Page 1937 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-588
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ASCD BRAKE SWITCH
ASCD BRAKE SWITCH
DescriptionINFOID:0000000001693416
When the brake pedal is depressed, ASCD brake switch is turned OFF and

Page 1938 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASCD BRAKE SWITCH
EC-589
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Check the following.
Harness connectors M69, E7 (LHD models)
Harness connectors M25, M20

ASCD BRAKE SWITCH
EC-589
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
Check the following.
Harness connectors M69, E7 (LHD models)
Harness connectors M25, M201 (RHD models)
10A fuse (No. 2)
Harness for open or short between ASCD brake switch and fuse
>> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK ASCD BRAKE SWITCH INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT
1. Turn ignition switch OFF.
2. Disconnect ECM harness connector.
3. Check the continuity between ASCD brake switch harness connector and ECM harness connector.
4. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 5.
NO >> Repair open circuit or short to ground or short to power in harness or connectors.
5.CHECK ASCD BRAKE SWITCH
Refer to EC-591, "
Component Inspection (ASCD Brake Switch)".
Is the inspection result normal?
YES >> GO TO 13.
NO >> Replace ASCD brake switch.
6.CHECK ASCD CLUCH SWITCH CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD cluch switch harness connector.
3. Turn ignition switch ON.
4. Check the continuity between ASCD cluch switch harness connector and ground.
5. Also check harness for short to ground and short to power.
Is the inspection result normal?
YES >> GO TO 11.
NO >> GO TO 7.
7.CHECK ASCD BRAKE SWITCH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect ASCD brake switch harness connector.
3. Turn ignition switch ON.
4. Check the voltage between ASCD brake switch harness connector and ground.
Is the inspection result normal?
ASCD brake switch ECM
Continuity
Connector Terminal Connector Terminal
E36 (LHD models)
M205 (RHD models)2 E16 100 Existed
ASCD cluch switch
Ground Condition Voltage (V)
Connector Terminal
E35 (LHD models)
M206 (RHD models)1 Ground Brake pedalSlightly depressed Approx. 0
Fully released Battery voltage
ASCD brake switch
Ground Voltage
Connector Terminal
E36 (LHD models)
M205 (RHD models)1 Ground Battery voltage

Page 1939 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-590
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ASCD BRAKE SWITCH
YES >> GO TO 9.
NO >> GO TO 8.
8.DETECT MALFUNCTIONING PART
Check the following.
Harness connector M69,E7 (LHD models)
H

Page 1940 of 5883

NISSAN TIIDA 2007 Service Repair Manual ASCD BRAKE SWITCH
EC-591
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
>> INSPECTION END
Component Inspection (ASCD Brake Switch)INFOID:0000000001693419
1.CHECK AS

Page 1941 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-592
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
ASCD INDICATOR
ASCD INDICATOR
DescriptionINFOID:0000000001693421
ASCD indicator lamp illuminates to indicate ASCD operation status. Lamp has t

Page 1942 of 5883

NISSAN TIIDA 2007 Service Repair Manual COOLING FAN
EC-593
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
COOLING FAN
DescriptionINFOID:0000000001693424
Cooling fan operates at each speed when the current

Page 1943 of 5883

NISSAN TIIDA 2007 Service Repair Manual EC-594
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
COOLING FAN
>> Repair or replace malfunctioning part.
3.CHECK COOLING FAN MOTORS CIRCUIT FOR OPEN AND SHORT
1. Disconnect cooling fan motor ha

Page 1944 of 5883

NISSAN TIIDA 2007 Service Repair Manual COOLING FAN
EC-595
< COMPONENT DIAGNOSIS >[HR16DE (WITHOUT EURO-OBD)]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
6.DETECT MALFUNCTIONING PART
Check the following.
Harness for open or short between cooling fan
