Page 5777 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-62 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 8 (V)GroundCombination switch INPUT 3InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4V Lighting switch HI (Wiper intermittent

Page 5778 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS BCM (BODY CONTROL MODULE) WCS-63 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 9 (P)GroundCombination switch INPUT 1InputCombination switch (Wiper intermit- tent dial 4)All switch OFF 1.4V Turn

Page 5779 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-64 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 13 (V)GroundCombination switch OUTPUT 1OutputCombination switchAll switch OFF (Wiper intermittent dial 4)0V Front wiper switch HI (Wiper intermitte

Page 5780 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS BCM (BODY CONTROL MODULE) WCS-65 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 24 (O)GroundIgnition power sup- plyInputIgnition switch OFF or ACC 0V Ignition switch ON or START Battery voltage 25

Page 5781 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-66 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 27 (Y)GroundCombination switch INPUT 4InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4V Lighting switch AUTO (Wiper intermitte

Page 5782 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS BCM (BODY CONTROL MODULE) WCS-67 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 28 (R)GroundCombination switch INPUT 2InputCombination switch (Wiper intermit- tent dial 4)All switch OFF 1.4V Lig

Page 5783 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-68 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 324 (LG)GroundDoor lock status indi- catorOutputDoor lock status indicatorON Battery voltage OFF 0V 33 (G)GroundCombination switch OUTPUT 2OutputCo

Page 5784 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS BCM (BODY CONTROL MODULE) WCS-69 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 527 (GR)Ground PTC relay 2 control Output Ignition ONPTC heater 2 ON 0V PTC heater 2 OFF Battery voltage 58 (Y)Groun
