Page 5369 of 5883

NISSAN TIIDA 2007 Service Repair Manual TCM
TM-423
< ECU DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
TCM CONNECTOR TERMINAL LAYOUT
TERMINALS AND REFERENCE VALUES FOR TCM
Data are reference valuesand are measured betwe

Page 5370 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-424
< ECU DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
TCM
3GRTorque converter clutch
solenoid valveWhen A/T performs lock-up. 8 - 15V
When A/T does not perform lock-up. 0V
5 L CAN H — —
6 P CAN L — �

Page 5371 of 5883

NISSAN TIIDA 2007 Service Repair Manual TCM
TM-425
< ECU DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
*1: These terminals are connected to the data link connector.
*2: These terminals are connected to the ECM.34 LG PNP

Page 5372 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-426
< ECU DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
TCM
Wiring Diagram - A/T CONTROL SYSTEM -
INFOID:0000000001714340
Fail-SafeINFOID:0000000001714341
The TCM has an electronic Fail-safe mode. This allows

Page 5373 of 5883

NISSAN TIIDA 2007 Service Repair Manual TCM
TM-427
< ECU DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
The SELF-DIAGNOSIS results will be as follows:
The first SELF-DIAGNOSIS will indicate damage to the vehicle speed

TCM
TM-427
< ECU DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
The SELF-DIAGNOSIS results will be as follows:
The first SELF-DIAGNOSIS will indicate damage to the vehicle speed sensor or the revolution sensor.
During the next SELF-DIAGNOSIS, performed after checking the sensor, no damages will be indicated.
FAIL-SAFE FUNCTION
The following fail-safe functions allow vehicles to be driven even when sensor, switch or solenoid malfunction
occurs.
Vehicle Speed Sensor·A/T (Revolution Sensor)
Vehicle speed sensor·MTR signal is input from combination meter.
Accelerator Pedal Position Sensor Signal and Throttle Position Sensor Signal
TCM controls the throttle opening angle to a predetermined fixed position to enable driving if a malfunctioning
signal is input to TCM.
PNP Switch
When the multiple PNP switch signals are input to TCM, the priority of selector lever position becomes “D”,
“N”, “R”, “2” and “1” in order by internal TCM determination.
The use of 4th gear is inhibited until normal operation resumes. Because the hydraulic circuit of the control
valve is switched by manual valve according to the selector lever position, however, actual operating condition
of vehicle becomes as follows.
Shift Solenoid Valve A and B
If non-standard solenoid signal is sent to TCM, use of certain gears is limited. Refer to chart shown below.
●: Solenoid ON
×: Solenoid OFF
–: Non-standard condition
Line Pressure Solenoid Valve
If non-standard solenoid signal is sent to TCM, line pressure solenoid valve is turned OFF to achieve maxi-
mum oil pressure.
Torque Converter Clutch Solenoid Valve
Actual lever position PNP switch input signal Running status
“P” “P” position and other position signals P
“R” “R” position and other position signals R
“N” “N” position and other position signals N
“D” “D” position and other position signals D
1⇔D2⇔D3⇔D4
“2”“2” position and other position signals (Except “1” position) 21⇔22⇔23
“2” position and “1” position signals 21⇔22
“1”“1” position and other position signals (Except “2” position) 11⇔12⇔13
“1” position and “2” position signals 11⇔12
Shift positionNormalMalfunction in solenoid
valve AMalfunction in solenoid
valve BMalfunction in solenoid
valves A and B
A BGearABGearABGearABGear
“D” position●●1st –●→×
3rd ●→×–
3rd ––
3rd ×●2nd –●→× ×–––
××3rd – x×–––
●×4th – x●→×–––
“2” position●●1st –●→×●→×–––
×●2nd –●→× ×–––
××3rd – x×–––
“1” position●●1st –●→×●→×–––
×●2nd –●→× ×–––
××3rd – x×–––

Page 5374 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-428
< ECU DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
TCM
If non-standard solenoid signal is sent to TCM, torque converter clutch solenoid valve is turned OFF to release
lock-up.
Overrun Clutch Solenoid Val

Page 5375 of 5883

NISSAN TIIDA 2007 Service Repair Manual SYSTEM SYMPTOM
TM-429
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
C
E
F
G
H
I
J
K
L
MA
B
TM
N
O
P
SYMPTOM DIAGNOSIS
SYSTEM SYMPTOM
Symptom ChartINFOID:0000000001714345
Numbers are arranged in order o

Page 5376 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-430
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Shift ShockSharp shock in shift-
ing from “N” to “D” po-
sition.ON vehicle1. Engine idling speedXX-XX, "*****"

(Type 1), XX

TM-430
< SYMPTOM DIAGNOSIS >[TYPE 2 (4AT: RE4F03B)]
SYSTEM SYMPTOM
Shift ShockSharp shock in shift-
ing from “N” to “D” po-
sition.ON vehicle1. Engine idling speedXX-XX, "*****"

(Type 1), XX-XX,
"*****" (Type 2)
2. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
3. Line pressure testTM-178
4. A/T fluid temperature sensorTM-48
(Type 1),
XX-XX, "*****"

(Type 2)
5. Engine speed signalTM-56
(Type 1),
XX-XX, "*****"

(Type 2)
6. Line pressure solenoid valveTM-81
(Type 1),
XX-XX, "*****"

(Type 2)
7. Control valve assemblyXX-XX, "*****"
8. Accumulator N-DXX-XX, "*****"
OFF vehicle 9. Forward clutchXX-XX, "*****"
Too sharp a shock in
changing from D
1 to
D
2.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Accumulator servo releaseXX-XX, "*****"
4. Control valve assemblyXX-XX, "*****"
5. A/T fluid temperature sensorTM-48
(Type 1),
XX-XX, "*****"

(Type 2)
OFF vehicle 6. Brake bandXX-XX, "*****"
Too sharp a shock in
changing from D
2 to
D
3.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Control valve assemblyXX-XX, "*****"
OFF vehicle4. High clutchXX-XX, "*****"5. Brake bandXX-XX, "*****"
Too sharp a shock in
changing from D
3 to
D
4.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Control valve assemblyXX-XX, "*****"
OFF vehicle4. Brake bandXX-XX, "*****"5. Overrun clutchXX-XX, "*****"
6. Forward one-way clutchXX-XX, "*****"
Gear change shock
during deceleration by
releasing accelerator
pedal.ON vehicle1. Accelerator pedal position sensorEC-297
(Type 1),
EC-583
(Type 2)
2. Line pressure testTM-178
3. Overrun clutch solenoid valveTM-93
(Type 1),
XX-XX, "*****"

(Type 2)
4. Control valve assemblyXX-XX, "*****"
Large shock in chang-
ing from 1
2 to 11 in “1”
position.ON vehicle 1. Control valve assemblyXX-XX, "*****"OFF vehicle 2. Low & reverse brakeXX-XX, "*****"
Items Symptom Condition Diagnostic item Reference page
