![NISSAN TIIDA 2007 Service Repair Manual EC-284
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P1805 BRAKE SWITCH
Harness connectors M69, E7 (LHD models)
Harness connectors M201, M25 (RHD models)
Harness for open or short between stop NISSAN TIIDA 2007 Service Repair Manual EC-284
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P1805 BRAKE SWITCH
Harness connectors M69, E7 (LHD models)
Harness connectors M201, M25 (RHD models)
Harness for open or short between stop](/manual-img/5/57395/w960_57395-1632.png)
EC-284
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P1805 BRAKE SWITCH
Harness connectors M69, E7 (LHD models)
Harness connectors M201, M25 (RHD models)
Harness for open or short between stop lamp switch and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK STOP LAMP SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect ECM harness connector.
2. Check the continuity between ECM harness connector and stop lamp switch harness connector.
3. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NG >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors M201, M25, M69, E7 (RHD models)
Harness for open or short between ECM and stop lamp switch
>> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK STOP LAMP SWITCH
Refer to EC-284, "
Component Inspection (Stop Lamp Switch)".
Is the inspection result normal?
YES >> GO TO 7.
NO >> Replace stop lamp switch.
7.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component Inspection (Stop Lamp Switch)INFOID:0000000001671062
1.CHECK STOP LAMP SWITCH-I
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Check the continuity between stop lamp switch terminals under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.CHECK STOP LAMP SWITCH-II
1. Adjust stop lamp switch installation. Refer to BR-6, "
Inspection and Adjustment".
2. Check the continuity between stop lamp switch terminals under the following conditions.
ECM Stop lamp switch
Continuity
Connector Terminal Connector Terminal
E16 99E13 (LHD models)
M203 (RHD models)2Existed
Terminals Condition Continuity
1 and 2 Brake pedalFully released Not existed
Slightly depressed Existed
Page 1634 of 5883
P1805 BRAKE SWITCH
EC-285
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace stop lamp switch.
Terminals Condition Continuity
1 and 2 Brake pedalFully released Not existed
Slightly depressed Existed
Page 1635 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-286
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2122, P2123 APP SENSOR
P2122, P2123 APP SENSOR
DescriptionINFOID:0000000001671063
The accelerator pedal position sensor is installed on the uppe NISSAN TIIDA 2007 Service Repair Manual EC-286
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2122, P2123 APP SENSOR
P2122, P2123 APP SENSOR
DescriptionINFOID:0000000001671063
The accelerator pedal position sensor is installed on the uppe](/manual-img/5/57395/w960_57395-1634.png)
EC-286
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2122, P2123 APP SENSOR
P2122, P2123 APP SENSOR
DescriptionINFOID:0000000001671063
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The ECM uses this signal for the engine oper-
ation such as fuel cut.
DTC LogicINFOID:0000000001671064
DTC DETECTION LOGIC
NOTE:
If DTC P2122 or P2123 is displayed with DTC P1229, first perform the trouble diagnosis for DTC P1229.
Refer to EC-265, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-286, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001671065
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
PBIB1741E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2122Accelerator pedal posi-
tion sensor 1 circuit low
inputAn excessively low voltage from the APP sen-
sor 1 is sent to ECM. Harness or connectors
(APP sensor 1 circuit is open or shorted.)
Accelerator pedal position sensor
(APP sensor 1)
P2123Accelerator pedal posi-
tion sensor 1 circuit high
inputAn excessively high voltage from the APP sen-
sor 1 is sent to ECM.
Page 1636 of 5883
![NISSAN TIIDA 2007 Service Repair Manual P2122, P2123 APP SENSOR
EC-287
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. D NISSAN TIIDA 2007 Service Repair Manual P2122, P2123 APP SENSOR
EC-287
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. D](/manual-img/5/57395/w960_57395-1635.png)
P2122, P2123 APP SENSOR
EC-287
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONGN PART
Check the following.
Harness or connectors E7, M69, M25, M201 (RHD models).
Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK APP SENSOR 1 GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sensor harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.DETECT MALFUNCTIONGN PART
Check the following.
Harness or connectors E7, M69, M25, M201 (RHD models).
Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK APP SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between APP sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
APP sensor
Ground Voltage
Connector Terminal
E12 (LHD models)
M204 (RHD models)4 Ground Approx. 5V
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)2 E 1 6 111 E x i s t e d
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)3 E16 110 Existed
Page 1637 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-288
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2122, P2123 APP SENSOR
7.DETECT MALFUNCTIONGN PART
Check the following.
Harness or connectors E7, M69, M25, M201 (RHD models).
Harness for o NISSAN TIIDA 2007 Service Repair Manual EC-288
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2122, P2123 APP SENSOR
7.DETECT MALFUNCTIONGN PART
Check the following.
Harness or connectors E7, M69, M25, M201 (RHD models).
Harness for o](/manual-img/5/57395/w960_57395-1636.png)
EC-288
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2122, P2123 APP SENSOR
7.DETECT MALFUNCTIONGN PART
Check the following.
Harness or connectors E7, M69, M25, M201 (RHD models).
Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
8.CHECK APP SENSOR
Refer to EC-288, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-288, "
Special Repair Requirement".
>> INSPECTION END
10.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001671066
1.CHECK ACCELERATOR PEDAL POSITION SENSOR
1. Reconnect all harness connectors disconnected.
2. Turn ignition switch ON.
3. Check the voltage between ECM harness connector terminals as follows.
Is the inspection result normal?
YES >> INSPECTION END
NO >> GO TO 2.
2.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-288, "
Special Repair Requirement".
>> INSPECTION END
Special Repair RequirementINFOID:0000000001671067
1.PERFORM ACCELERATOR PEDAL RELEASED POSITION LEARNING
Refer to EC-26, "
ACCELERATOR PEDAL RELEASED POSITION LEARNING : Special Repair Requirement".
>> GO TO 2.
(+) (–)
Condition Voltage
Connector Terminal Connector Terminal
E1611 0
(APP sensor 1 signal)
E16111
Accelerator pedalFully released 0.6 - 0.9V
Fully depressed 3.9 - 4.7V
103
(APP sensor 2 signal)104Fully released 0.3 - 0.6V
Fully depressed 1.95 - 2.4V
Page 1638 of 5883
P2122, P2123 APP SENSOR
EC-289
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-27, "
THROTTLE VALVE CLOSED POSITION LEARNING : Special Repair Requirement".
>> GO TO 3.
3.PERFORM IDLE AIR VOLUME LEARNING
Refer to EC-27, "
IDLE AIR VOLUME LEARNING : Special Repair Requirement".
>> END
Page 1639 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-290
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2127, P2128 APP SENSOR
P2127, P2128 APP SENSOR
DescriptionINFOID:0000000001671068
The accelerator pedal position sensor is installed on the uppe NISSAN TIIDA 2007 Service Repair Manual EC-290
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2127, P2128 APP SENSOR
P2127, P2128 APP SENSOR
DescriptionINFOID:0000000001671068
The accelerator pedal position sensor is installed on the uppe](/manual-img/5/57395/w960_57395-1638.png)
EC-290
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
P2127, P2128 APP SENSOR
P2127, P2128 APP SENSOR
DescriptionINFOID:0000000001671068
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The ECM uses this signal for the engine oper-
ation such as fuel cut.
DTC LogicINFOID:0000000001671069
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-290, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001671070
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
PBIB1741E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2127Accelerator pedal posi-
tion sensor 2 circuit low
inputAn excessively low voltage from the APP sen-
sor 2 is sent to ECM. Harness or connectors
(APP sensor 2 circuit is open or shorted.)
[Crankshaft position sensor (POS) circuit
is shorted.]
(Refrigerant pressure sensor circuit is
shorted.)
Accelerator pedal position sensor
(APP sensor 2)
Crankshaft position sensor (POS)
Refrigerant pressure sensor P2128Accelerator pedal posi-
tion sensor 2 circuit high
inputAn excessively high voltage from the APP sen-
sor 2 is sent to ECM.
Page 1640 of 5883
![NISSAN TIIDA 2007 Service Repair Manual P2127, P2128 APP SENSOR
EC-291
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-I
1. NISSAN TIIDA 2007 Service Repair Manual P2127, P2128 APP SENSOR
EC-291
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-I
1.](/manual-img/5/57395/w960_57395-1639.png)
P2127, P2128 APP SENSOR
EC-291
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-I
1. Disconnect accelerator pedal position (APP) sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between APP sensor harness connector and ground.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 3.
3.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-II
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between APP sensor harness connector and ECM harness connector.
Is the inspection result normal?
YES >> GO TO 5.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Harness or connectors E7, M69, M25, M201 (RHD models).
Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-III
Check harness for short to power and short to ground, between the following terminals.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.DETECT MALFUNCTIONING PART
Check the following.
Harness or connectors E7, M69, M25, M201 (RHD models).
Harness for open or short between ECM and APP sensor.
>> Repair open circuit or short to ground or short to power in harness or connectors.
APP sensor
Ground Voltage
Connector Terminal
E12 (LHD models)
M204 (RHD)5 Ground Approx. 5V
APP sensor ECM
Continuity
Connector Terminal Connector Terminal
E12 (LHD models)
M204 (RHD models)5 E16 102 Existed
ECM Sensor
Connector Terminal Item Connector Terminal
F1174 Refrigerant pressure sensor E17 3
75 CKP sensor (POS) F15 1
E16 102 APP sensorE12 (LHD models)
M204 (RHD models)5
