EM-330
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
31. Remove the nut, the cover, the protector and the threaded rod.
32. Install ring gear stopper [SST: KV113B0060 (Mot. 582-01)] and
tighten flywheel bolts with new one.
33. Turn all bolts 36 degrees clockwise (angle tightening).
CAUTION:
Check and confirm the tightening angle by using the angle
wrench [SST: KV10112100 ( — )] or protractor. Avoid judg-
ment by visual inspection without the tool.
34. Install the clutch housing. Refer to TM-680, "
Exploded View".
35. Remove ring gear stopper [SST: KV113B0060 (Mot. 582-01)].
InspectionINFOID:0000000001381515
CYLINDER BLOCK TOP SURFACE DISTORTION
Using a scraper, remove gasket on the cylinder block surface, and also remove engine oil, scale, carbon, or
other contamination.
CAUTION:
Be careful not to allow gasket flakes to enter engine oil or engine coolant passages.
Measure the distortion on the cylinder block upper face at some
different points in six directions with a straight edge (A) and feeler
gauge (B).
If it exceeds the limit, replace cylinder block.
PISTON PROTRUSION
1. Clean the piston head.
2. Turn the crankshaft one turn in its operating direction to bring piston No. 1 close to TDC.
3. Install dial gauge stand set [KV113B0050 (Mot. 252-01) (com-
mercial service tool) or equivalent tool] on the piston.
4. Install dial gauge stand set [KV113B0040 (Mot. 251-01) (com-
mercial service tool) or equivalent tool] equipped with a gauge
on dial gauge stand set [KV113B0050 (Mot. 252-01) (commer-
cial service tool) or equivalent tool], and find TDC.
NOTE:
All measurements must be carried out along the longitudinal
axis of the engine, in order to eliminate any errors due to tilting
of the piston.
WARNING:
MBIB0499E
: 20.0 N·m (2.0 kg-m, 15 ft-lb)
MBIB0500E
Limit : Refer to EM-337, "CylinderBlock".
PBIC3250J
MBIB0480E
Page 2978 of 5883
CYLINDER BLOCK
EM-331
< DISASSEMBLY AND ASSEMBLY >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
The gauge follower must not be in the valve clearance.
5. Inspect the piston protrusion.
CRANKSHAFT LATERAL PLAY
1. Install crankshaft.
2. Inspect the lateral play.
CONNECTING ROD BIG END LONGITUDINAL PLAY
1. Install crankshaft.
2. Install piston and connecting rod assembly.
3. Inspect that the big end lateral play.
PISTON DIAMETER
Measure the piston diameter.
The piston diameter (A) must be measured at height (a) = 56 mm
(2.205 in).
PISTON RING THICKNESS
Measure piston ring thickness with micrometer.
The piston rings are supplied ready adjusted.
PISTON RING SIDE CLEARANCE
Standard : Refer to EM-337, "CylinderBlock".
Standard : Refer to EM-337, "
CylinderBlock".
MBIB0477E
Standard : Refer to EM-337, "CylinderBlock".
MBIB0479E
Standard : Refer to EM-337, "CylinderBlock".
SEM882E
Standard : Refer to EM-337, "CylinderBlock".
Page 2979 of 5883
EM-332
< DISASSEMBLY AND ASSEMBLY >[K9K]
CYLINDER BLOCK
Measure the side clearance of piston ring and piston ring groove
with a feeler gauge (A).
If the measured value exceeds the limit, replace piston ring, and
measure again. If it still exceeds the limit, replace piston also.
PISTON RING END GAP
Lubricate with new engine oil to piston (1) and piston ring (2), and
then insert (A) piston ring until middle of cylinder (B) with piston,
and measure piston ring end gap with a feeler gauge (C).
If the measured value exceeds the limit, replace piston ring.
CRANKSHAFT MAIN JOURNAL DIAMETER
Use micrometer to measure crankshaft main journal diameter.
CRANKSHAFT PIN JOURNAL DIAMETER
Use micrometer to measure crankshaft pin journal diameter.Standard : Refer to EM-337, "
CylinderBlock".
PBIC3280J
Standard : Refer to EM-337, "CylinderBlock".
PBIC3267J
Standard : Refer to EM-337, "CylinderBlock".
FEM114
Standard : Refer to EM-337, "CylinderBlock".
PBIC0127E
Page 2980 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-333
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
G NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-333
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
G](/manual-img/5/57395/w960_57395-2979.png)
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-333
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
SERVICE DATA AND SPECIFICATIONS (SDS)
SERVICE DATA AND SPECIFICATIONS (SDS)
General SpecificationINFOID:0000000001381516
GENERAL SPECIFICATIONS
Drive BeltINFOID:0000000001381517
DRIVE BELT
CamshaftINFOID:0000000001381518
CAMSHAFT
Unit: mm (in)
Cylinder arrangement In-line 4
Displacement cm
3 (cu in)1.461 (89.15)
Bore and stroke mm (in)76 x 80.5 (2.99 x 3.17)
Valve arrangementSOHC
Firing order1-3-4-2
Number of piston ringsCompression 2
Oil 1
Number of main bearings5
Compression ratio15.3
Compression pressure kPa (bar, kg/cm
2, psi)Maximum pressure must be at least 1,800
(18, 18.36, 261)
Valve timing
abcde f
200°191°-9°20°-7°27°
PBIC0187E
Tension of drive belt Auto adjustment by auto-tensioner
Items Standard
Camshaft bracket inner diameterNo. 1, 2, 3, 4, 5 25.04 - 25.06 (0.9858 - 0.9866)
No. 6 28.04 - 28.06 (1.1039 - 1.1047)
Camshaft journal diameterNo. 1, 2, 3, 4, 5 24.979 - 25.000 (0.9834 - 0.9843)
No. 6 27.979 - 28.000 (1.1015 - 1.1024)
Camshaft end play 0.080 - 0.178 (0.0031 - 0.0070)
Camshaft runoutLess than 0.05 (0.0020)
Page 2981 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-334
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
VALVE LIFTER
Unit: mm (in)
VALVE CLEARANCE
Unit: mm (in)
AVAILABLE VALVE LIFTER
Unit: mm (in)
Camshaft cam he NISSAN TIIDA 2007 Service Repair Manual EM-334
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
VALVE LIFTER
Unit: mm (in)
VALVE CLEARANCE
Unit: mm (in)
AVAILABLE VALVE LIFTER
Unit: mm (in)
Camshaft cam he](/manual-img/5/57395/w960_57395-2980.png)
EM-334
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
VALVE LIFTER
Unit: mm (in)
VALVE CLEARANCE
Unit: mm (in)
AVAILABLE VALVE LIFTER
Unit: mm (in)
Camshaft cam height “A”Intake 43.985 - 44.045 (1.7317 - 1.7341)
Exhaust 44.565 - 44.625 (1.7545 - 1.7569) Items Standard
SEM671
Items Standard
Valve lifter outer diameter 34.965 - 34.985 (1.3767 - 1.3774)
Valve lifter hole diameter 35.000 - 35.040 (1.3780 - 1.3795)
Valve lifter clearance 0.015 - 0.075 (0.0006 - 0.0030)
Items Cold
Intake0.125 - 0.250 (0.0049 - 0.0098)
Exhaust0.325 - 0.450 (0.0128 - 0.0177)
Part number Thickness
13229BN700 7.550 (0.2972)
13229BN701 7.575 (0.2982)
13229BN702 7.600 (0.2992)
13229BN703 7.625 (0.3002)
13229BN704 7.650 (0.3012)
13229BN705 7.675 (0.3022)
13229BN706 7.700 (0.3031)
13229BN707 7.725 (0.3041)
13229BN708 7.750 (0.3051)
13229BN709 7.775 (0.3061)
13229BN710 7.800 (0.3071)
13229BN711 7.825 (0.3081)
13229BN712 7.850 (0.3091)
13229BN713 7.875 (0.3100)
13229BN714 7.900 (0.3110)
13229BN715 7.925 (0.3120)
13229BN716 7.950 (0.3130)
13229BN717 7.975 (0.3140)
Page 2982 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-335
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Cylinder HeadINFOID:0000000001381519
CYLINDER HEAD
Unit: mm (in)
VALVE DIMENS NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-335
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Cylinder HeadINFOID:0000000001381519
CYLINDER HEAD
Unit: mm (in)
VALVE DIMENS](/manual-img/5/57395/w960_57395-2981.png)
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-335
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Cylinder HeadINFOID:0000000001381519
CYLINDER HEAD
Unit: mm (in)
VALVE DIMENSIONS
13229BN718 8.000 (0.3150)
13229BN719 8.025 (0.3159)
13229BN720 8.050 (0.3169)
13229BN721 8.075 (0.3179)
13229BN722 8.100 (0.3189)
13229BN723 8.125 (0.3199)
13229BN724 8.150 (0.3209)Part number Thickness
Items Standard
Cylinder head gasket thickness 0.68 - 0.74 (0.0269 - 0.0291)
Head surface distortion Less than 0.05 (0.002)
Normal cylinder head height “H” 127 (5.000)
E1BIA0063ZZ
Items Standard
Valve head diameter “D” mm (in)Intake 33.38 - 33.62 (1.314 - 1.324)
Exhaust 28.88 - 29.12 (1.137 - 1.146)
Valve length “L” mm (in)Intake 100.74 - 101.16 (3.9661 - 3.9827)
Exhaust 100.54 - 100.96 (3.9583 - 3.9748)
Valve stem diameter “d” mm (in)Intake5.969 - 5.985 (0.2350 - 0.2356)
Measuring point (X1) is 41 (1.61)
Exhaust5.955 - 5.971 (0.2344 - 0.2351)
Measuring point (X1) is 41 (1.61)
Valve seat angle “α”degree 45°00′ (45.00°)
Valve margin “T” mm (in) 1.0 (0.039)
Page 2983 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-336
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
VA LV E G U I D E
VALVE SEAT
Valve lift mm (in)Intake 8.0 (0.315)
Exhaust 8.6 (0.339) Items Standard
E1BIA00 NISSAN TIIDA 2007 Service Repair Manual EM-336
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
VA LV E G U I D E
VALVE SEAT
Valve lift mm (in)Intake 8.0 (0.315)
Exhaust 8.6 (0.339) Items Standard
E1BIA00](/manual-img/5/57395/w960_57395-2982.png)
EM-336
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
SERVICE DATA AND SPECIFICATIONS (SDS)
VA LV E G U I D E
VALVE SEAT
Valve lift mm (in)Intake 8.0 (0.315)
Exhaust 8.6 (0.339) Items Standard
E1BIA0064ZZ
Items Standard
Valve guide mm (in)Length 40.35 - 40.65 (1.5886 - 1.6004)
Outer diameter 10.956 - 11.062 (0.4313 - 0.4355)
Inner diameter (Finished
size)6.000 - 6.018 (0.2362 - 0.2369)
Cylinder head valve guide hole diameter mm (in) 11.0 (0.4431)
Valve guide clearance mm (in)Intake 0.020 - 0.050 (0.0008 - 0.0020)
Exhaust 0.030 - 0.063 (0.0012 - 0.0025)
Projection length “A” mm (in)Intake 14.0 (0.5512)
Exhaust 14.2 (0.5591)
Valve guide inclination angle “a” degree 90°00′ (90.00°)
E1BIA0065ZZ
Items Standard
Cylinder head seat recess diameter “D” mm (in)Intake 34.444 - 34.474 (1.3561 - 1.3572)
Exhaust 29.955 - 29.985 (1.1793 - 1.1805)
Valve seat outer diameter “D” mm (in)Intake 34.534 - 34.550 (1.3596 - 1.3602)
Exhaust 30.035 - 30.048 (1.1825 - 1.1830)
Angle “α”degree 89°30′ (89.50°)
Contacting width “X” mm (in) 1.8 (0.071)
Valve seat height “H” mm (in)Intake 4.61 - 4.69 (0.1815 - 0.1846)
Exhaust 5.63 - 5.71 (0.2217 - 0.2248)
Page 2984 of 5883
![NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-337
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
VALVE SPRING
Cylinder BlockINFOID:0000000001381520
CYLINDER BLOCK
Unit: mm (i NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS)
EM-337
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
VALVE SPRING
Cylinder BlockINFOID:0000000001381520
CYLINDER BLOCK
Unit: mm (i](/manual-img/5/57395/w960_57395-2983.png)
SERVICE DATA AND SPECIFICATIONS (SDS)
EM-337
< SERVICE DATA AND SPECIFICATIONS (SDS) [K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
VALVE SPRING
Cylinder BlockINFOID:0000000001381520
CYLINDER BLOCK
Unit: mm (in)
PISTON MARKING
Cylinder head seat recess depth “H” mm (in)Intake 6.0 (0.236)
Exhaust 7.0 (0.276) Items Standard
E1BIA0066ZZ
Items Standard
Free height mm (in) 43.31 (1.7051)
Pressure N (kg, lb) at height mm (in)218 - 242 (22.2 - 24.7, 49.0 - 54.4) at 33.80 (1.3307)
477 - 523 (48.7 - 53.3, 107.2 - 117.6) at 24.80 (0.9764)
Spring squareness mm (in) 1.2 (0.047)
Full pressed height mm (in) 23.40 (0.9213)
Diameter of wire mm (in) 3.45 (0.1358)
Outer diameter at the top of spring mm (in) 20.8 - 21.2 (0.8189 - 0.8346)
Outer diameter at the bottom of spring mm (in) 25.5 - 25.9 (1.0039 - 1.0197)
Inner diameter at the top of spring mm (in) 13.9 - 14.3 (0.5472 - 0.5630)
Inner diameter at the bottom of spring mm (in) 18.6 - 19.0 (0.7323 - 0.7480)
Items Standard
Cylinder block top surface clearance Less than 0.05 (0.002)
1 Direction of fitting of the piston mark towards the flywheel
2 Height between the piston pin and the top of the piston (see table below).
MBIB0337E
