a. Place differential case in the upright position so that the side
gear to be mea NISSAN TIIDA 2007 Service Repair Manual REPAIR FOR COMPONENT PARTS
TM-295
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
a. Place differential case in the upright position so that the side
gear to be mea](/manual-img/5/57395/w960_57395-5240.png)
REPAIR FOR COMPONENT PARTS
TM-295
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
a. Place differential case in the upright position so that the side
gear to be measured is at the top.
(A): Location for inserting feeler gauge
(B): Side gear tooth
(C): The center line of differential case
b. In order to maximize the back clearance, rotate side gears so
that a tooth on side gears at the top and bottom will align at the
same position as shown.
c. Adjust the back clearance of side gear according to the following
procedures.
i. Insert feeler gauges (A) of the same thickness to the back of
side gear from both sides, preventing side gear from falling, to
measure the clearance.
Measure clearance 3 times by rotating side gears and take the
average.
CAUTION:
In all 3 measurements, maximize the clearance by aligning
teeth on side gears at the top and bottom at the same posi-
tion.
ii. Select side gear thrust washer so that the clearance will fall
within the standard.
iii. Turn differential case upside down, and measure the back clear-
ance of the other side gear in the same manner.
NOTE:
Adjust the clearance to approx. 0.1 mm (0.004 in) for used differ-
ential [driven approx. 3,000 km (1864 mile) or more].
3. Install lock pin (1) to pinion mate shaft using Tool (A).
CAUTION:
Make sure that lock pin (1) flush with differential case.
4. Set Tool (A) on differential side bearing (RH side) (1), and press
differential side bearing (RH side) (1) to differential case (2).
CAUTION:
Set Tool (A) on differential side bearing inner race.
SCIA7064E
Differential side gear clearance:
Refer to TM-323, "
Final Drive".
SCIA7061E
Tool number: KV32101000
SCIA7228E
Tool number: ST33200000
SCIA7062E
Page 5242 of 5883
TM-296
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
REPAIR FOR COMPONENT PARTS
5. Set Tool (A) on differential side bearing (LH side) (1), and press
differential side bearing (LH side) (1) to differential case (2).
CAUTION:
Set Tool (A) on differential side bearing inner race.
6. Install final gear on differential case, and tighten bolts to the
specified torque in the numerical order as shown.Tool number: ST33200000
SCIA7063E
SCIA0294J
Page 5243 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY
TM-297
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ASSEMBLY
Assembly (1)INFOID:0000000001730996
1. Drive transaxle case side oil seal (1) using Tools, NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY
TM-297
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ASSEMBLY
Assembly (1)INFOID:0000000001730996
1. Drive transaxle case side oil seal (1) using Tools,](/manual-img/5/57395/w960_57395-5242.png)
ASSEMBLY
TM-297
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
ASSEMBLY
Assembly (1)INFOID:0000000001730996
1. Drive transaxle case side oil seal (1) using Tools, and converter
housing side oil seal (2) using suitable tool, to the dimensions as
shown
(A): Transaxle case side
(B): Converter housing side
NOTE:
Differential side oil seal pulling direction is used as the reference.
2. Install O-ring on governor cap.
CAUTION:
Do not reuse O-ring.
Apply ATF to O-ring.
3. Install governor cap in transaxle case.
4. Install snap ring in transaxle case.
5. Install parking actuator support (1) on transaxle case.
(A): Inside
(B): Outside
CAUTION:
Be careful with the direction of parking actuator support (1).
6. Tighten parking actuator support bolts to the specified torque.
7. Install parking pawl (2) on transaxle case, and secure it with
parking shaft (1).Tool numbers : ST35325000 ( — )
: KV31103000 ( — )
Dimension "C" : 0 ±±
Dimension "D" : 1.1 ± 0.5 mm (0.043 ± 0.020 in)
SCIA7226E
SCIA5910J
SCIA6997E
Page 5244 of 5883
TM-298
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
ASSEMBLY
8. Install return spring (2) on parking shaft (3) and parking pawl (1)
using suitable tool.
Adjustment (1)INFOID:0000000001730997
REDUCTION PINION GEAR BEARING PRELOAD
1. Select proper thickness of reduction pinion gear adjusting shim using the following procedures.
a. Place reduction pinion gear on transaxle case as shown.
b. Install idler gear bearing outer race on transaxle case.
c. Place idler gear bearing inner race on outer race.
d. Measure dimensions “B”, “C” and “D”, and calculate dimension
“A”.
Measure dimension “B” between the end of reduction pinion
gear and the surface of transaxle case.
Measure dimension “B” in at least two places, and take
the average.
SCIA6996E
SCIA3623E
“A”: Distance between the surface of idler gear bear-
ing inner race and the adjusting shim mating
surface of reduction pinion gear.
A = D − (B + C)
SCIA3624E
SCIA3625E
Page 5245 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY
TM-299
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Measure dimension “C” between the surface of idler gear
bearing inner race and the surface of NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY
TM-299
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Measure dimension “C” between the surface of idler gear
bearing inner race and the surface of](/manual-img/5/57395/w960_57395-5244.png)
ASSEMBLY
TM-299
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Measure dimension “C” between the surface of idler gear
bearing inner race and the surface of transaxle case.
Measure dimension “C” in at least two places, and take
the average.
Remove reduction pinion gear from transaxle case.
Measure dimension “D” between the end of reduction pinion
gear and the adjusting shim mating surface of reduction pinion
gear.
Measure dimension “D” in at least two places, and take
the average.
Calculate dimension “A”.
e. Measure dimension “E” between the end of idler gear and idler
gear bearing inner race mating surface of idler gear.
Measure dimension “E” in at least two places, and take
the average.
f. Select proper thickness of reduction pinion gear adjusting shim.
2. Install reduction pinion gear (1) and reduction pinion gear adjust-
ing shim (2) selected in step 2-e on transaxle case.
CAUTION:
Apply ATF to reduction pinion gear bearing.
3. Press idler gear bearing inner race on idler gear (3). Refer to
TM-281, "
Output Shaft, Output Gear, Idler Gear, Reduction Pin-
ion Gear and Bearing Retainer".
4. Set Tool (A) on idler gear (3), and press idler gear (3) on reduc-
tion pinion gear (1).
CAUTION:
Apply ATF to idler gear bearing.
Press idler gear (3) until idler gear (3) fully contacts reduc-
tion pinion gear bearing adjusting shim (2).
5. Set manual shaft in “P” position to secure idler gear (3).
6. Tighten lock nut of idler gear to the specified torque.
CAUTION:
Lock idler gear with parking pawl when tightening lock nut.
SCIA3626E
A = D − (B + C)
SAT336DA
Proper shim thickness = A − E − 0.05 mm (0.0020 in)*
(*: Bearing preload)
SAT337D
Tool number: ST35271000
SCIA7110E
Page 5246 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-300
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
ASSEMBLY
7. Measure turning torque of reduction pinion gear.
When measuring turning torque, turn reduction pinion
gear in both directions se NISSAN TIIDA 2007 Service Repair Manual TM-300
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
ASSEMBLY
7. Measure turning torque of reduction pinion gear.
When measuring turning torque, turn reduction pinion
gear in both directions se](/manual-img/5/57395/w960_57395-5245.png)
TM-300
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
ASSEMBLY
7. Measure turning torque of reduction pinion gear.
When measuring turning torque, turn reduction pinion
gear in both directions several times to seat bearing roll-
ers correctly.
If turning torque is out of specification, decrease or
increase thickness of reduction pinion gear adjusting
shim.
OUTPUT SHAFT BEARING PRELOAD
1. Select proper thickness of output gear adjusting spacer using the following procedures.
a. Remove paper rolled around output shaft.
b. Install output gear bearing outer race on bearing retainer.
c. Place bearing retainer on output shaft.
d. Place output gear bearing inner race on bearing retainer.
e. Measure dimensions “G” and “H”, and calculate dimension “F”.
Measure dimension “G” between end of output shaft and sur-
face of output gear bearing inner race.
Measure dimension “G” in at least two places, and take
the average.Turning torque of reduction pinion gear:
Refer to TM-323, "
Reduction Pinion Gear".
SAT190FB
SAT682D
“F”: Distance between the surface of output gear
bearing inner race and adjusting spacer mating
surface of output shaft.
F = H − G
SAT683D
SAT684D
Page 5247 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY
TM-301
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Measure dimension “H” between end of output shaft and
adjusting spacer mating surface of outpu NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY
TM-301
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Measure dimension “H” between end of output shaft and
adjusting spacer mating surface of outpu](/manual-img/5/57395/w960_57395-5246.png)
ASSEMBLY
TM-301
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
Measure dimension “H” between end of output shaft and
adjusting spacer mating surface of output shaft.
Measure dimension “H” in at least two places, and take
the average.
Calculate dimension “F”.
f. Measure dimension “I” between end of output gear (adjusting
spacer mating surface) and output gear bearing inner race fitting
surface.
Measure dimension “I” in at least two places, and take the
average.
g. Select proper thickness of output gear adjusting spacer.
2. Install bearing retainer (1) in transaxle case.
3. Tighten bearing retainer bolts to the specified torque.
4. Install output shaft (1) and output gear adjusting spacer (2)
selected in step 1-f on transaxle case.
CAUTION:
Apply ATF to output shaft bearing.
Do not force output shaft to install or seal ring may be
damaged.
5. Press output gear bearing inner race on output gear (3).
6. Set Tool (A) on output gear (3), and press output gear (3) on out-
put shaft (1).
CAUTION:
Apply ATF to output gear bearing.
Do not pinch seal ring when output shaft is pressed in.
Press output gear (3) until output gear (3) fully contacts output gear adjusting space (2).
7. Set manual shaft in “P” position to secure idler gear.
8. Tighten lock nut of output gear to the specified torque.
CAUTION:
Do not reuse lock nut.
Lock idler gear with parking pawl when tightening lock nut.F = H − G
SAT685D
Proper spacer thickness
= F − I − [0.03 − 0.08 mm (0.0012 − 0.0031 in)]*
(*: Bearing preload)
SAT686D
SCIA5909J
Tool number: ST35271000
SCIA7080E
Page 5248 of 5883
![NISSAN TIIDA 2007 Service Repair Manual TM-302
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
ASSEMBLY
9. Remove idler gear (1) using Tool (A) to measure output shaft
bearing preload.
10. Measure turning torque of output shaft.
When m NISSAN TIIDA 2007 Service Repair Manual TM-302
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
ASSEMBLY
9. Remove idler gear (1) using Tool (A) to measure output shaft
bearing preload.
10. Measure turning torque of output shaft.
When m](/manual-img/5/57395/w960_57395-5247.png)
TM-302
< DISASSEMBLY AND ASSEMBLY >[TYPE 1 (4AT: RE4F03B)]
ASSEMBLY
9. Remove idler gear (1) using Tool (A) to measure output shaft
bearing preload.
10. Measure turning torque of output shaft.
When measuring turning torque, turn output shaft in both
directions several times to seat bearing rollers correctly.
If turning torque is out of specification, decrease or
increase thickness of output gear adjusting spacer.
11. Press idler gear on reduction pinion gear.
12. Tighten lock nut (1) of idler gear to the specified torque.
13. After properly adjusting turning torque, clinch lock nuts (1) of
idler gear and output gear as shown.
14. Install side cover gasket and side cover on transaxle case.
CAUTION:
Do not reuse side cover gasket.
Completely remove all moisture, oil and old gasket, etc.
from the transaxle case and side cover mating surfaces.
15. Tighten side cover bolts (1) to the specified torque.Tool number: ST27180001
SCIA5921J
Turning torque of output shaft:
Refer to TM-323, "
Output Shaft".
SAT190FB
L1: 3 mm (0.12 in) or more
L
2: 1 mm (0.04 in) or more
SCIA5922J
SCIA6039J
