Page 3041 of 5883
EXL-40
< COMPONENT DIAGNOSIS >
HEADLAMP (LO) CIRCUIT
NO >> Repair the harness.
Page 3042 of 5883

FRONT FOG LAMP CIRCUIT
EXL-41
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
FRONT FOG LAMP CIRCUIT
DescriptionINFOID:0000000001523265
The IPDM E/R (intelligent power distribution module engine room) controls the front fog lamp relay based on
inputs from the BCM via the CAN communication lines. When the front fog lamp relay is energized, power
flows from the front fog lamp relay to fuse 56 in the IPDM E/R and on to the front fog lamps.
Component Function CheckINFOID:0000000001523266
1.CHECK FRONT FOG LAMP OPERATION
CONSULT-III
1. Select "FR FOG LAMP" of IPDM E/R EXTERNAL LAMPS active test item.
2. With test items operating, check that the front fog lamps are turned ON.
Is the front fog lamp turned ON?
YES >> Front fog lamp circuit is normal.
NO >> Refer to EXL-41, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001523267
1.CHECK FRONT FOG LAMP FUSE
1. Turn the ignition switch OFF.
2. Check that the following fuses are not open.
Is the fuse open?
YES >> Repair the harness and replace the fuse.
NO >> GO TO 2
2.CHECK FRONT FOG LAMP OUTPUT VOLTAGE
CONSULT-III
1. Turn the ignition switch OFF.
2. Disconnect the front fog lamp connector.
3. Turn the ignition switch ON.
4. Select "FR FOG LAMP" of BCM active test item.
5. With FR FOG LAMP ON, check the voltage between the fog lamp connector and ground.
Is the measurement value normal?
YES >> GO TO 4
NO >> GO TO 3
3.CHECK FRONT FOG LAMP OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect IPDM E/R connector.
3. Check continuity between the IPDM E/R harness connector (A) and the front fog lamp harness connector
(B).ON : Front fog lamp ON
OFF : Front fog lamp OFF
Unit Location Fuse No. Capacity
Front fog lamp IPDM E/R 56 15A
(+)
(−)Voltage
Connector Terminal
LH E27
6 Ground Battery voltage
RH E28
Page 3043 of 5883
EXL-42
< COMPONENT DIAGNOSIS >
FRONT FOG LAMP CIRCUIT
Does continuity exist?
YES >> GO TO 4
NO >> Repair the harnesses or connectors.
4.CHECK FRONT FOG LAMP GROUND CIRCUIT
1. Disconnect the front fog lamp connector.
2. Check continuity between the front fog lamp harness connector terminal and ground.
Does continuity exist?
YES >> Inspect the fog lamp bulb.
NO >> Repair the harness.
AB
Continuity
Connector Terminal Connector Terminal
LH
E4750 E27
6Yes
RH 51 E28
Connector Terminal — Continuity
LH E27 7
Ground Yes
RH E28 7
Page 3044 of 5883

REAR FOG LAMP CIRCUIT
EXL-43
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
REAR FOG LAMP CIRCUIT
DescriptionINFOID:0000000001527571
The BCM (Body Control Module) controls power to the rear fog lamps based on inputs from the lighting switch
(combination switch). The BCM sends a request (via CAN communication lines) to the combination meter to
turn the rear fog lamp indicator light ON.
Component Function CheckINFOID:0000000001527572
1.CHECK REAR FOG LAMP OPERATION
CONSULT-III
1. Select "RR FOG LAMP" of BCM active test item.
2. With test items operating, check that the rear fog lamps are turned ON.
Is the rear fog lamp turned ON?
YES >> Rear fog lamp circuit is normal.
NO >> Refer to EXL-43, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001527573
HATCHBACK
1.CHECK BCM POWER AND GROUND SUPPLY
Verify BCM power and ground supply. Refer to BCS-30, "
Diagnosis Procedure".
Does BCM have proper power and ground?
YES >> GO TO 2
NO >> Repair harness or connector.
2.CHECK REAR FOG LAMP OUTPUT VOLTAGE
CONSULT-III
1. Turn the ignition switch OFF.
2. Disconnect the rear fog lamp connector B89 and rear combination lamp LH connector B80.
3. Turn the ignition switch ON.
4. Select "RR FOG LAMP" of BCM active test item.
5. With RR FOG LAMP ON, check the voltage between the rear fog lamp connector B89 terminal 1, rear
combination lamp LH connector B80 terminal 2 and ground.
Is battery voltage present?
YES >> GO TO 4
NO >> GO TO 3
3.CHECK REAR FOG LAMP OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect BCM connector M20.
3. Check continuity between the BCM harness connector M20 (A) terminal 69 and the rear fog lamp harness
connector B89 (B) terminal 1 and rear combination lamp LH connector B80 (C) terminal 2. ON : Front fog lamp ON
OFF : Front fog lamp OFF
(+)
(−)Voltage
Connector Terminal
B89 1
Ground Battery voltage
B80 2
Page 3045 of 5883

EXL-44
< COMPONENT DIAGNOSIS >
REAR FOG LAMP CIRCUIT
Does continuity exist?
YES >> GO TO 4
NO >> Repair the harnesses or connectors.
4.CHECK REAR FOG LAMP GROUND CIRCUIT
1. Disconnect the rear fog lamp connector B89 and rear combination lamp LH connector B80.
2. Check continuity between the rear fog lamp connector B89 terminal 2 and rear combination lamp LH con-
nector B80 terminal 1 and ground.
Does continuity exist?
YES >> Inspect the fog lamp bulb.
NO >> Repair the harness.
SEDAN
1.CHECK BCM POWER AND GROUND SUPPLY
Verify BCM power and ground supply. Refer to BCS-30, "
Diagnosis Procedure"
Does BCM have proper power and ground?
YES >> GO TO 2
NO >> Repair harness or connector.
2.CHECK REAR FOG LAMP OUTPUT VOLTAGE
CONSULT-III
1. Turn the ignition switch OFF.
2. Disconnect the rear fog lamp connector B89 and rear combination lamp RH connector B59.
3. Turn the ignition switch ON.
4. Select "RR FOG LAMP" of BCM active test item.
5. With RR FOG LAMP ON, check the voltage between the rear fog lamp connector B89 terminal 2, rear
combination lamp RH connector B59 terminal 2 and ground.
Is battery voltage present?
YES >> GO TO 4
NO >> GO TO 3
3.CHECK REAR FOG LAMP OPEN CIRCUIT
1. Turn the ignition switch OFF.
2. Disconnect BCM connector M20.
3. Check continuity between the BCM harness connector M20 (A) terminal 69 and the rear fog lamp harness
connector B89 (B) terminal 2 and rear combination lamp RH connector B59 (C) terminal 2.
A—
Continuity
Connector Terminal Connector Terminal
M20 69B:B89 1
Ye s
C:B80 2
Connector Terminal — Continuity
B89 2
Ground Yes
B80 1
(+)
(−) Voltage
Connector Terminal
Rear fog lamp B89 2
Ground Battery voltage
Rear combination lamp RH B59 2
A—
Continuity
Connector Terminal Connector Terminal
Page 3046 of 5883
REAR FOG LAMP CIRCUIT
EXL-45
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Does continuity exist?
YES >> GO TO 4
NO >> Repair the harnesses or connectors.
4.CHECK REAR FOG LAMP GROUND CIRCUIT
1. Disconnect the rear fog lamp connector B89 and rear combination lamp RH connector B59.
2. Check continuity between the rear fog lamp connector B89 terminal 1 and rear combination lamp LH con-
nector B59 terminal 1 and ground.
Does continuity exist?
YES >> Inspect the fog lamp bulb.
NO >> Repair the harness.
M20 69B:B89 2
Ye s
C:B59 2
Connector Terminal — Continuity
B89 1
Ground Yes
B59 1
Page 3047 of 5883

EXL-46
< COMPONENT DIAGNOSIS >
PARKING LAMP CIRCUIT
PARKING LAMP CIRCUIT
WITH DAYTIME LIGHT SYSTEM
WITH DAYTIME LIGHT SYSTEM : DescriptionINFOID:0000000001523268
The IPDM E/R (Intelligent Power Distribution Module Engine Room) controls the daytime light relay based on
inputs from the BCM via the CAN communication lines. When the daytime light relay is energized power flows
to the front and rear combination lamps and the license plate lamps.
WITH DAYTIME LIGHT SYSTEM : Component Function CheckINFOID:0000000001523269
1.CHECK PARKING LAMP OPERATION
CONSULT-III
1. Select "TAIL LAMP" of IPDM E/R active test item.
2. With test items operating, check that the parking lamps are turned ON.
Is the parking lamp turned ON?
YES >> Parking lamp circuit is normal.
NO >> Refer to EXL-46, "
WITH DAYTIME LIGHT SYSTEM : Diagnosis Procedure".
WITH DAYTIME LIGHT SYSTEM : Diagnosis ProcedureINFOID:0000000001523270
1.CHECK PARKING LAMP FUSE
1. Turn the ignition switch OFF.
2. Check that the following fuse is not open.
Is the fuse open?
YES >> Repair the harness and replace the fuse.
NO >> GO TO 2
2.CHECK DAYTIME LIGHT RELAY OUTPUT (VOLTAGE)
CONSULT-III
1. Turn the ignition switch OFF.
2. Disconnect the front or rear combination lamp connectors.
3. Turn the ignition switch ON.
4. Select "TAIL LAMP" of IPDM E/R active test item.
5. With TAIL LAMP ON, check the voltage between the front and rear combination lamps connectors and
license plate lamp connector and ground.ON : Parking lamp ON
OFF : Parking lamp OFF
Unit Location Fuse No. Capacity
Daytime light relay (parking lamps) Fuse and fusible link box 26 10A
(+)
(−)Voltage
Front combination lamp
connectorTe r m i n a l
LH E53
6 Ground Battery voltage
RH E54
WKIA5502E
Page 3048 of 5883

PARKING LAMP CIRCUIT
EXL-47
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
EXL
N
O
P
Is battery voltage present?
YES >> GO TO 4
NO >> GO TO 3
3.CHECK PARKING LAMP CIRCUIT (OPEN)
1. Turn the ignition switch OFF.
2. Disconnect daytime light relay connector E67.
3. Check continuity between the daytime light relay harness connector E67 (A) and the front combination
lamp harness connector (B).
4. Check continuity between the daytime light relay harness connector E67 (A) and the license plate lamp
harness connector (B)(hatchback) or (C)(sedan).
5. Check continuity between the daytime light relay harness connector E67 (A) and the rear combination
lamp harness connector (B).
Does continuity exist?
YES >> GO TO 4
NO >> Repair the daytime light relay, harness or connectors.
4.CHECK PARKING LAMP GROUND CIRCUIT
1. Turn ignition switch OFF.
(+)
(−)Voltage
License plate lamp connector Terminal
LHA: B87 (hatchback)
B: B62 (sedan)
1 Ground Battery voltage
RHA: B88 (hatchback)
B: B63 (sedan)
(+)
(−)Voltage
Rear combination lamp
connectorTe r m i n a l
LH B80
4 Ground Battery voltage
RH B59
P K I C 111 8 E
AB
Continuity
Connector Terminal Connector Terminal
E67 3LH E53
6Yes
RH B54
Connector Terminal Connector Terminal Continuity
A: E67 3LHB: B87 (hatchback)
C: B62 (sedan)
1Yes
RHB: B88 (hatchback)
C: B63 (sedan)
AB
Continuity
Connector Terminal Connector Terminal
E67 3LH B80
4Yes
RH B59
