Page 497 of 5883
CO-16
< ON-VEHICLE REPAIR >[HR16DE]
RADIATOR
ON-VEHICLE REPAIR
RADIATOR
ComponentINFOID:0000000001534605
Removal and InstallationINFOID:0000000001534606
WARNING:
1. Reservoir tank cap 2. Reservoir tank 3. Radiator hose (upper)
4. Mounting rubber (upper) 5. Radiator cap 6. Reservoir tank hose
7. Radiator 8. A/T fluid cooler hose 9. Mounting rubber (lower)
10. O-ring 11. Radiator drain plug 12. A/T fluid cooler hose
13. Radiator hose (lower) 14. Cooling fan assembly
A. To water outlet B. To A/T C. To water inlet
D. M/T models E. Models with A/C
AWBIA0128GB
Page 498 of 5883
![NISSAN TIIDA 2007 Service Repair Manual RADIATOR
CO-17
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Do not remove radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping fro NISSAN TIIDA 2007 Service Repair Manual RADIATOR
CO-17
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Do not remove radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping fro](/manual-img/5/57395/w960_57395-497.png)
RADIATOR
CO-17
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Do not remove radiator cap when the engine is hot. Serious burns could occur from high-pressure
engine coolant escaping from radiator. Wrap a thick cloth around the cap. Slowly turn it a quarter of a
turn to release built-up pressure. Carefully remove radiator cap by turning it all the way.
REMOVAL
1. Drain engine coolant from radiator. Refer to CO-11, "Changing Engine Coolant".
CAUTION:
Perform this step when engine is cold.
Do not spill engine coolant on drive belt.
2. Remove air duct (inlet). Refer to EM-27, "
Exploded View".
3. Remove reservoir tank as follows:
a. Disconnect reservoir tank hose.
b. Release the tab (A) in the direction shown by the arrow ( ).
c. Lift up while removing the reservoir tank hose, and remove it.
4. Disconnect harness connector from fan motor, and move harness aside.
5. Disconnect A/T fluid cooler hoses if equipped.
Install plug to avoid leakage of A/T fluid if equipped.
6. Remove radiator hoses (upper and lower).
7. Remove radiator core support cover.
8. Remove radiator core support (upper) bolts, bolts of stationary
part on the radiator core support side and clip. Lift radiator
assembly (1) from radiator (upper) mount part of radiator core
support (upper) (2).
9. Move radiator assembly (1) to the rearward direction of vehicle,
and then lift it upward to remove.
CAUTION:
Do not damage or scratch A/C condenser if equipped and
radiator core when removing.
INSTALLATION
Installation is the reverse order of removal.
CAUTION:
Do not damage or scratch A/C condenser if equipped and radiator core when removing.
INSPECTION AFTER INSTALLATION
Check for leaks of engine coolant.
Start and warm up engine. Visually check if there is no leaks of engine coolant and A/T fluid if equipped.
PBIC3800E
PBIC3805E
Page 499 of 5883
CO-18
< ON-VEHICLE REPAIR >[HR16DE]
COOLING FAN
COOLING FAN
Component (Models with A/C)INFOID:0000000001534607
Component (Models without A/C)INFOID:0000000001534608
1. Fan motor cover 2. Fan motor 3. Cooling fan control module
4. Washer 5. Fan shroud 6. Washer
7. Cooling fan A. Apply on fan motor shaft Front
PBIC4538E
1. Fan motor 2. Fan shroud 3. Cooling fan
A. Apply on fan motor shaft Front
WBIA0786E
Page 500 of 5883
COOLING FAN
CO-19
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Removal and InstallationINFOID:0000000001534609
REMOVAL
1. Drain engine coolant from radiator. Refer to CO-11, "Changing Engine Coolant".
CAUTION:
Perform this step when engine is cold.
Do not spill engine coolant on drive belt.
2. Remove air duct (inlet). Refer to EM-27, "
Exploded View".
3. Remove reservoir tank.
4. Disconnect radiator hose (upper) at radiator side. Refer to CO-16, "
Component".
5. Disconnect harness connectors from fan motor, and move harness to aside.
6. Remove cooling fan assembly.
CAUTION:
Be careful not to damage or scratch the radiator core.
INSTALLATION
Installation is the reverse order of removal.
Cooling fans are controlled by ECM. For details, refer to CO-4, "
Engine Cooling System".
CAUTION:
Be careful not to damage or scratch the radiator core.
Page 501 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CO-20
< ON-VEHICLE REPAIR >[HR16DE]
WATER PUMP
WATER PUMP
Exploded ViewINFOID:0000000001381568
Removal and InstallationINFOID:0000000001381569
REMOVAL
1. Drain engine coolant from radiator. Refer to C NISSAN TIIDA 2007 Service Repair Manual CO-20
< ON-VEHICLE REPAIR >[HR16DE]
WATER PUMP
WATER PUMP
Exploded ViewINFOID:0000000001381568
Removal and InstallationINFOID:0000000001381569
REMOVAL
1. Drain engine coolant from radiator. Refer to C](/manual-img/5/57395/w960_57395-500.png)
CO-20
< ON-VEHICLE REPAIR >[HR16DE]
WATER PUMP
WATER PUMP
Exploded ViewINFOID:0000000001381568
Removal and InstallationINFOID:0000000001381569
REMOVAL
1. Drain engine coolant from radiator. Refer to CO-11, "Changing Engine Coolant".
CAUTION:
Perform this step when the engine is cold.
Never spill engine coolant on drive belts.
2. Steer front wheel to the right.
3. Remove front fender protector (RH). Refer to EXT-22, "
Removal and Installation".
4. Loosen mounting bolts of water pump pulley before loosening belt tension of drive belt.
5. Remove drive belt. Refer to EM-16, "
Removal and Installation".
6. Remove water pump pulley.
7. Remove water pump.
Loosen mounting bolts in reverse order as shown.
Engine coolant will leak from cylinder block, so have a recep-
tacle ready below.
CAUTION:
Handle water pump vane so that it does not contact any
other parts.
Water pump cannot be disassembled and should be
replaced as a unit.
INSTALLATION
Installation is in the reverse order of removal.
Water pump.
1. Gasket 2. Water pump 3. Water pump pulley
PBIC3807E
KBIA3393J
Page 502 of 5883
WATER PUMP
CO-21
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Tighten bolts in numerical order as shown.
Water pump pulley.
CAUTION:
Never install mounting bolts (A) to oblong holes (B).
Water pump pulley (1)
InspectionINFOID:0000000001381570
INSPECTION AFTER REMOVAL
Visually check if there is no significant dirt or rusting on water
pump body and vane (A).
Make sure that there is no looseness in vane shaft, and that it turns
smoothly when rotated by hand.
Replace water pump, if necessary.
INSPECTION AFTER INSTALLATION
Check that the reservoir tank cap is tightened.
Check for leaks of engine coolant using suitable tools. Refer to CO-11, "
Inspection".
Start and warm up the engine. Visually make sure that there is no leaks of engine coolant.
KBIA3393J
PBIC3809E
PBIC3808E
Page 503 of 5883
CO-22
< ON-VEHICLE REPAIR >[HR16DE]
THERMOSTAT
THERMOSTAT
Exploded ViewINFOID:0000000001381571
Removal and InstallationINFOID:0000000001381572
REMOVAL
1. Drain engine coolant from radiator. Refer to CO-11, "Changing Engine Coolant".
CAUTION:
Perform this step when engine is cold.
Never spill engine coolant on drive belt.
2. Add paint mark, then disconnect radiator hose (lower) from water inlet. Refer to CO-16, "
Component".
3. Remove water inlet and thermostat.
Engine coolant will leak from cylinder block, so have a receptacle ready below.
INSTALLATION
Installation is in the reverse order of removal.
Thermostat
Install thermostat with making rubber ring (1) groove fit to thermo-
stat flange (A) with the whole circumference.
1. Radiator hose (lower) 2. Water inlet 3. Rubber ring
4. Thermostat
A. To radiator
PBIC3810E
PBIC3811E
Page 504 of 5883
![NISSAN TIIDA 2007 Service Repair Manual THERMOSTAT
CO-23
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Install thermostat (2) into the cylinder block (1) with jiggle valve (A)
facing upwards.
Water Inlet.
After installati NISSAN TIIDA 2007 Service Repair Manual THERMOSTAT
CO-23
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Install thermostat (2) into the cylinder block (1) with jiggle valve (A)
facing upwards.
Water Inlet.
After installati](/manual-img/5/57395/w960_57395-503.png)
THERMOSTAT
CO-23
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
CO
N
P O
Install thermostat (2) into the cylinder block (1) with jiggle valve (A)
facing upwards.
Water Inlet.
After installation, fix water inlet clip (A) on the oil level gauge guide
(1) positioned (b) as shown.
InspectionINFOID:0000000001381573
INSPECTION AFTER REMOVAL
WARNING:
Use a protector to prevent a burn during the work.
Thermostat
Place a thread (A) so that it is caught in the valves of thermostat
(1). Immerse fully in a container (B) filled with water. Heat while
stirring.
The valve opening temperature is the temperature at which the
valve opens and falls from the thread.
Continue heating. Check the full open valve lift amount.
After checking the maximum valve lift amount, lower the water
temperature and check the valve closing temperature.
If out of the standard, replace thermostat.
INSPECTION AFTER INSTALLATION
Check that the reservoir tank cap is tightened.
Check for leaks of engine coolant using suitable tools. Refer to CO-11, "
Inspection".
Start and warm up the engine. Visually make sure that there is no leaks of engine coolant.
PBIC3812E
PBIC3755E
Standard : Refer to CO-27, "Thermostat".
PBIC3314J
