Page 5769 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-54 < ECU DIAGNOSIS > COMBINATION METER Fail Safe INFOID:0000000001728310 The combination meter performs a fail-safe operation for the functions listed below when communication is lost. ALNIA0862GB

Page 5770 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS COMBINATION METER WCS-55 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P DTC IndexINFOID:0000000001728311 NOTE: “TIME” indicates the following.  0: Indicates that a malfunction is detected at

Page 5771 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-56 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) BCM (BODY CONTROL MODULE) Reference ValueINFOID:0000000001728312 VALUES ON THE DIAGNOSIS TOOL Monitor Item Condition Value/Status AIR COND SWA/C swit

Page 5772 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS BCM (BODY CONTROL MODULE) WCS-57 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P ENGINE RUNEngine stopped OFF Engine running ON ENGINE STATUS NOTE: Diesel engine models onlyEngine stopped STOP Whi

Page 5773 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-58 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 1: With Intelligent Key 2: With remote keyless entry system 3: HatchbackKEYLESS LOCK 2LOCK button of key fob is not pressed OFF LOCK button of key fo

Page 5774 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS BCM (BODY CONTROL MODULE) WCS-59 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P Terminal LayoutINFOID:0000000001728313 TERMINAL LAYOUT Physical ValuesINFOID:0000000001728314 PHYSICAL VALUES CAUTIO

Page 5775 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS-60 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE)  Check combination switch system terminal waveform under the loaded condition with lighting switch, turn signal switch and wiper switch OFF is not t

Page 5776 of 5883

NISSAN TIIDA 2007 Service Repair Manual WCS BCM (BODY CONTROL MODULE) WCS-61 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 7 (LG)GroundCombination switch INPUT 5InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.3V Front
