Page 2297 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-948
< COMPONENT DIAGNOSIS >[MR18DE]
P2122, P2123 APP SENSOR
P2122, P2123 APP SENSOR
DescriptionINFOID:0000000001161933
The accelerator pedal position sensor is installed on the upper end
of the acc

EC-948
< COMPONENT DIAGNOSIS >[MR18DE]
P2122, P2123 APP SENSOR
P2122, P2123 APP SENSOR
DescriptionINFOID:0000000001161933
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The ECM uses this signal for the engine oper-
ation such as fuel cut.
DTC LogicINFOID:0000000001161934
DTC DETECTION LOGIC
NOTE:
If DTC P2122 or P2123 is displayed with DTC P1229, first perform the trouble diagnosis for DTC P1229.
Refer to EC-928, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-948, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001161935
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
PBIB1741E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2122Accelerator pedal posi-
tion sensor 1 circuit low
inputAn excessively low voltage from the APP sen-
sor 1 is sent to ECM. Harness or connectors
(APP sensor 1 circuit is open or shorted.)
Accelerator pedal position sensor
(APP sensor 1)
P2123Accelerator pedal posi-
tion sensor 1 circuit high
inputAn excessively high voltage from the APP sen-
sor 1 is sent to ECM.

Page 2298 of 5883

NISSAN TIIDA 2007 Service Repair Manual P2122, P2123 APP SENSOR
EC-949
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 1 POWER SUPPLY CIRCUIT
1. Disconnect accele

Page 2299 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-950
< COMPONENT DIAGNOSIS >[MR18DE]
P2122, P2123 APP SENSOR
7.DETECT MALFUNCTIONING PART
Check the following.
Harness conector E7, M69, M25, M201 (RHD models)
Harness for open or short between

Page 2300 of 5883

NISSAN TIIDA 2007 Service Repair Manual P2122, P2123 APP SENSOR
EC-951
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
>> GO TO 2.
2.PERFORM THROTTLE VALVE CLOSED POSITION LEARNING
Refer to EC-694, "
THROTTLE VALVE CLOSED PO

Page 2301 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-952
< COMPONENT DIAGNOSIS >[MR18DE]
P2127, P2128 APP SENSOR
P2127, P2128 APP SENSOR
DescriptionINFOID:0000000001161938
The accelerator pedal position sensor is installed on the upper end
of the acc

EC-952
< COMPONENT DIAGNOSIS >[MR18DE]
P2127, P2128 APP SENSOR
P2127, P2128 APP SENSOR
DescriptionINFOID:0000000001161938
The accelerator pedal position sensor is installed on the upper end
of the accelerator pedal assembly. The sensor detects the accelera-
tor position and sends a signal to the ECM.
Accelerator pedal position sensor has two sensors. These sensors
are a kind of potentiometers which transform the accelerator pedal
position into output voltage, and emit the voltage signal to the ECM.
In addition, these sensors detect the opening and closing speed of
the accelerator pedal and feed the voltage signals to the ECM. The
ECM judges the current opening angle of the accelerator pedal from
these signals and controls the throttle control motor based on these
signals.
Idle position of the accelerator pedal is determined by the ECM
receiving the signal from the accelerator pedal position sensor. The ECM uses this signal for the engine oper-
ation such as fuel cut.
DTC LogicINFOID:0000000001161939
DTC DETECTION LOGIC
DTC CONFIRMATION PROCEDURE
1.PRECONDITIONING
If DTC Confirmation Procedure has been previously conducted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
TESTING CONDITION:
Before performing the following procedure, confirm that battery voltage is more than 8V at idle.
>> GO TO 2.
2.PERFORM DTC CONFIRMATION PROCEDURE
1. Start engine and let it idle for 1 second.
2. Check DTC.
Is DTC detected?
YES >> Go to EC-952, "Diagnosis Procedure".
NO >> INSPECTION END
Diagnosis ProcedureINFOID:0000000001161940
1.CHECK GROUND CONNECTION
1. Turn ignition switch OFF.
2. Check ground connection E15. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 2.
PBIB1741E
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P2127Accelerator pedal posi-
tion sensor 2 circuit low
inputAn excessively low voltage from the APP sen-
sor 2 is sent to ECM. Harness or connectors
(APP sensor 2 circuit is open or shorted.)
[Crankshaft position sensor (POS) circuit
is shorted.]
(Refrigerant pressure sensor circuit is
shorted.)
Accelerator pedal position sensor
(APP sensor 2)
Crankshaft position sensor (POS)
Refrigerant pressure sensor P2128Accelerator pedal posi-
tion sensor 2 circuit high
inputAn excessively high voltage from the APP sen-
sor 2 is sent to ECM.

Page 2302 of 5883

NISSAN TIIDA 2007 Service Repair Manual P2127, P2128 APP SENSOR
EC-953
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
NO >> Repair or replace ground connection.
2.CHECK APP SENSOR 2 POWER SUPPLY CIRCUIT-I
1. Disconnect acce

Page 2303 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-954
< COMPONENT DIAGNOSIS >[MR18DE]
P2127, P2128 APP SENSOR
7.CHECK COMPONENTS
Check the following.
Crankshaft position sensor (POS) (Refer to EC-865, "
Component Inspection".)
Refrigerant pres

Page 2304 of 5883

NISSAN TIIDA 2007 Service Repair Manual P2127, P2128 APP SENSOR
EC-955
< COMPONENT DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
13.REPLACE ACCELERATOR PEDAL ASSEMBLY
1. Replace accelerator pedal assembly.
2. Go to EC-955, "
Special R
