Page 3569 of 5883

NISSAN TIIDA 2007 Service Repair Manual HAC-236 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] BLOWER MOTOR CONTROL SYSTEM YES >> GO TO 6. NO >> Repair harness or connector. 6.CHECK CIRCUIT CONTINUITY BETWEEN FRONT AIR CONTROL AND V

Page 3570 of 5883

NISSAN TIIDA 2007 Service Repair Manual BLOWER MOTOR CONTROL SYSTEM HAC-237 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] C D E F G H J K L MA B HAC N O P Apply 12 volts to terminal 1 and ground to terminal 2 and verify that the mo

Page 3571 of 5883

NISSAN TIIDA 2007 Service Repair Manual HAC-238 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] MAGNET CLUTCH MAGNET CLUTCH System DescriptionINFOID:0000000001547352 SYSTEM DESCRIPTION Front air control controls compressor operation

Page 3572 of 5883

NISSAN TIIDA 2007 Service Repair Manual MAGNET CLUTCH HAC-239 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] C D E F G H J K L MA B HAC N O P 6. CHECK INTAKE SENSOR CIRCUIT Perform diagnostic procedure for the intake sensor circuit.

Page 3573 of 5883

NISSAN TIIDA 2007 Service Repair Manual HAC-240 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] MAGNET CLUTCH 1. Turn ignition switch OFF. 2. Disconnect A/C compressor connector. 3. Start the engine. 4. Press AUTO switch and A/C swi

Page 3574 of 5883

NISSAN TIIDA 2007 Service Repair Manual MAGNET CLUTCH HAC-241 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] C D E F G H J K L MA B HAC N O P 1. Turn ignition switch OFF. 2. Disconnect front air control connector and BCM connector.

Page 3575 of 5883

NISSAN TIIDA 2007 Service Repair Manual HAC-242 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] MAGNET CLUTCH 1. Start the engine. 2. Check voltage between ECM harness connector F11 and ground. Is the inspection result normal YES >>

Page 3576 of 5883

NISSAN TIIDA 2007 Service Repair Manual MAGNET CLUTCH HAC-243 < COMPONENT DIAGNOSIS >[AUTO AIR CONDITIONER (W/NAVI)] C D E F G H J K L MA B HAC N O P 1. Reconnect front air control connector and BCM connector. 2. Turn ignition switch ON. 3.
