NISSAN TIIDA 2007 Service Repair Manual EC-1140
< COMPONENT DIAGNOSIS >[K9K]
P0200 FUEL INJECTOR
P0200 FUEL INJECTOR
DTC LogicINFOID:0000000001162596
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored

Page 2490 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0200 FUEL INJECTOR
EC-1141
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
YES >> GO TO 4.
NO >> Replace malfunctioning fuel injector.
4.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Int

Page 2491 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1142
< COMPONENT DIAGNOSIS >[K9K]
P0201, P0202, P0203, P0204 FUEL INJECTOR
P0201, P0202, P0203, P0204 FUEL INJECTOR
DTC LogicINFOID:0000000001162599
DTC DETECTION LOGIC
NOTE:
Conditions for applyi

EC-1142
< COMPONENT DIAGNOSIS >[K9K]
P0201, P0202, P0203, P0204 FUEL INJECTOR
P0201, P0202, P0203, P0204 FUEL INJECTOR
DTC LogicINFOID:0000000001162599
DTC DETECTION LOGIC
NOTE:
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present after the engine has been started.
If the DTC is present:
-Malfunction indicator (Red) lights up.
-Malfunction indicator (Yellow) lights up.
Diagnosis ProcedureINFOID:0000000001162600
1.CHECK FUEL INJECTOR POWER SUPPLY CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Disconnect fuel injector harness connector.
4. Check the continuity between fuel injector harness connector and ECM harness connector.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
2.CHECK FUEL INJECTOR OUTPUT CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between fuel injector harness connector and ECM harness connector.
DTC No. Trouble diagnosis name Possible cause
P0201NO. 1 CYLINDER FUEL INJECTOR CIRCUIT
CO: Open circuit
CC: Short circuit
1.DEF: Line in open circuit
2.DEF: Open circuit or internal electronic malfunction
Harness or connectors
(The fuel injector circuit is open or
shorted.)
Fuel injector P0202NO. 2 CYLINDER FUEL INJECTOR CIRCUIT
CO: Open circuit
CC: Short circuit
1.DEF: Line in open circuit
2.DEF: Open circuit or internal electronic malfunction
P0203NO. 3 CYLINDER FUEL INJECTOR CIRCUIT
CO: Open circuit
CC: Short circuit
1.DEF: Line in open circuit
2.DEF: Open circuit or internal electronic malfunction
P0204NO. 4 CYLINDER FUEL INJECTOR CIRCUIT
CO: Open circuit
CC: Short circuit
1.DEF: Line in open circuit
2.DEF: Open circuit or internal electronic malfunction
Fuel injector ECM
Continuity
Cylinder Connector Terminal Connector Terminal
1F17 1F108
Existed 2F18 1F107
3F19 1F106
4F20 1F105

Page 2492 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0201, P0202, P0203, P0204 FUEL INJECTOR
EC-1143
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
2. Also check harness for short to ground and short to power.
Is the inspection result no

Page 2493 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1144
< COMPONENT DIAGNOSIS >[K9K]
P0225 APP SENSOR
P0225 APP SENSOR
DescriptionINFOID:0000000001162604
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal a

EC-1144
< COMPONENT DIAGNOSIS >[K9K]
P0225 APP SENSOR
P0225 APP SENSOR
DescriptionINFOID:0000000001162604
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensors detect the accelera-
tor pedal position and sends a signal to the ECM. The ECM uses the
signal to determine the amount of fuel to be injected.
DTC LogicINFOID:0000000001162605
DTC DETECTION LOGIC
NOTE:
If DTC P0225 is displayed with DTC P0641, first perform trouble diagnosis for DTC P0641. Refer to
EC-1180, "
DTC Logic".
If DTC P0225 is displayed with DTC P0651, first perform trouble diagnosis for DTC P0651. Refer to
EC-1182, "
DTC Logic".
If DTC P2120 is present at the same time, check that the APP sensor connector is connected cor-
rectly.
Conditions for applying the diagnostic procedure to the stored DTCs:
- The DTC is declared present after a series of full load/no load action on the accelerator.
If the DTC is present:
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162606
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK ACCELERATOR PEDAL POSITION SENSOR POWER SUPPLY CIRCUIT
1. Disconnect accelerator pedal position sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between accelerator pedal position sensor connector and ground.
PBIB1741E
DTC No. Trouble diagnosis name Possible cause
P0225ACCELERATOR PEDAL POSITION SENSOR 1 AND ACCELERATOR
PEDAL POSITION SENSOR 2 CIRCUIT
CC.1: Short circuit to +12V
1.DEF: Signal incoherence
2.DEF: No signal
CO.0: Open circuit or short circuit to ground Harness or connectors
(APP sensor 1 and 2 circuit is open or
shorted.)
Accelerator pedal position sensor
(APP sensor 1 and 2.)
Accelerator pedal position sensor
Ground Voltage
Sensor Connector Terminal
1
E12 (LHD models)
M204 (RHD models)4
Ground Approx. 5V
25

Page 2494 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0225 APP SENSOR
EC-1145
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Harness connectors

P0225 APP SENSOR
EC-1145
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Is the inspection result normal?
YES >> GO TO 4.
NO >> GO TO 3.
3.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD models)
Harness connectors M25, M201 (RHD models)
Harness for open or short between ECM and accelerator pedal position sensor
>> Repair open circuit or short to ground or short to power in harness or connector.
4.CHECK ACCELERATOR PEDAL POSITION SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between accelerator pedal position sensor harness connector and ECM harness
connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 6.
NO >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD models)
Harness connectors M25, M201 (RHD models)
Harness for open or short between ECM and accelerator pedal position sensor
>> Repair open circuit or short to ground or short to power in harness or connector.
6.CHECK ACCELERATOR PEDAL POSITION SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between accelerator pedal position sensor harness connector and ECM harness
connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 8.
NO >> GO TO 7.
7.DETECT MALFUNCTIONING PART
Harness connectors E7, M69 (RHD models)
Harness connectors M25, M201 (RHD models)
Harness for open or short between ECM and accelerator pedal position sensor
>> Repair open circuit or short to ground or short to power in harness or connector.
8.CHECK ACCELERATOR PEDAL POSITION SENSOR
Refer to EC-1146, "
Component Inspection".
Accelerator pedal position sensor ECM
Continuity
Sensor Connector Terminal Connector Terminal
1
E12 (LHD models)
M204 (RHD models)2
E16127
Existed
21120
Accelerator pedal position sensor ECM
Continuity
Sensor Connector Terminal Connector Terminal
1
E12 (LHD models)
M204 (RHD models)3
E16126
Existed
26119

Page 2495 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-1146
< COMPONENT DIAGNOSIS >[K9K]
P0225 APP SENSOR
Is the inspection result normal?
YES >> GO TO 9.
NO >> Replace accelerator pedal position sensor.
9.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "

Page 2496 of 5883

NISSAN TIIDA 2007 Service Repair Manual P0235 TC BOOST SENSOR
EC-1147
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0235 TC BOOST SENSOR
DescriptionINFOID:0000000001162608
The turbocharger boost sensor detects pressure in th

P0235 TC BOOST SENSOR
EC-1147
< COMPONENT DIAGNOSIS >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
P0235 TC BOOST SENSOR
DescriptionINFOID:0000000001162608
The turbocharger boost sensor detects pressure in the exit side of the charge air cooler. The sensor output
voltage to the ECM increases as pressure increases.
DTC LogicINFOID:0000000001162609
DTC DETECTION LOGIC
NOTE:
If DTC P0235 is displayed with DTC P0651, first perform trouble diagnosis for DTC P0651. Refer to
EC-1182, "
DTC Logic".
Conditions for applying the diagnostic procedure to the stored DTCs:
The DTC is declared present after the ignition has been switched on for 1 second, with a warm engine when
the vehicle is stationary.
If the DTC is present:
-Malfunction indicator (Red) lights up.
Diagnosis ProcedureINFOID:0000000001162610
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace ground connection.
2.CHECK TUBOCHARGER BOOST SENSOR SUPPLY CIRCUIT
1. Disconnect turbocharger boost sensor harness connector.
2. Turn ignition switch ON.
3. Check the voltage between turbocharger boost sensor connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK TUBOCHARGER BOOST SENSOR GROUND CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between turbocharger boost sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
DTC No. Trouble diagnosis name Possible cause
P0235 CC.1: short circuit to +12V
CO.0: Open circuit or Short circuit to ground
1.DEF: Micro-breaks
2.DEF: Signal outside lower level
3.DEF: Signal outside upper level Harness or connectors
(Turbocharger boost sensor circuit is
open or shorted.)
Turbocharger boost sensor
Turbocharger boost sensor
Ground Voltage
Connector Terminal
F50 1 Ground Approx. 5V
Turbocharger boost sensor ECM
Continuity
Connector Terminal Connector Terminal
F50 2 F10 43 Existed
