EC-1148
< COMPONENT DIAGNOSIS >[K9K]
P0235 TC BOOST SENSOR
YES >> GO TO 4.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK TUBOCHARGER BOOST SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Check the continuity between turbocharger boost sensor harness connector and ECM harness connector.
2. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK TUBOCHARGER BOOST SENSOR
Refer to EC-1148, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 6.
NO >> Replace turbocharger boost sensor.
6.CHECK INTERMITTENT INCIDENT
Refer to GI-55, "
Intermittent Incident".
>> INSPECTION END
Component InspectionINFOID:0000000001162611
1.CHECK TURBOCHARGER BOOST SENSOR-I
1. Turn ignition switch OFF.
2. Remove turbocharger boost sensor with its harness connected.
3. Turn ignition switch ON.
4. Select “DATA MONITOR” mode with CONSULT-III.
5. Check “BOOST PRESS” and “ATOMOS PRESS” indication.
If the value is not very close to
“ATOMOS PRESS”, maximum pressure difference between “ATOMOS
PRESS” and “BOOST PRESS” with the ignition switch ON (engine stop) = ± 50 mbar?
YES >> GO TO 2.
NO >> Replace turbocharger boost sensor.
2.CHECK TURBOCHARGER BOOST SENSOR-II
1. Use pump to apply turbocharger boost sensor as shown in the
figure.
2. Apply a pressure of between 10 kPa(0.100 bar, 0.102 kg/cm
2,
1.5 psi) - 13 kPa(0.130 bar, 0.133 kg/cm
2, 1.9 psi) [maximum
pressure to be applied: 13 kPa(0.130 bar, 0.133 kg/cm
2, 1.9
psi)].
3. Select “DATA MONITOR” mode with CONSULT-III.
4. Check “BOOST PRESS” indication with that given by the vac-
uum pump.
If there is no discrepancy?
YES >> INSPECTION END
NO >> Replace turbocharger boost sensor.
Turbocharger boost sensor ECM
Continuity
Connector Terminal Connector Terminal
F50 3 F10 44 Existed
JMBIA0433ZZ
