EC-1196
< COMPONENT DIAGNOSIS >[K9K]
P2263 TC SYSTEM
Check turbocharger.
Is the inspection result normal?
Yes >> Repair or replace.
No >> GO TO 6.
6.CHECK TURBOCHARGER BOOST CONTROL SOLENOID VALVE POWER SUPPLY CIRCUIT
1. Disconnect turbocharger boost control solenoid valve harness connector.
2. Turn ignition switch ON.
3. Check the voltage between turbocharger boost control solenoid valve harness connector and ground.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
7.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors E8, F8
Harness for open or short between IPDM E/R and turbocharger boost control solenoid valve
Harness for open or short between ECM and turbocharger boost control solenoid valve
>> Repair open circuit or short to ground or short to power in harness or connectors.
8.CHECK TURBOCHARGER BOOST CONTROL SOLENOID VALVE OUTPUT SIGNAL CIRCUIT FOR
OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between turbocharger boost control solenoid valve harness connector and ECM har-
ness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 10.
NO >> GO TO 9.
9.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors E8, F8
Harness for open or short between ECM and turbocharger boost control solenoid valve
>> Repair open circuit or short to ground or short to power in harness or connectors.
10.CHECK TURBOCHARGER BOOST CONTROL SOLENOID VALVE
Refer to EC-1117, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 11.
NO >> Replace turbocharger boost control solenoid valve.
11 .CHECK TURBOCHARGER BOOST SENSOR
Refer to EC-1119, "
Component Inspection".
Turbocharger boost control solenoid valve
Ground Voltage
Connector Terminal
E59 2 Ground Battery voltage
Turbocharger boost control solenoid valve ECM
Continuity
Connector Terminal Connector Terminal
E59 1 F11 52 Existed
Page 2546 of 5883
P2263 TC SYSTEM
EC-1197
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 12.
NO >> Replace turbocharger boost sensor.
12.CHECK THROTTLE CONTROL MOTOR
Refer to EC-1189, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace electric throttle control actuator.
13.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>>INSPECTION END
Page 2547 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-1198
< COMPONENT DIAGNOSIS >[K9K]
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
DTC LogicINFOID:0000000001162676
DTC DETECTION LOGIC
NOTE NISSAN TIIDA 2007 Service Repair Manual EC-1198
< COMPONENT DIAGNOSIS >[K9K]
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
DTC LogicINFOID:0000000001162676
DTC DETECTION LOGIC
NOTE](/manual-img/5/57395/w960_57395-2546.png)
EC-1198
< COMPONENT DIAGNOSIS >[K9K]
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
DTC LogicINFOID:0000000001162676
DTC DETECTION LOGIC
NOTE:
Special note:
The brake and accelerator pedals were detected as depressed simultaneously for 30 seconds.
If the DTC is present:
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162677
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK BRAKE SWITCH CIRCUIT
1. Turn ignition switch ON.
2. Check the voltage between ECM harness connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 10.
3.CHECK ACCELERATOR PEDAL POSITION SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect accelerator pedal position sensor harness connector.
3. Turn ignition switch ON.
4. Check the voltage between accelerator pedal position sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 5.
DTC No. Trouble diagnosis name Possible cause
P2299ACCELERATOR PEDAL/BRAKE PEDAL INCONSISTENCY
1.DEF: Inconsistency Harness or connectors
(APP sensor 1 and 2 circuit is open or
shorted.)
(Stop lamp switch circuit is open or short-
ed.)
Accelerator pedal position sensor
(APP sensor 1 and 2.)
Stop lamp switch
Accelerator pedal
+–
Condition Voltage
Connector Terminal Connector Terminal
E1611 5
(Brake switch)E16 128 Brake pedalFully released 0V
Slightly depressed Battery voltage
Accelerator pedal position sensor
Ground Voltage
Sensor Connector Terminal
1
E12 (LHD models)
M204 (RHD models)4
Ground Approx. 5V
25
Page 2548 of 5883
![NISSAN TIIDA 2007 Service Repair Manual P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
EC-1199
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD NISSAN TIIDA 2007 Service Repair Manual P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
EC-1199
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD](/manual-img/5/57395/w960_57395-2547.png)
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
EC-1199
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD models)
Harness connectors M25, M201 (RHD models)
Harness for open or short between ECM and accelerator pedal position sensor
>> Repair open circuit or short to ground or short to power in harness or connector.
5.CHECK ACCELERATOR PEDAL POSITION SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between accelerator pedal position sensor harness connector and ECM harness
connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
6.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD models)
Harness connectors M25, M201 (RHD models)
Harness for open or short between ECM and accelerator pedal position sensor
>> Repair open circuit or short to ground or short to power in harness or connector.
7.CHECK ACCELERATOR PEDAL POSITION SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between accelerator pedal position sensor harness connector and ECM harness
connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 9.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD models)
Harness connectors M25, M201 (RHD models)
Harness for open or short between ECM and accelerator pedal position sensor
>> Repair open circuit or short to ground or short to power in harness or connector.
9.CHECK ACCELERATOR PEDAL POSITION SENSOR
Refer to EC-1146, "
Component Inspection".
Is the inspection result normal?
Accelerator pedal position sensor ECM
Continuity
Sensor Connector Terminal Connector Terminal
1
E12 (LHD models)
M204 (RHD models)2
E16127
Existed
21120
Accelerator pedal position sensor ECM
Continuity
Sensor Connector Terminal Connector Terminal
1
E12 (LHD models)
M204 (RHD models)3
E16126
Existed
26119
Page 2549 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-1200
< COMPONENT DIAGNOSIS >[K9K]
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
YES >> GO TO 15.
NO >> Replace accelerator pedal position sensor.
10.CHECK BRAKE SWITCH POWER SUPPLY CIRCUIT
1 NISSAN TIIDA 2007 Service Repair Manual EC-1200
< COMPONENT DIAGNOSIS >[K9K]
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
YES >> GO TO 15.
NO >> Replace accelerator pedal position sensor.
10.CHECK BRAKE SWITCH POWER SUPPLY CIRCUIT
1](/manual-img/5/57395/w960_57395-2548.png)
EC-1200
< COMPONENT DIAGNOSIS >[K9K]
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
YES >> GO TO 15.
NO >> Replace accelerator pedal position sensor.
10.CHECK BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between stop lamp switch harness connector and ground.
Is the inspection result normal?
YES >> GO TO 12.
NO >> GO TO 11.
11 .DETECT MALFUNCTIONING PART
Check the following.
Harness connectors M69, E7 (LHD models)
Harness connectors M25, M201 (RHD models)
10A fuse (No. 7)
Harness for open or short between fuse and stop lamp switch
>> Repair open circuit or short to ground or short to power in harness or connectors.
12.CHECK BRAKE SWITCH INPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between stop lamp switch harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 14.
NO >> GO TO 13.
13.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors M69, E7 (RHD models)
Harness connectors M25, M201 (RHD models)
10A fuse (No. 7)
Harness for open or short between fuse and stop lamp switch
>> Repair open circuit or short to ground or short to power in harness or connectors.
14.CHECK STOP LAMP SWITCH
Refer to EC-1215, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 15.
NO >> Replace stop lamp switch.
15.CHECK ACCELERATOR PEDAL
Stop lamp switch
Ground Voltage
Connector Terminal
E13 (LHD models)
M203 (RHD models)1 Ground Battery voltage
Stop lamp switch ECM
Continuity
Connector Terminal Connector Terminal
E13 (LHD models)
M203 (RHD models)2 E16 115 Existed
Page 2550 of 5883
P2299 ACCELERATOR/BRAKE PEDAL POSITION INCONSISTENCY
EC-1201
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Refer to EC-1146, "Component Inspection".
Is the inspection result normal?
YES >> GO TO 16.
NO >> Replace accelerator pedal position sensor.
16.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Page 2551 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-1202
< COMPONENT DIAGNOSIS >[K9K]
P2413 EGR SYSTEM
P2413 EGR SYSTEM
DTC LogicINFOID:0000000001162678
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
NISSAN TIIDA 2007 Service Repair Manual EC-1202
< COMPONENT DIAGNOSIS >[K9K]
P2413 EGR SYSTEM
P2413 EGR SYSTEM
DTC LogicINFOID:0000000001162678
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:](/manual-img/5/57395/w960_57395-2550.png)
EC-1202
< COMPONENT DIAGNOSIS >[K9K]
P2413 EGR SYSTEM
P2413 EGR SYSTEM
DTC LogicINFOID:0000000001162678
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC becomes present after the engine is started.
Special notes:
- Engine instability, possibly even stalling.
- Difficult to start engine or even impossible when cold.
- Loss of performance.
- Possible smoke emissions.
If the DTC is present:
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162679
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK EGR VOLUME CONTROL VALVE INSTALLATION
Check that EGR volume control valve is installed properly.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Install EGR volume control valve properly.
3.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR POWER SUPPLY CIRCUIT
1. Disconnect EGR volume control valve harness connector.
2. Turn ignition switch ON.
3. Check the voltage between EGR volume control valve control position sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR GROUND CIRCUIT FOR
DTC No. Trouble diagnosis name Possible cause
P2413EGR VOLUME CONTROL
1.DEF: Jammed component Harness or connectors
(The EGR volume control valve circuit is open
or shorted.)
(The EGR volume control valve control posi-
tion sensor circuit is open or shorted.)
EGR volume control valve
EGR volume control valve control position
sensor
Incorrect EGR volume control valve installa-
tion
EGR volume control valve stuck closed
EGR passage clogged
GR volume control valve control position sensor
Ground Voltage
Connector Terminal
F52 1 Ground Approx. 5V
Page 2552 of 5883
![NISSAN TIIDA 2007 Service Repair Manual P2413 EGR SYSTEM
EC-1203
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between E NISSAN TIIDA 2007 Service Repair Manual P2413 EGR SYSTEM
EC-1203
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between E](/manual-img/5/57395/w960_57395-2551.png)
P2413 EGR SYSTEM
EC-1203
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between EGR volume control valve control position sensor harness connector and
ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK EGR VOLUME CONTROL VALVE CONTROL POSITION SENSOR INPUT CIRCUIT FOR OPEN
AND SHORT
1. Check the continuity between EGR volume control valve control position sensor harness connector and
ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
6.CHECK EGR VOLUME CONTROL VALVE CONTROL MOTOR CIRCUIT
1. Check harness continuity between the following terminals.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
7.CHECK EGR VOLUME CONTROL VALVE VISUALLY
1. Remove the EGR volume control valve
2. Check if foreign matter is caught between the EGR volume control valve and the housing.
Is the inspection result normal?
YES >> GO TO 8.
NO >> Remove the foreign matter and clean the EGR volume control valve.
8.CHECK EGR PASSAGE
Check the following for clogging and cracks.
EGR tube
EGR volume control valve control posi-
tion sensorECM
Continuity
Connector Terminal Connector Terminal
F52 3 F11 82 Existed
EGR volume control valve control posi-
tion sensorECM
Continuity
Connector Terminal Connector Terminal
F52 5 F11 86 Existed
EGR volume control valve ECM
Continuity
Connector Terminal Connector Terminal
F522
F1195 Existed
96 Not existed
695 Not existed
96 Existed
