NISSAN TIIDA 2007 Service Repair Manual BCS-34 < COMPONENT DIAGNOSIS > COMBINATION SWITCH COMBINATION SWITCH DescriptionINFOID:0000000001451493 COMBINATION SWITCH MATRIX Combination switch consists of INPUT circuit and OUTPUT circuit. Combi

Page 170 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCS BCM (BODY CONTROL MODULE) BCS-35 < ECU DIAGNOSIS > C D E F G H I J K L B A O P N ECU DIAGNOSIS BCM (BODY CONTROL MODULE) Reference ValueINFOID:0000000001451495 VALUES ON THE DIAGNOSIS TOOL Monitor

Page 171 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCS-36 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) ENGINE RPM NOTE: Diesel engine models onlyEngine runningApproximately the same as tachom- eter reading ENGINE RUNEngine stopped OFF Engine running O

Page 172 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCS BCM (BODY CONTROL MODULE) BCS-37 < ECU DIAGNOSIS > C D E F G H I J K L B A O P N I-KEY UNLOCK1UNLOCK button of Intelligent Key is not pressed OFF UNLOCK button of Intelligent Key is pressed ON KEY

Page 173 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCS-38 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 1: With Intelligent Key 2: With remote keyless entry system 3: Hatchback Terminal LayoutINFOID:0000000001538883 TERMINAL LAYOUT ALMIA0185ZZ

Page 174 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCS BCM (BODY CONTROL MODULE) BCS-39 < ECU DIAGNOSIS > C D E F G H I J K L B A O P N Physical ValuesINFOID:0000000001538886 PHYSICAL VALUES CAUTION:  Check combination switch system terminal waveform

Page 175 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCS-40 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 7 (LG)GroundCombination switch INPUT 5InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.3V Front fog lamp switch ON (Wiper interm

Page 176 of 5883

NISSAN TIIDA 2007 Service Repair Manual BCS BCM (BODY CONTROL MODULE) BCS-41 < ECU DIAGNOSIS > C D E F G H I J K L B A O P N 8 (V)GroundCombination switch INPUT 3InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4V Light
