EC-308
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN
>> Repair or replace malfunctioning part.
3.CHECK COOLING FAN MOTORS CIRCUIT FOR OPEN AND SHORT
1. Disconnect cooling fan motor harness connector.
2. Check the continuity between IPDM E/R harness connector and cooling fan motor harness connector.
3. Check the continuity between cooling fan motor harness connector or IPDM E/R harness connector and
ground.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between cooling fan motor and IPDM E/R
Harness for open or short between cooling fan motor and ground
Harness for open or short between IPDM E/R and ground
Resistor E5
>> Repair or replace malfunctioning part.
5.CHECK COOLING FAN MOTORS CIRCUIT FOR OPEN AND SHORT
1. Disconnect cooling fan motor harness connector.
2. Check the continuity between IPDM E/R harness connector and cooling fan motor harness connector.
3. Check the continuity between cooling fan motor harness connector or IPDM E/R harness connector and
ground.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 7.
NO >> GO TO 6.
IPDM E/R Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E44 24
E3 1 Existed
E45 30
Cooling fan motor IPDM E/R
Ground Continuity
Connector Terminal Connector Terminal
E3 2 E4659
Ground Existed
39
IPDM E/R Cooling fan motor
Continuity
Connector Terminal Connector Terminal
E4423
E31
Existed 24 2
E45 30 3
Cooling fan motor IPDM E/R
Ground Continuity
Connector Terminal Connector Terminal
E3 4 E4659
Ground Existed
39
Page 1658 of 5883
![NISSAN TIIDA 2007 Service Repair Manual COOLING FAN
EC-309
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
6.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between cooling fan mot NISSAN TIIDA 2007 Service Repair Manual COOLING FAN
EC-309
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
6.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between cooling fan mot](/manual-img/5/57395/w960_57395-1657.png)
COOLING FAN
EC-309
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
6.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between cooling fan motor and IPDM E/R
Harness for open or short between cooling fan motor and ground
Harness for open or short between IPDM E/R and ground
>> Repair or replace malfunctioning part.
7.CHECK GROUND CONNECTION
Check ground connection E24. Refer to Ground Inspection in GI-58, "
Circuit Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Repair or replace ground connection.
8.CHECK COOLING FAN MOTOR
Refer to EC-309, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 9.
NO >> Replace malfunctioning cooling fan motor.
9.CHECK INTERMITTENT INCIDENT
Perform GI-55, "
Intermittent Incident".
Is the inspection result normal?
YES >> Replace IPDM E/R.
NO >> Repair or replace harness or connector.
Component InspectionINFOID:0000000001677300
1.CHECK OVERALL FUNCTION
Check if the vehicle is equipped with an air conditioner.
Is it equipped with an air conditioner?
YES >> GO TO 2.
NO >> GO TO 3.
2.CHECK COOLING FAN MOTOR
1. Turn ignition switch OFF.
2. Disconnect cooling fan motor harness connector.
3. Supply cooling fan motor terminals with battery voltage and check operation.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan motor.
3.CHECK COOLING FAN MOTOR
1. Turn ignition switch OFF.
2. Disconnect cooling fan motor harness connector.
3. Supply cooling fan motor terminals with battery voltage and check operation.
Te r m i n a l s
Operation
(+) (–)
1 2 Cooling fan operates.
Page 1659 of 5883
EC-310
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
COOLING FAN
Is the inspection result normal?
YES >> INSPECTION END
NO >> Replace cooling fan motor.
Te r m i n a l s
Operation
(+) (–)
14
Cooling fan operates at low speed.
23
1 and 2 3 and 4 Cooling fan operates at high speed.
Page 1660 of 5883
![NISSAN TIIDA 2007 Service Repair Manual ELECTRICAL LOAD SIGNAL
EC-311
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000001671096
The electrical load signal (Head NISSAN TIIDA 2007 Service Repair Manual ELECTRICAL LOAD SIGNAL
EC-311
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000001671096
The electrical load signal (Head](/manual-img/5/57395/w960_57395-1659.png)
ELECTRICAL LOAD SIGNAL
EC-311
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
ELECTRICAL LOAD SIGNAL
DescriptionINFOID:0000000001671096
The electrical load signal (Headlamp switch signal, rear window defogger switch signal, etc.) is transferred
through the CAN communication line from BCM to ECM via IPDM E/R.
Component Function CheckINFOID:0000000001671097
1.CHECK REAR WINDOW DEFOGGER SWITCH FUNCTION
1. Turn ignition switch ON.
2. Connect CONSULT-III and select “DATA MONITOR” mode.
3. Select “LOAD SIGNAL” and check indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Go to EC-311, "
Diagnosis Procedure".
2.CHECK LIGHTING SWITCH FUNCTION
Check “LOAD SIGNAL” indication under the following conditions.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Go to EC-311, "
Diagnosis Procedure".
3.CHECK HEATER FAN CONTROL SWITCH FUNCTION
Select “HEATER FAN SW” and check indication under the following conditions.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-311, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001671098
1.INSPECTION START
Confirm the malfunctioning circuit (rear window defogger, headlamp or heater fan). Refer to EC-311, "
Compo-
nent Function Check".
Which circuit is related to the incident?
Rear window defogger>>GO TO 2
Headlamp>>GO TO 3.
Heater fan>>GO TO 4.
2.CHECK REAR WINDOW DEFOGGER SYSTEM
Refer to DEF-6, "
System Diagram".
Monitor item Condition Indication
LOAD SIGNAL Rear window defogger switchON ON
OFF OFF
Monitor item Condition Indication
LOAD SIGNAL Lighting switchON at 2nd position ON
OFF OFF
Monitor item Condition Indication
HEATER FAN SW Heater fan control switchON ON
OFF OFF
Page 1661 of 5883
EC-312
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
ELECTRICAL LOAD SIGNAL
>> INSPECTION END
3.CHECK HEADLAMP SYSTEM
Refer to EXL-10, "
System Diagram" (XENON TYPE) or EXL-8, "System Diagram" (HALOGEN TYPE).
>> INSPECTION END
4.CHECK HEATER FAN CONTROL SYSTEM
Refer to HAC-118, "
System Description" (without NAVI system) or HAC-232, "System Description" (with NAVI
system).
>> INSPECTION END
Page 1662 of 5883
![NISSAN TIIDA 2007 Service Repair Manual FUEL INJECTOR
EC-313
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
FUEL INJECTOR
DescriptionINFOID:0000000001671099
The fuel injector is a small, precise solenoid val NISSAN TIIDA 2007 Service Repair Manual FUEL INJECTOR
EC-313
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
FUEL INJECTOR
DescriptionINFOID:0000000001671099
The fuel injector is a small, precise solenoid val](/manual-img/5/57395/w960_57395-1661.png)
FUEL INJECTOR
EC-313
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
FUEL INJECTOR
DescriptionINFOID:0000000001671099
The fuel injector is a small, precise solenoid valve. When the ECM
supplies a ground to the fuel injector circuit, the coil in the fuel injec-
tor is energized. The energized coil pulls the ball valve back and
allows fuel to flow through the fuel injector into the intake manifold.
The amount of fuel injected depends upon the injection pulse dura-
tion. Pulse duration is the length of time the fuel injector remains
open. The ECM controls the injection pulse duration based on
engine fuel needs.
Component Function CheckINFOID:0000000001671100
1.INSPECTION START
Turn ignition switch to START.
Is any cylinder ignited?
YES >> GO TO 2.
NO >> Go to EC-313, "
Diagnosis Procedure".
2.CHECK FUEL INJECTOR FUNCTION
With CONSULT-III
1. Start engine.
2. Perform “POWER BALANCE” in “ACTIVE TEST” mode with CONSULT-III.
3. Make sure that each circuit produces a momentary engine speed drop.
Without CONSULT-III
1. Let engine idle.
2. Listen to each fuel injector operating sound.
Is the inspection result normal?
YES >> INSPECTION END
NO >> Go to EC-313, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001671101
1.CHECK FUEL INJECTOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector.
3. Turn ignition switch ON.
4. Check the voltage between fuel injector harness connector and ground.
PBIA9664J
Clicking noise should be heard.
PBIB3332E
Page 1663 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EC-314
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
FUEL INJECTOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Harness connect NISSAN TIIDA 2007 Service Repair Manual EC-314
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
FUEL INJECTOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Harness connect](/manual-img/5/57395/w960_57395-1662.png)
EC-314
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
FUEL INJECTOR
Is the inspection result normal?
YES >> GO TO 3.
NO >> GO TO 2.
2.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors F8, E8
10A fuse (No. 55)
Harness for open or short between fuel injector and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
3.CHECK FUEL INJECTOR OUTPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between fuel injector harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK FUEL INJECTOR
Refer to EC-314, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 5.
NO >> Replace malfunctioning fuel injector.
5.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001671102
1.CHECK FUEL INJECTOR
1. Turn ignition switch OFF.
2. Disconnect fuel injector harness connector.
3. Check resistance between fuel injector terminals as follows.
Fuel injector
Ground Voltage
Cylinder Connector Terminal
1F17 1
Ground Battery voltage 2F18 1
3F19 1
4F20 1
Fuel injector ECM
Continuity
Cylinder Connector Terminal Connector Terminal
1F17 2
F1031
Existed 2F18 2 30
3F19 2 29
4F20 2 25
Page 1664 of 5883
FUEL INJECTOR
EC-315
< COMPONENT DIAGNOSIS >[HR16DE (WITH EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P OIs the inspection result normal?
YES >> INSPECTION END
NO >> Replace malfunctioning fuel injector.
Terminals Resistance [at 10 - 60°C (50 - 140°F)]
1 and 2 11.1 - 14.5Ω
