EM-322
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
e. Position bearing insert [SST: KV113B0160 (Mot. 1493-01)] on
the bearing cap.
f. Install the main bearing in bearing insert [SST: KV113B0160
(Mot. 1493-01)], then press at (A) until the main bearing is
touching at (B) with bearing insert.
g. Lubricate the main bearing with engine oil.
h. Install the crankshaft.
i. Install the lateral shims on bearing No. 3, putting the grooves on
the crankshaft side.
j. Degrease the gasket faces (of the cylinder block and bearing
No. 1). They should be clean, dry and free from grease (in par-
ticular, remove finger marks).
k. Lay two beads of liquid sealant with a width of 4 mm (0.16 in) on
bearing No. 1 of the cylinder block.
l. Install the main bearing caps on bearing cap No. 1 (these are
numbered from 1 - 5 and these numbers should be positioned
opposite the water pump). Then tighten the bolts to a torque of
25 N·m (2.6 kg-m, 18 ft-lb) plus an angle tightening of 47
degrees.
m. Turn all bolts 47 degrees clockwise (angle tightening).
CAUTION:
Check and confirm the tightening angle by using the angle
wrench [SST: KV10112100 ( — )] or protractor. Avoid judg-
ment by visual inspection without the tool.
n. Check the lateral play. Refer to EM-330, "
Inspection".
9. Install connecting rod bearing with the following procedure.
MBIB0474E
MBIB0475E
MBIB0478E
: 25.0 N·m (2.6 kg-m, 18 ft-lb)
MBIB0476E
Page 2970 of 5883
CYLINDER BLOCK
EM-323
< DISASSEMBLY AND ASSEMBLY >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
The connecting rod bearing are installed using bearing assem-
bling set [SST: KV113B0140 (Mot. 1492)] and bearing assem-
bling adapter [SST: KV113B0150 (Mot. 1492-03)].
a. Slide the connecting rod bearing support (A) of bearing assem-
bling adapter [SST: KV113B0150 (Mot. 1492-03)] (positioning
the engraved mark (B) as shown)] into the groove (C) of the
base of bearing assembling set [SST: KV113B0140 (Mot.
1492)].
b. Install the guide (D) of bearing assembling adapter [SST:
KV113B0150 (Mot. 1492-03)] onto the base (as shown).
c. Lay the body of the connecting rod on the base of the tool (as
shown in the diagram). Check that the lower part (E) of the small
end is touching the centering pin and push the guide (G) in the
direction of the arrow.
MBIB0461E
MBIB0352E
MBIB0462E
MBIB0463E
MBIB0464E
Page 2971 of 5883
EM-324
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
d. Lay the connecting rod bearing [with a width of 20.625 mm
(0.8120 in)] (F) on the connecting rod bearing support, then
push it in the direction of the arrow (as shown).
e. Bring the connecting rod support up against the base of the con-
necting rod body.
f. Remove the connecting rod body support and repeat the opera-
tion for the remaining connecting rod bodies.
g. Position the connecting rod bearing support either on the
engraved mark (C) if the width of the connecting rod bearing is
equal to 20.625 mm (0.8120 in).
h. Position the connecting rod bearing support either on the
engraved mark (D) if the width of the connecting rod bearing is
equal to 17.625 mm (0.6939 in).
i. Install the connecting rod cap as shown.
j. Push the guide (in the direction of the arrow) until the connecting
rod cap is in contact with the pins (I) on the base of the tool.
MBIB0465E
MBIB0466E
MBIB0467E
MBIB0468E
MBIB0469E
Page 2972 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CYLINDER BLOCK
EM-325
< DISASSEMBLY AND ASSEMBLY >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
k. Install the connecting rod bearing (H) on the bearing support,
then push it in the direction of the arrow (as NISSAN TIIDA 2007 Service Repair Manual CYLINDER BLOCK
EM-325
< DISASSEMBLY AND ASSEMBLY >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
k. Install the connecting rod bearing (H) on the bearing support,
then push it in the direction of the arrow (as](/manual-img/5/57395/w960_57395-2971.png)
CYLINDER BLOCK
EM-325
< DISASSEMBLY AND ASSEMBLY >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
k. Install the connecting rod bearing (H) on the bearing support,
then push it in the direction of the arrow (as shown).
l. Bring the connecting rod bearing support up against the base of
the connecting rod cap.
m. Remove the connecting rod bearing support and repeat the
operation for the remaining connecting rod caps.
10. Assemble connecting rod and piston with the following procedure.
a. The pistons have a mark engraved on their heads indicating the engine rear side.
Oil the piston pin.
Check that the piston pins rotate correctly in the new piston and in the matching connecting rod.
b. Point the mark (A) engraved on the top of the piston upwards
and the flat (B) of the big end downwards as shown.
c. Position the opening (C) of the snap rings opposite the removal
and fitting channel (D).
d. Install snap ring.
Rings set to their original adjustment must be free within their
channels.
Ensure the snap rings are fitted the correct way, with the word
TOP pointing upwards.
MBIB0470E
MBIB0471E
MBIB0342E
MBIB0343E
Page 2973 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-326
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
e. Ensure the break in each piston ring is correctly oriented as
shown.
f. Apply new engine oil to the pistons.
g. Install the connecting rod/pi NISSAN TIIDA 2007 Service Repair Manual EM-326
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
e. Ensure the break in each piston ring is correctly oriented as
shown.
f. Apply new engine oil to the pistons.
g. Install the connecting rod/pi](/manual-img/5/57395/w960_57395-2972.png)
EM-326
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
e. Ensure the break in each piston ring is correctly oriented as
shown.
f. Apply new engine oil to the pistons.
g. Install the connecting rod/piston assemblies into the cylinder
block using the ring, being careful to fit them the right way round
(mark towards the flywheel).
h. Install the connecting rods onto the oiled crankshaft pins of the
crankshaft.
i. Install the connecting rod caps, ensuring they are correctly
matched.
j. Tighten the connecting rod cap bolts.
k. Turn all bolts 45 degrees clockwise (angle tightening).
CAUTION:
Check and confirm the tightening angle by using the angle wrench [SST: KV10112100 ( — )] or pro-
tractor. Avoid judgment by visual inspection without the tool.
l. Inspect that the big end lateral play. Refer to EM-330, "
Inspection".
11. Install the oil pump sprocket and chain.
12. Tighten oil pump mounting bolts.
13. Install water pump, Refer to CO-66, "
Removal and Installation".
NOTE:
The gasket faces (cylinder block, crankshaft cover and water
pump) must be clean, dry and free from grease (in particular,
remove finger marks).
14. Install crankshaft cover oil seal with a new one.
15. Install the crankshaft cover in the numerical order as shown.
16. Apply two beads (B) of liquid gasket, with a diameter of 5 mm
(0.20 in).
Apply two points (C) of liquid gasket, with a diameter of 5 mm
(0.20 in) at the intersection of the crankshaft cover and the cylin-
der block.
Use Genuine Liquid Gasket or equivalent.: 20.0 N·m (2.0 kg-m, 15 ft-lb)
: 25.0 N·m (2.6 kg-m, 18 ft-lb)
: 11.0 N·m (1.1 kg-m, 8 ft-lb)
MBIB0339E
MBIB0442E
E1BIA0051ZZ
MBIB0483E
Page 2974 of 5883
CYLINDER BLOCK
EM-327
< DISASSEMBLY AND ASSEMBLY >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
17. Apply two beads (B) of liquid gasket, with a diameter of 5 mm
(0.20 in).
Use Genuine Liquid Gasket or equivalent.
18. Install the oil pan Refer to EM-284, "
Removal and Installation".
19. Crankshaft elastomer seal, timing side.
20. Screw the threaded rod (A) of front oil seal drift set [SST:
KV113B0220 (Mot. 1586)] into the crankshaft.
21. Position the spacer (B) of front oil seal drift set [SST:
KV113B0220 (Mot. 1586)] on the crankshaft.
22. Install the protector complete with the seal onto the spacer, tak-
ing care not to touch the seal.
23. Install the cover (A) and the nut (B) (putting the threaded part
(C) of the nut on the side away from the engine) of front oil seal
drift set [SST: KV113B0220 (Mot. 1586)].
MBIB0484E
MBIB0487E
MBIB0488E
MBIB0489E
MBIB0490E
Page 2975 of 5883
EM-328
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
24. Tighten the nut until the cover touches the spacer.
25. Remove the nut, the cover, the protector and the threaded rod.
26. Crankshaft elastomer seal, flywheel side.
27. Install front oil seal drift set [SST: KV113B0210 (Mot. 1585)] on
the crankshaft, securing it with bolts (F).
MBIB0491E
MBIB0492E
MBIB0493E
MBIB0494E
Page 2976 of 5883
CYLINDER BLOCK
EM-329
< DISASSEMBLY AND ASSEMBLY >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
28. Put the protector complete with the seal on front oil seal drift set
