Page 697 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-108 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] DOOR LOCK ACTUATOR DOOR LOCK ACTUATOR DRIVER SIDE DRIVER SIDE : DescriptionINFOID:0000000001507385 Locks/unlocks the door with the signa

Page 698 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK ACTUATOR DLK-109 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check continuity between BCM connector (A) M20 terminals 76, 77 and front door lo

Page 699 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-110 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] DOOR LOCK ACTUATOR 2. Check voltage between BCM connector M20 terminals 67, 77 and ground. Is the inspection result normal? YES >> GO TO

Page 700 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK ACTUATOR DLK-111 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P 2. Check continuity between BCM connector M19 terminals 67, 77 and ground. Is the in

Page 701 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-112 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] DOOR LOCK ACTUATOR 2.CHECK DOOR LOCK ACTUATOR HARNESS 1. Disconnect BCM and rear door lock actuator LH. 2. Check continuity between BCM

Page 702 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK ACTUATOR DLK-113 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P REAR RH : Diagnosis ProcedureINFOID:0000000001507393 1.CHECK DOOR LOCK ACTUATOR SIGN

Page 703 of 5883

NISSAN TIIDA 2007 Service Repair Manual DLK-114 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] DOOR LOCK ACTUATOR 2. Check continuity between BCM connector (A) M20 terminals 67, 77 and ground. Is the inspection result normal? YES

Page 704 of 5883

NISSAN TIIDA 2007 Service Repair Manual DOOR LOCK ACTUATOR DLK-115 < COMPONENT DIAGNOSIS >[WITH I-KEY, WITHOUT SUPER LOCK] C D E F G H I J L MA B DLK N O P Is the inspection result normal? YES >> GO TO 2. NO >> GO TO 4. 2.CHECK BACK DOOR LO
