Page 4097 of 5883
LAN
DLC BRANCH LINE CIRCUIT
LAN-357
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
DLC BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333797
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the data link connector for damage, bend and loose connection
(connector side and harness side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
Check the resistance between the data link connector terminals.
Is the measurement value within the specification?
YES (Present error)>>Check the CAN system type decision again.
YES (Past error)>>Error was detected in the data link connector branch line circuit.
NO >> Repair the data link connector branch line.
Data link connector
Resistance (Ω)
Connector No. Terminal No.
M22 6 14 Approx. 54 – 66
Page 4098 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LAN-358
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
EPS BRANCH LINE CIRCUIT
EPS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333798
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the igni NISSAN TIIDA 2007 Service Repair Manual LAN-358
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
EPS BRANCH LINE CIRCUIT
EPS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333798
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the igni](/manual-img/5/57395/w960_57395-4097.png)
LAN-358
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
EPS BRANCH LINE CIRCUIT
EPS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333798
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the EPS control unit for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of EPS control unit.
2. Check the resistance between the EPS control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the EPS control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the EPS control unit. Refer to STC-9, "
Diagnosis Proce-
dure".
Is the inspection result normal?
YES (Present error)>>Replace the EPS control unit. Refer to ST-9, "Removal and Installation".
YES (Past error)>>Error was detected in the EPS control unit branch line.
NO >> Repair the power supply and the ground circuit.
EPS control unit harness connector
Resistance (Ω)
Connector No. Terminal No.
M53 9 16 Approx. 54 – 66
Page 4099 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LAN
I-KEY BRANCH LINE CIRCUIT
LAN-359
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
I-KEY BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333799
INSPECTION PROCED NISSAN TIIDA 2007 Service Repair Manual LAN
I-KEY BRANCH LINE CIRCUIT
LAN-359
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
I-KEY BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333799
INSPECTION PROCED](/manual-img/5/57395/w960_57395-4098.png)
LAN
I-KEY BRANCH LINE CIRCUIT
LAN-359
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
I-KEY BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333799
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the Intelligent Key unit for damage, bend and loose connection
(unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of Intelligent Key unit.
2. Check the resistance between the Intelligent Key unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the Intelligent Key unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the Intelligent Key unit. Refer to SEC-37, "
INTELLIGENT
KEY UNIT : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the Intelligent Key unit. Refer to SEC-79, "Removal and Installation".
YES (Past error)>>Error was detected in the Intelligent Key unit branch line.
NO >> Repair the power supply and the ground circuit.
Intelligent Key unit harness connector
Resistance (Ω)
Connector No. Terminal No.
M52 2 3 Approx. 54 – 66
Page 4100 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LAN-360
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
M&A BRANCH LINE CIRCUIT
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333800
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the igni NISSAN TIIDA 2007 Service Repair Manual LAN-360
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
M&A BRANCH LINE CIRCUIT
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333800
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the igni](/manual-img/5/57395/w960_57395-4099.png)
LAN-360
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
M&A BRANCH LINE CIRCUIT
M&A BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333800
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the combination meter for damage, bend and loose connection
(unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of combination meter.
2. Check the resistance between the combination meter harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the combination meter branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the combination meter. Refer to MWI-26, "
COMBINATION
METER : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the combination meter. Refer to MWI-94, "Removal and Installation".
YES (Past error)>>Error was detected in the combination meter branch line.
NO >> Repair the power supply and the ground circuit.
Combination meter harness connector
Resistance (Ω)
Connector No. Terminal No.
M24 1 2 Approx. 54 – 66
Page 4101 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LAN
STRG BRANCH LINE CIRCUIT
LAN-361
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333801
INSPECTION PROCEDUR NISSAN TIIDA 2007 Service Repair Manual LAN
STRG BRANCH LINE CIRCUIT
LAN-361
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333801
INSPECTION PROCEDUR](/manual-img/5/57395/w960_57395-4100.png)
LAN
STRG BRANCH LINE CIRCUIT
LAN-361
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
STRG BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333801
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the steering angle sensor for damage, bend and loose connection
(unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of steering angle sensor.
2. Check the resistance between the steering angle sensor harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the steering angle sensor branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the steering angle sensor. Refer to BRC-142, "
Diagnosis
Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the steering angle sensor. Refer to BRC-186, "Removal and Installation".
YES (Past error)>>Error was detected in the steering angle sensor branch line.
NO >> Repair the power supply and the ground circuit.
Steering angle sensor harness connector
Resistance (Ω)
Connector No. Terminal No.
M80 4 8 Approx. 54 – 66
Page 4102 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LAN-362
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333802
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the igniti NISSAN TIIDA 2007 Service Repair Manual LAN-362
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333802
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the igniti](/manual-img/5/57395/w960_57395-4101.png)
LAN-362
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
AV BRANCH LINE CIRCUIT
AV BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333802
INSPECTION PROCEDURE
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the NAVI control unit for damage, bend and loose connection (unit
side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of NAVI control unit.
2. Check the resistance between the NAVI control unit harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the NAVI control unit branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the NAVI control unit. Refer to AV-80, "
NAVI CONTROL
UNIT : Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the NAVI control unit. Refer to AV-130, "Removal and Installation".
YES (Past error)>>Error was detected in the NAVI control unit branch line.
NO >> Repair the power supply and the ground circuit.
NAVI control unit harness connector
Resistance (Ω)
Connector No. Terminal No.
B68 71 72 Approx. 54 – 66
Page 4103 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LAN
ABS BRANCH LINE CIRCUIT
LAN-363
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ABS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333803
1.CHECK CONNECTOR
1. NISSAN TIIDA 2007 Service Repair Manual LAN
ABS BRANCH LINE CIRCUIT
LAN-363
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ABS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333803
1.CHECK CONNECTOR
1.](/manual-img/5/57395/w960_57395-4102.png)
LAN
ABS BRANCH LINE CIRCUIT
LAN-363
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
C
D
E
F
G
H
I
J
K
L B A
O
P N
ABS BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333803
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connectors of the ABS actuator and electric unit (control unit) for damage, bend
and loose connection (unit side and connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of ABS actuator and electric unit (control unit).
2. Check the resistance between the ABS actuator and electric unit (control unit) harness connector termi-
nals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the ABS actuator and electric unit (control unit) branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the ABS actuator and electric unit (control unit). Refer to the
following.
ABS models: BRC-36, "
Diagnosis Procedure"
ESP models: BRC-116, "Diagnosis Procedure"
Is the inspection result normal?
YES (Present error)>>Replace the ABS actuator and electric unit (control unit). Refer to the following.
ABS models: BRC-85, "
Removal and Installation"
ESP models: BRC-184, "Removal and Installation"
YES (Past error)>>Error was detected in the ABS actuator and electric unit (control unit) branch line.
NO >> Repair the power supply and the ground circuit.
ABS actuator and electric unit (control unit) harness connector
Resistance (Ω)
Connector No. Terminal No.
E33 26 15 Approx. 54 – 66
Page 4104 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LAN-364
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
TCM BRANCH LINE CIRCUIT
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333804
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. D NISSAN TIIDA 2007 Service Repair Manual LAN-364
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
TCM BRANCH LINE CIRCUIT
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333804
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. D](/manual-img/5/57395/w960_57395-4103.png)
LAN-364
< COMPONENT DIAGNOSIS >[CAN SYSTEM (TYPE 24)]
TCM BRANCH LINE CIRCUIT
TCM BRANCH LINE CIRCUIT
Diagnosis ProcedureINFOID:0000000001333804
1.CHECK CONNECTOR
1. Turn the ignition switch OFF.
2. Disconnect the battery cable from the negative terminal.
3. Check the terminals and connector of the TCM for damage, bend and loose connection (unit side and
connector side).
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair the terminal and connector.
2.CHECK HARNESS FOR OPEN CIRCUIT
1. Disconnect the connector of TCM.
2. Check the resistance between the TCM harness connector terminals.
Is the measurement value within the specification?
YES >> GO TO 3.
NO >> Repair the TCM branch line.
3.CHECK POWER SUPPLY AND GROUND CIRCUIT
Check the power supply and the ground circuit of the TCM. Refer to TM-109, "
Diagnosis Procedure".
Is the inspection result normal?
YES (Present error)>>Replace the TCM. Refer to XXX.
YES (Past error)>>Error was detected in the TCM branch line.
NO >> Repair the power supply and the ground circuit.
TCM harness connector
Resistance (Ω)
Connector No. Terminal No.
E31 5 6 Approx. 54 – 66
