Page 713 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-124 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] INSIDE KEY ANTENNA With CONSULT-III 1. Check “ANTENNA” in “Active Test” mode with CONSULT-III. 2. Touch “ROOM ANT 1”. 3. Wh

Page 714 of 5883

NISSAN TIIDA 2007 Service Repair Manual INSIDE KEY ANTENNA DLK-125 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P Is the inspection result normal? YES >> GO TO 4. NO >> GO TO 2. 2.CHECK INSIDE KEY

Page 715 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-126 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] INSIDE KEY ANTENNA 3. Check continuity between Intelligent Key unit connector and ground. Is the inspection result normal? YES >> GO TO

Page 716 of 5883

NISSAN TIIDA 2007 Service Repair Manual INSIDE KEY ANTENNA DLK-127 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P Is the inspection result normal? YES >> Replace inside key antenna (console). Refer

Page 717 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-128 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] INSIDE KEY ANTENNA With CONSULT-III 1. Check “ANTENNA” in “Active Test” mode with CONSULT-III. 2. Touch “ROOM ANT 2”. 3. Wh

Page 718 of 5883

NISSAN TIIDA 2007 Service Repair Manual INSIDE KEY ANTENNA DLK-129 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P Is the inspection result normal? YES >> GO TO 4. NO >> GO TO 2. 2.CHECK INSIDE KEY

Page 719 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-130 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] INSIDE KEY ANTENNA 3. Check continuity between Intelligent Key unit connector and ground. Is the inspection result normal? YES >> GO TO

Page 720 of 5883

NISSAN TIIDA 2007 Service Repair Manual INSIDE KEY ANTENNA DLK-131 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P Is the inspection result normal? YES >> Replace inside key antenna (rear floor). Ref
