK SW” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door lock and unlock switch is OK.
NO >> Refer to DLK-495, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530620
1.CHECK DOOR LOCK AND UNLOCK INPUT SIGNAL
1. Turn ignition switch OFF.
2. Disconnect door lock and unlock switch connector.
3. Using an oscilloscope, check voltage between door lock and
unlock switch harness connector (A) D7 terminal 6, connector
(B) D8 terminal 18 and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
Monitor item Condition
CDL LOCK SW LOCK : ON
UNLOCK : OFF
CDL UNLOCK SW LOCK : OFF
UNLOCK : ON
ALKIA0737ZZ
Te r m i n a l
Signal
(Reference value) (+)
(–)
Door lock and unlock switch
connectorTe r m i n a l
D7 6
Ground
D8 18
JPMIA0154GB
Page 1085 of 5883
![NISSAN TIIDA 2007 Service Repair Manual DLK-496
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check c NISSAN TIIDA 2007 Service Repair Manual DLK-496
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check c](/manual-img/5/57395/w960_57395-1084.png)
DLK-496
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
2.CHECK DOOR LOCK AND UNLOCK SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BCM connector.
3. Check continuity between BCM connector (A) M18 terminals 6,
25 and door lock and unlock switch connector (B) D7 terminal 6,
connector (C) D8 terminal 18.
4. Check continuity between BCM connector (A) M18 terminals 6, 25 and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace harness.
3.CHECK DOOR LOCK AND UNLOCK SWITCH GROUND
Check continuity between main power window and door lock/unlock
switch connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair or replace harness.
4.CHECK BCM OUTPUT SIGNAL
1. Connect BCM connector.
ALKIA0738ZZ
BCM connector TerminalDoor lock and unlock
switch connectorTerminal Continuity
M186D8 18
Ye s
25 D7 6
BCM connector Terminal
GroundContinuity
M186
No
25
LIIA0392E
Main power window and door lock/unlock
switch connectorTe r m i n a l
GroundContinuity
D8 17 Yes
Page 1086 of 5883
DOOR LOCK AND UNLOCK SWITCH
DLK-497
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check signal between BCM connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 6.
5.CHECK DOOR LOCK AND UNLOCK SWITCH
Check door lock and unlock switch
Refer to DLK-497, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace door lock and unlock switch. Refer to XX-XX, "*****"
.
6.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
Component InspectionINFOID:0000000001530621
1.CHECK DOOR LOCK AND UNLOCK SWITCH
Check continuity between main power window and door lock/unlock
switch terminals.
ALKIA0739ZZ
Te r m i n a l
Signal
(Reference value) (+)
(–)
BCM connector Terminal
M186
Ground
25
JPMIA0154GB
ALKIA0740ZZ
Page 1087 of 5883
DLK-498
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
DOOR LOCK AND UNLOCK SWITCH
Is the inspection result normal?
YES >> Main power window and door lock/unlock switch is OK.
NO >> Replace main power window and door lock/unlock switch. Refer to XX-XX, "*****"
.
Door lock and unlock switch Terminals Condition Continuity
D7, D86
17UNLOCK Yes
NEUTRAL/LOCK No
18LOCK Yes
NEUTRAL/UNLOCK No
Page 1088 of 5883
DOOR SWITCH
DLK-499
< COMPONENT DIAGNOSIS >[WITHOUT I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
DOOR SWITCH
DRIVER SIDE
DRIVER SIDE : DescriptionINFOID:0000000001530622
Detects door open/closed condition.
DRIVER SIDE : Component Function CheckINFOID:0000000001530623
1.CHECK FUNCTION
With CONSULT-III
Check door switches “DOOR SW-DR” in “Data Monitor” mode with CONSULT-III.
Is the inspection result normal?
YES >> Door switch is OK.
NO >> Refer to DLK-499, "
DRIVER SIDE : Diagnosis Procedure".
DRIVER SIDE : Diagnosis ProcedureINFOID:0000000001530624
1.CHECK DOOR SWITCH INPUT SIGNAL
1. Turn ignition switch OFF.
2. Check signal between BCM connector and ground with oscillo-
scope.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 2.
2.CHECK DOOR SWITCH CIRCUIT
Monitor item Condition
DOOR SW-DR OPEN :ON
CLOSE :OFF
ALKIA0745ZZ
Te r m i n a l s
Door conditionVoltage (V)
(Approx.) (+)
(–)
BCM
connectorTe r m i n a l
M18 29 GroundOPEN 0
CLOSE
JPMIA0011GB
