Page 2713 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-66
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
6. Install the camshaft sprocket (INT) to the camshaft (INT) with the
following procedure.
a. Align the matching mark (A) put according to step “4”. Se NISSAN TIIDA 2007 Service Repair Manual EM-66
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
6. Install the camshaft sprocket (INT) to the camshaft (INT) with the
following procedure.
a. Align the matching mark (A) put according to step “4”. Se](/manual-img/5/57395/w960_57395-2712.png)
EM-66
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
6. Install the camshaft sprocket (INT) to the camshaft (INT) with the
following procedure.
a. Align the matching mark (A) put according to step “4”. Securely
align the knock pin and the pin hole, and then install them.
b. Temporarily tighten the bolt on the front side of camshaft (INT)
(1).
7. Put a thick shop cloth (B) to the lower surface, and then set the
tools to the bolt camshaft (INT) (1).
8. Tighten the mounting bolt.
CAUTION:
Hold the camshaft hexagonal part (A), and then secure the
camshaft.
9. Return the camshaft (INT) to the cylinder head carefully.
10. Install the camshaft (EXH) to the camshaft sprocket (EXH) (2)
while aligning the matching make (marked when timing chain is
removed) (A) and the matching mark (stamp) (B) of camshaft
sprocket (EXH).
If the positions of knock pin and pin groove are not aligned,
move the camshaft (EXH) slightly to correct these positions.
PBIC3700E
2 : Camshaft sprocket (INT)
AWBIA011 0ZZ
PBIC3701E
1 : Timing chain
3 : Camshaft sprocket (INT)
C : Matching mark (peripheral stamp line)
AWBIA011 2ZZ
Page 2714 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-67
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
11. Tighten the mounting bolt.
CAUTION:
Hold the camshaft hexagonal part (A), and then secure the
camshaft.
Make sure t NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-67
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
11. Tighten the mounting bolt.
CAUTION:
Hold the camshaft hexagonal part (A), and then secure the
camshaft.
Make sure t](/manual-img/5/57395/w960_57395-2713.png)
CAMSHAFT
EM-67
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
11. Tighten the mounting bolt.
CAUTION:
Hold the camshaft hexagonal part (A), and then secure the
camshaft.
Make sure that the matching mark (marked when timing
chain is removed) and each camshaft sprocket matching
mark are in the correct location.
12. Install camshaft brackets (No. 2 to 5) aligning the identification
marks on upper surface as shown.
Install so that identification mark can be correctly read when
viewed from the INT side.
13. Tighten mounting bolts of camshaft brackets in the following
steps, in numerical order as shown.
a. Tighten No. 9 to 11 in numerical order.
b. Tighten No. 1 to 8 in numerical order.
c. Tighten all bolts in numerical order.
d. Tighten all bolts in numerical order.
1 : Camshaft sprocket (EXH)
AWBIA0102ZZ
A : EXH side
B : INT side
: Engine front
PBIC3703E
A : EXH side
B : INT side
: Engine front
: 2.0 N·m (0.2 kg-m, 1 ft-lb)
: 2.0 N·m (0.2 kg-m, 1 ft-lb)
: 5.9 N·m (0.6 kg-m, 4 ft-lb)
: 10.4 N·m (1.1 kg-m, 8 ft-lb)
PBIC3686E
Page 2715 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-68
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
14. Install timing chain with the following procedure.
Install by aligning matching marks on each sprocket and tim-
ing chain.
If these matching marks NISSAN TIIDA 2007 Service Repair Manual EM-68
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
14. Install timing chain with the following procedure.
Install by aligning matching marks on each sprocket and tim-
ing chain.
If these matching marks](/manual-img/5/57395/w960_57395-2714.png)
EM-68
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
14. Install timing chain with the following procedure.
Install by aligning matching marks on each sprocket and tim-
ing chain.
If these matching marks are not aligned, rotate the camshaft
slightly to correct the position.
CAUTION:
Check matching mark position of each sprocket and tim-
ing chain again after installing the timing chain, keep
matching marks aligned by holding them with a hand.
To avoid skipped teeth, never rotate crankshaft and cam-
shaft until front cover is installed.
15. Install timing chain tension guide (2) and timing chain slack
guide (1).
16. Install chain tensioner (1).
Fix the plunger at the most compressed position using a stop-
per pin (A), and then install it.
Securely pull out the stopper pin after installing the chain ten-
sioner.
17. Check matching mark position of timing chain and each sprocket again.
A : Dark blue link
B : Matching mark (stamp)
C : Orange link
D : Matching mark (stamp)
E : Crankshaft key (point straight up)
F : Matching mark (peripheral stamp line)
G : Dark blue link
PBIC3721E
PBIC3714E
PBIC3722E
Page 2716 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-69
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
18. Pull out the stopper pin (A), and then apply the tension to the
timing chain by rotating the crankshaft pulley clockwis NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-69
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
18. Pull out the stopper pin (A), and then apply the tension to the
timing chain by rotating the crankshaft pulley clockwis](/manual-img/5/57395/w960_57395-2715.png)
CAMSHAFT
EM-69
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
18. Pull out the stopper pin (A), and then apply the tension to the
timing chain by rotating the crankshaft pulley clockwise slightly.
19. Return the camshaft sprocket (INT) in the most retarded position with the following procedure.
a. Remove the stopper pin (A) from the camshaft sprocket (INT).
b. Turn the crankshaft slowly clockwise and return the camshaft sprocket (INT) to the most retarded angle
position.
When first turning the crankshaft the camshaft sprocket (INT)
will turn. Once it is turned more, and the vane (camshaft) also
turns, then it has reached the most retarded angle position.
The most retarded angle position can be checked by seeing if
the stopper pin groove (A) is shifted clockwise.
After spinning the crankshaft slightly in the counterclockwise
direction, you can make sure the lock pin has joined by seeing
if the vane (camshaft) and the sprocket move together.
20. Install the front oil seal to the front cover. Refer to EM-78, "
FRONT OIL SEAL : Removal and Installation"
21. Install front cover with the following procedure:
1 : Plunger
2 : Chain tensioner
B: Lever
C: Lever hole
D : Front cover has been omitted
PBIC3772E
B: Tape
AWBIA0107ZZ
B : Stopper pin hole
C : Most advanced angle
D : Most retarded angle (lock pin engaged)
PBIC3705E
Page 2717 of 5883
EM-70
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
a. Apply a continuous bead of liquid gasket with tube presser
(commercial service tool) to front cover as shown.
Use Genuine Liquid Gasket or equivalent.
b. Apply a continuous bead of liquid gasket with suitable tool to
front cover as shown.
Use Genuine Liquid Gasket or equivalent.
1 : Cylinder head
2 : Cylinder block
3 : Oil pan (upper)
A : Liquid gasket application area φ 3.0 - 4.0 mm (0.12 - 0.16 in)
PBIC3724E
A : Liquid gasket application area φ 3.0 - 4.0 mm (0.12 - 0.16 in)
PBIC3725E
Page 2718 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-71
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
c. Tighten bolts in the numerical order shown.
d. After all bolts are tightened, retighten them to specified torque in
nume NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-71
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
c. Tighten bolts in the numerical order shown.
d. After all bolts are tightened, retighten them to specified torque in
nume](/manual-img/5/57395/w960_57395-2717.png)
CAMSHAFT
EM-71
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
c. Tighten bolts in the numerical order shown.
d. After all bolts are tightened, retighten them to specified torque in
numerical order as shown.
CAUTION:
Be sure to wipe off any excessive liquid gasket leaking to
surface.
22. Insert crankshaft pulley by aligning with crankshaft key.
When inserting crankshaft pulley with a plastic hammer, tap on its center portion (not circumference).
CAUTION:
Never damage front oil seal lip section.
23. Tighten crankshaft pulley bolt with the following procedure:
Secure crankshaft pulley with a suitable tool, and tighten crankshaft pulley bolt.
a. Apply new engine oil to thread and seat surfaces of crankshaft pulley bolt.
b. Tighten crankshaft pulley bolt.
c. Put a paint mark (B) on crankshaft pulley, mating with any one of
six easy to recognize angle marks (A) on crankshaft bolt flange
(1).
d. Turn another 60 degrees clockwise (angle tightening).
Check the tightening angle with movement of one angle mark.
24. Make sure that crankshaft turns smoothly by rotating by hand clockwise.
25. Install the camshaft position sensor (PHASE) to the rear end of cylinder head.
Tighten bolts with it seated completely.
26. Check and adjust valve clearance. Refer to EM-21, "
Inspection and Adjustment".
27. Installation is in the reverse order of removal, for the remaining parts.
InspectionINFOID:0000000001381416
INSPECTION AFTER REMOVAL
Oil Filter
KBIA3429J
: 35.0 N·m (3.6 kg-m, 26 ft-lb)
PBIC3726E
Page 2719 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-72
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
Make sure that there is no foreign material on the oil filter (1) and
check it for clogging.
Check the oil filter for damage.
If there is some damage NISSAN TIIDA 2007 Service Repair Manual EM-72
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
Make sure that there is no foreign material on the oil filter (1) and
check it for clogging.
Check the oil filter for damage.
If there is some damage](/manual-img/5/57395/w960_57395-2718.png)
EM-72
< ON-VEHICLE REPAIR >[HR16DE]
CAMSHAFT
Make sure that there is no foreign material on the oil filter (1) and
check it for clogging.
Check the oil filter for damage.
If there is some damage, replace the oil filter, the plug, and the
washer as a set.
Camshaft Runout
1. Put V-block on a precise flat table, and support No. 2 and 5 jour-
nals of camshaft.
CAUTION:
Never support No. 1 journal (on the side of camshaft
sprocket) because it has a different diameter from the other
four locations.
2. Set a dial indicator vertically to No. 3 journal.
3. Turn camshaft to one direction with hands, and measure the
camshaft runout on the dial indicator. (Total indicator reading)
4. If it exceeds the limit, replace camshaft.
Camshaft Cam Height
1. Measure the camshaft cam height with a micrometer (A).
2. If wear exceeds the limit, replace camshaft.
Camshaft Journal Oil Clearance
CAMSHAFT JOURNAL DIAMETER
Measure the outer diameter of camshaft journal with a micrometer
(A).
CAMSHAFT BRACKET INNER DIAMETER
Tighten camshaft bracket bolts with the specified torque. Refer to EM-59, "
Removal and Installation".
PBIC3693E
Standard and Limit:
Refer to EM-123, "
Camshaft".
PBIC2499E
Standard and Cam wear Limit:
Refer to EM-123, "
Camshaft".
PBIC3178J
Standard: Refer to EM-123, "Camshaft".
PBIC3179J
Page 2720 of 5883
![NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-73
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Measure inner diameter (B) of camshaft bracket with a bore gauge
(A).
CAMSHAFT JOURNAL OIL CLEARANCE
(Oil clearance) = NISSAN TIIDA 2007 Service Repair Manual CAMSHAFT
EM-73
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Measure inner diameter (B) of camshaft bracket with a bore gauge
(A).
CAMSHAFT JOURNAL OIL CLEARANCE
(Oil clearance) =](/manual-img/5/57395/w960_57395-2719.png)
CAMSHAFT
EM-73
< ON-VEHICLE REPAIR >[HR16DE]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Measure inner diameter (B) of camshaft bracket with a bore gauge
(A).
CAMSHAFT JOURNAL OIL CLEARANCE
(Oil clearance) = (Camshaft bracket inner diameter) – (Camshaft journal diameter)
If it exceeds the limit, replace either or both camshaft and cylinder head.
NOTE:
Camshaft brackets cannot be replaced as single parts, because they are machined together with cylinder
head. Replace whole cylinder head assembly.
Camshaft End Play
1. Install camshaft in cylinder head. Refer to EM-59, "Removal and Installation".
2. Install a dial indicator (A) in thrust direction on front end of cam-
shaft. Measure the camshaft end play on the dial indicator when
camshaft is moved forward/backward (in direction to axis).
Measure the following parts if out of the standard.
- Dimension “A” for cylinder head No. 1 journal bearing
- Dimension “B” for camshaft thrust
Follow the standards above, and then replace camshaft and/or
cylinder head.
Camshaft Sprocket Runout
1. Put V-block on precise flat table, and support No. 2 and 5 journals of camshaft.
CAUTION:
Never support No. 1 journal (on the side of camshaft sprocket) because it has a different diameter
from the other four locations.Standard: Refer to EM-123, "
Camshaft".
PBIC3180J
Standard and Limit: Refer to EM-123, "Camshaft".
Standard and Limit: Refer to EM-123, "
Camshaft".
PBIC3694E
Standard : 4.000 - 4.030 mm (0.1575 - 0.1587 in)
Standard : 3.877 - 3.925 mm (0.1526 - 0.1545 in)
KBIA3345J
