NISSAN TIIDA 2007 Service Repair Manual MWI-54 < ECU DIAGNOSIS > COMBINATION METER DTC Index INFOID:0000000001374709 NOTE: “TIME” indicates the following.  0: Indicates that a malfunction is detected at present.  1-63: Indicates that

Page 4362 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-55 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P BCM (BODY CONTROL MODULE) Reference ValueINFOID:0000000001713119 VALUES ON THE DIAGNOSIS TOOL Monitor Item Condition

Page 4363 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-56 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) ENGINE RUNEngine stopped OFF Engine running ON ENGINE STATUS NOTE: Diesel engine models onlyEngine stopped STOP While the engine stalls STALL Engine

Page 4364 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-57 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 1: With Intelligent Key 2: With remote keyless entry system 3: HatchbackKEYLESS LOCK 2LOCK button of key fob is not

Page 4365 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-58 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) Terminal Layout INFOID:0000000001713120 TERMINAL LAYOUT Physical ValuesINFOID:0000000001713121 PHYSICAL VALUES CAUTION: ALMIA0185ZZ

Page 4366 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-59 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P  Check combination switch system terminal waveform under the loaded condition with lighting switch, turn signal swi

Page 4367 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI-60 < ECU DIAGNOSIS > BCM (BODY CONTROL MODULE) 7 (LG)GroundCombination switch INPUT 5InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.3V Front fog lamp switch ON (Wiper interm

Page 4368 of 5883

NISSAN TIIDA 2007 Service Repair Manual MWI BCM (BODY CONTROL MODULE) MWI-61 < ECU DIAGNOSIS > C D E F G H I J K L MB A O P 8 (V)GroundCombination switch INPUT 3InputCombination switchAll switch OFF (Wiper intermittent dial 4) 1.4V Lighti
