2007 NISSAN TIIDA Service Repair Manual

fog lightnight visionhood releasecoolingECUinfotainment
Popular search:
fog light bulbwiper fluidtire sizeparking brakeground clearanceip pulley speedfront cowl
Previous
Next
Load previous 8 pages

Page 5553 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY TM-607 < DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P 16. Install differential side bearing adjusting shim selected in differ- ential side bearing end pla

Page 5554 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-608 < DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)] ASSEMBLY Completely remove all moisture, oil and old sealant, etc. from the transaxle case and converter housing mating surfaces. 22. Install

Page 5555 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY TM-609 < DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P 30. Install control valve assembly on transaxle case. a. Install O-ring on terminal body. CAUTION:

Page 5556 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-610 < DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)] ASSEMBLY b. Install oil pan gasket on transaxle case. CAUTION:  Completely remove all moisture, oil and old gasket, etc. from the oil pan ga

Page 5557 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASSEMBLY TM-611 < DISASSEMBLY AND ASSEMBLY >[TYPE 2 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P Ensure revolution sensor harness is firmly secured with bolt. (1): Revolution sensor : Bolt 38. Inst

Page 5558 of 5883

NISSAN TIIDA 2007 Service Repair Manual TM-612 < SERVICE DATA AND SPECIFICATIONS (SDS) [TYPE 2 (4AT: RE4F03B)] SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) SERVICE DATA AND SPECIFICATIONS (SDS) General Specifi

Page 5559 of 5883

NISSAN TIIDA 2007 Service Repair Manual SERVICE DATA AND SPECIFICATIONS (SDS) TM-613 < SERVICE DATA AND SPECIFICATIONS (SDS) [TYPE 2 (4AT: RE4F03B)] C E F G H I J K L MA B TM N O P Adjusting shims, Needle Bearings, Thrust Washers and Snap R
