Page 3697 of 5883

NISSAN TIIDA 2007 Service Repair Manual INT-18 < ON-VEHICLE REPAIR > BACK DOOR TRIM BACK DOOR TRIM Removal and InstallationINFOID:0000000001329114 REMOVAL CAUTION:  Insert a suitable tool between panel on vehicle and clips (as indicated wi

Page 3698 of 5883

NISSAN TIIDA 2007 Service Repair Manual BODY SIDE TRIM INT-19 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P BODY SIDE TRIM ComponentINFOID:0000000001329051 Hatchback Models AWJIA0060ZZ 1. Front pillar garnish 2. Front body side wel

Page 3699 of 5883

NISSAN TIIDA 2007 Service Repair Manual INT-20 < ON-VEHICLE REPAIR > BODY SIDE TRIM Sedan Models Removal and InstallationINFOID:0000000001329052 WARNING: Do not reuse center pillar upper garnish if removed. CAUTION:  Insert a suitable tool

Page 3700 of 5883

NISSAN TIIDA 2007 Service Repair Manual BODY SIDE TRIM INT-21 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P FRONT PILLAR GARNISH Removal Release the clips, then remove front pillar garnish. Installation Installation is in the rever

Page 3701 of 5883

NISSAN TIIDA 2007 Service Repair Manual INT-22 < ON-VEHICLE REPAIR > BODY SIDE TRIM Installation is in the reverse order of removal. REAR KICKING PLATE INNER Removal Release the clips, then remove rear kicking plate inner. Installation Inst

Page 3702 of 5883

NISSAN TIIDA 2007 Service Repair Manual BODY SIDE TRIM INT-23 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P Do not reuse center pillar upper garnish if removed. 1. Remove center pillar lower garnish. Refer to "CENTER PILLAR LOWER G

Page 3703 of 5883

NISSAN TIIDA 2007 Service Repair Manual INT-24 < ON-VEHICLE REPAIR > LUGGAGE FLOOR TRIM LUGGAGE FLOOR TRIM Removal and InstallationINFOID:0000000001329113 REMOVAL CAUTION: 1. Luggage side lower finisher RH 2. Access cover 3. Shock absorber

Page 3704 of 5883

NISSAN TIIDA 2007 Service Repair Manual LUGGAGE FLOOR TRIM INT-25 < ON-VEHICLE REPAIR > C D E F G H I K L MA B INT N O P  Insert a trim stick or suitable tool between panel on vehicle and clips (as indicated with arrow) to release clips.
