EM-282
< ON-VEHICLE REPAIR >[K9K]
INJECTION TUBE AND FUEL INJECTOR
6. Remove fuel hose shield.
7. Disconnect fuel feed hose.
8. Remove high pressure pipes protection cover (upper).
9. Remove the neck located on the fuel rail.
NOTE:
Undo the nut on the pump side or the injector side, then the nut located on the rail side. Undo the
nuts for each pipe in turn. Move the nut along the pipe keeping the olive in contact with the taper.
10. Remove all the injection tubes.
11. Plug all the holes in the injection circuit.
12. Remove fuel rail.
13. Disconnect fuel return pipe.
14. Remove retaining clip and disconnect the diesel return pipe on
the injector.
15. Plug all the holes of the injection circuit.
16. Disconnect the injector harness connector (1).
17. Remove the injector bracket (2).
18. Remove the injector.
19. Pull off the flame shield washer.
20. Disconnect the fuel pressure sensor.
21. Remove the high pressure pipes protection cover (lower).
INSTALLATION
CAUTION:
All the injection tubes removed must be systematically replaced.
1. Clean the injector sockets and the injector bodies, as well as their brackets using a lint-free cloth (use the
wipes recommended for this purpose, dipped in clean solvent.
2. Dry off using a different new wipe.
3. Replace the flame shield washer with a new one.
4. Position the injector.
5. Tighten the mounting bracket bolts.
6. Install injection tubes with new one.
7. Finger tighten the nuts.
8. Before fitting the new injection tubes, lightly lubricate the nut threads with the oil from the sachet provided
in the new parts kit.
NOTE:
Fit the pump/rail pipe before the rail/injector tubes.
9. Fit the pump-rail injection tube as follows:
Remove the protective plugs from the high pressure pump outlet, the high pressure rail inlet and the
pipe.
E1BIA0049ZZ
MBIB9030E
: 30.0 N·m (3.1 kg-m, 22 ft-lb)
Page 2930 of 5883
INJECTION TUBE AND FUEL INJECTOR
EM-283
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
Insert the injection tube olive into the taper of the high pressure pump outlet,
Insert the injection tube olive into the taper of the high pressure rail inlet.
Finger tighten the nuts of the injection tube starting with the one located on the rail side.
10. Install the rail-injector injection tube.
11. Tighten the injection tube nut.
12. Connect fuel return pipe to injector and install retaining clip.
13. Installation is in the reverse order to removal for the remaining
parts.: 24.0 N·m (2.4 kg-m, 18 ft-lb)
E1BIA0055ZZ
Page 2931 of 5883
EM-284
< ON-VEHICLE REPAIR >[K9K]
OIL PAN
OIL PAN
Exploded ViewINFOID:0000000001381492
Removal and InstallationINFOID:0000000001381493
CAUTION:
To avoid the danger of being scalded, never drain the engine oil when the engine is hot.
REMOVAL
1. Remove engine undercover using power tool.
2. Remove oil level indicator.
3. Drain engine oil. Refer to LU-27, "
Draining".
CAUTION:
Perform when engine is cold.
4. Remove fender protector (RH).
5. Remove front driveshaft assembly (RH). Refer to FA X - 11 , "
Removal and Installation (Right Side)".
6. Remove driveshaft center bearing bracket.
7. Remove rear torque rod (lower). Refer to EM-302, "
Exploded View".
8. Remove bolts from the catalyst bracket. Refer to EM-274, "
Exploded View".
9. Disconnect and remove oil level sensor.
1. Gasket 2. Oil pan 3. O-ring
4. Drain plug 5. Oil level sensor 6. Clutch housing
7. Crankshaft position sensor
E1BIA0008GB
Page 2932 of 5883
OIL PAN
EM-285
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
10. Remove oil pan and transaxle joint bolts.
11. Support the engine bottom of the oil pan with a transmission jack
etc.
12. Remove oil pan bolts in reverse order as shown.
13. Insert seal cutter [SST: KV10111100 (—)] between upper oil pan
and cylinder block. Slide tool by tapping on the side of the tool
with a hammer.
CAUTION:
Exercise care not to damage mating surface.
14. Remove oil pan.
INSTALLATION
Installation is in the reverse order of removal.
MBIB1039E
MBIB0575E
MBIB1257E
SEM365EA
Page 2933 of 5883
EM-286
< ON-VEHICLE REPAIR >[K9K]
OIL PAN
1. Apply liquid gasket as shown.
Use Genuine Liquid Gasket or equivalent.
2. Using suitable tool, align the oil pan with the cylinder block.
3. Install oil pan bolts in numerical order as shown.
NOTE:
Wait at least 30 minutes after oil pan is installed before filling
engine with engine oil.
InspectionINFOID:0000000001381494
INSPECTION AFTER REMOVAL
Clean oil pump assembly if any objects attached.
INSPECTION AFTER INSTALLATION
Check the engine oil level. Refer to LU-26, "Inspection".
Start the engine and make sure there are no leaks of engine oil. Refer to LU-26, "
Inspection".
MBIB0593E
MBIB0594E
: 14.0 N·m (1.4 kg-m, 10 ft-lb)
MBIB1257E
Page 2934 of 5883
![NISSAN TIIDA 2007 Service Repair Manual HIGH PRESSURE SUPPLY PUMP
EM-287
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
HIGH PRESSURE SUPPLY PUMP
Exploded ViewINFOID:0000000001381495
Removal and InstallationINFOID:00000000013814 NISSAN TIIDA 2007 Service Repair Manual HIGH PRESSURE SUPPLY PUMP
EM-287
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
HIGH PRESSURE SUPPLY PUMP
Exploded ViewINFOID:0000000001381495
Removal and InstallationINFOID:00000000013814](/manual-img/5/57395/w960_57395-2933.png)
HIGH PRESSURE SUPPLY PUMP
EM-287
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
HIGH PRESSURE SUPPLY PUMP
Exploded ViewINFOID:0000000001381495
Removal and InstallationINFOID:0000000001381496
REMOVAL
CAUTION:
Be sure to read “Precautions for Diesel Equipment”. Refer to EM-253, "
Precaution for Diesel Equip-
ment".
Wait until the fuel temperature drops before carrying out any work.
Order the special high pressure injection circuit plug kit.
It is strictly forbidden to remove any high pressure supply
pump sprocket marked number 070 575 (see diagram). If the
pump is being replaced, the pulley must be replaced.
1. Disconnect the battery.
2. Remove air duct (inlet). Refer to EM-269, "
Exploded View".
3. Remove engine cover.
4. Remove blow-by hose.
5. Remove charge air cooler hose and pipes. Refer to EM-270,
"Exploded View".
6. Remove the RH front tire. Refer to WT-6, "
Rotation".
7. Remove fender protector (RH). Refer to EXT-22, "
Removal and
Installation".
8. Remove drive belt. Refer to EM-263, "
Removal and Installation".
9. Support the engine using suitable tool.
10. Remove the timing belt. Refer to EM-291, "
Removal and Installation".
11. Remove the oil level gauge guide and plug the hole. Refer to EM-281, "
Exploded View".
12. Remove high pressure pipes protection cover (upper). Refer to EM-281, "
Exploded View".
13. Carefully disconnect:
The connectors from the flow actuator,
The connectors from the fuel temperature sensor,
On the pump, the fuel supply and return pipes.
The return pipe connecting the injectors with the pump.
14. Remove the injection tube connecting the pump to the rail. Refer to EM-281, "
Removal and Installation".
1. High pressure supply pump protec-
tor2. Stud bolt 3. High pressure supply pump
4. Engine cover bracket
E1BIA0119GB
MBIB9036E
Page 2935 of 5883
![NISSAN TIIDA 2007 Service Repair Manual EM-288
< ON-VEHICLE REPAIR >[K9K]
HIGH PRESSURE SUPPLY PUMP
15. Plug all the holes of the injection circuit.
16. Remove the three mounting bolts from the high pressure supply pump then remove it.
INST NISSAN TIIDA 2007 Service Repair Manual EM-288
< ON-VEHICLE REPAIR >[K9K]
HIGH PRESSURE SUPPLY PUMP
15. Plug all the holes of the injection circuit.
16. Remove the three mounting bolts from the high pressure supply pump then remove it.
INST](/manual-img/5/57395/w960_57395-2934.png)
EM-288
< ON-VEHICLE REPAIR >[K9K]
HIGH PRESSURE SUPPLY PUMP
15. Plug all the holes of the injection circuit.
16. Remove the three mounting bolts from the high pressure supply pump then remove it.
INSTALLATION
1. Install the pump then position the mounting bolts without tightening them.
2. Before fitting the new injection tube, lightly lubricate the nut threads with the oil from the sachet provided
in the new parts kit.
3. Install the injection tubes according to the following:
remove the protective plugs.
insert the injection tube olive into the taper of the high pressure pump outlet.
insert the injection tube olive into the taper of the high pressure rail inlet.
4. Finger tighten the nuts of the injection tube starting with the one located on the rail side.
5. Tighten the bolts on the high pressure pump.
6. Tighten the injection tube nut.
7. Install the high pressure supply pump protector.
CAUTION:
When installing the high pressure supply pump protector, follow the steps below.
Be sure rubber spacer (1) is touching bolt head of high
pressure supply pump (4) as shown.
Tighten bolt (2) while holding protector towards the high
pressure supply pump.
Tighten nut (3).
Be sure rubber spacer (1) is touching bolt head of high
pressure supply pump (4).
8. Installation is in the reverse order to removal.
9. Test the sealing of the high pressure supply pump after it has been repaired (refer to EM-253, "
Precaution
for Diesel Equipment"). : 21.0 N·m (2.1 kg-m, 15 ft-lb)
: 24.0 N·m (2.4 kg-m, 18 ft-lb)
E1BIA0117ZZ
: 21.0 N·m (2.1 kg-m, 15 ft-lb)
: 21.0 N·m (2.1 kg-m, 15 ft-lb)
E1BIA0118ZZ
Page 2936 of 5883
ROCKER COVER
EM-289
< ON-VEHICLE REPAIR >[K9K]
C
D
E
F
G
H
I
J
K
L
MA
EM
N
P O
ROCKER COVER
Exploded ViewINFOID:0000000001381497
Removal and InstallationINFOID:0000000001381498
REMOVAL
1. Remove engine cover.
2. Remove air duct (inlet). Refer to EM-269, "
Exploded View".
3. Remove air duct (suction). Refer to EM-269, "
Exploded View".
4. Remove charge air cooler pipes and hoses. Refer to EM-270, "
Exploded View".
5. Disconnect and remove camshaft position sensor.
6. Remove fuel hose shield.
7. Disconnect electronic throttle control actuator. Refer to EM-272, "
Exploded View".
8. Remove blow-by hose.
9. Remove high pressure pipes protection cover (upper).
10. Unclip fuel injector spill hose from rocker cover.
11. Unclip timing belt upper cover.
12. Remove rocker cover.
NOTE:
Loosen bolts in the reverse order as shown.
INSTALLATION
1. Install new gasket to rocker cover.
1. Oil filler cap 2. Rocker cover 3. Gasket
4. Camshaft position sensor
E1BIA0006GB
E1BIA0048ZZ
