DLK-372
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
INTELLIGENT KEY WARNING BUZZER
INTELLIGENT KEY WARNING BUZZER
DescriptionINFOID:0000000001530361
Answers back and warns about an inappropriate operation. Hatchback vehicles are equipped with a warning
buzzer located inside the driver door. In addition to this buzzer, the sedan vehicles are equipped with a second
buzzer located in the trunk area.
Component Function CheckINFOID:0000000001530362
1.CHECK FUNCTION
With CONSULT-III
Check Intelligent Key warning buzzer “OUTSIDE BUZZER” operation in “Active Test” mode.
Does the warning buzzer(s) sound?
YES >> Intelligent Key warning buzzer(s) is OK.
NO >> Refer to DLK-372, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530363
1.CHECK INTELLIGENT KEY WARNING BUZZER(S) POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect Intelligent Key warning buzzer connector.
3. Check voltage between Intelligent Key warning buzzer connec-
tor and ground.
*: Sedan only
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace Intelligent Key warning buzzer power supply circuit.
2.CHECK HARNESS CONTINUITY
NOTE:
For sedan vehicles, ensure both Intelligent Key warning buzzers are disconnected before proceeding.
1. Disconnect Intelligent Key unit connector.
PIIB6622E
Te r m i n a l
Voltage (V)
(Approx.) (+)
(–)
Intelligent Key warning buzzer
connectorTe r m i n a l
D6 (driver door)
1 Ground Battery voltage
B82 (trunk)
*
Page 962 of 5883
![NISSAN TIIDA 2007 Service Repair Manual INTELLIGENT KEY WARNING BUZZER
DLK-373
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between Intelligent Key unit connector and
Intelligent Key NISSAN TIIDA 2007 Service Repair Manual INTELLIGENT KEY WARNING BUZZER
DLK-373
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between Intelligent Key unit connector and
Intelligent Key](/manual-img/5/57395/w960_57395-961.png)
INTELLIGENT KEY WARNING BUZZER
DLK-373
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
2. Check continuity between Intelligent Key unit connector and
Intelligent Key warning buzzer connector.
*: Sedan only
3. Check continuity between Intelligent Key warning buzzer connector and ground.
Is the inspection result normal?
YES >> GO TO 3.
NO >> Repair or replace harness between Intelligent Key warning buzzer and Intelligent Key unit.
3.CHECK INTELLIGENT KEY WARNING BUZZER
Check Intelligent Key warning buzzer.
Refer to DLK-373, "
Component Inspection".
Is the inspection result normal?
YES >> GO TO 4.
NO >> Replace Intelligent Key warning buzzer. Refer to XX-XX, "*****"
.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
Component InspectionINFOID:0000000001530364
1.CHECK INTELLIGENT KEY WARNING BUZZER
Connect battery power supply to Intelligent Key warning buzzer ter-
minals 1 and 2, and check the operation.
PIIB6623E
Intelligent Key unit
connectorTe r m i n a lIntelligent Key warning buzzer
connector Terminal Continuity
M52 4Driver door D6
2Yes
Trunk
*B82
Intelligent Key unit
connectorTe r m i n a l
GroundContinuity
M52 4 No
PIIB6624E
Page 963 of 5883
DLK-374
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
INTELLIGENT KEY WARNING BUZZER
*: Sedan only
Is the inspection result normal?
YES >> Intelligent Key warning buzzer is OK.
NO >> Replace Intelligent Key warning buzzer. Refer to XX-XX, "*****"
.
Intelligent Key warning buzzer
connectorTerminal Operation
(+) (-)
Buzzer sounds D6 (driver door)
12
B82 (trunk)
*
Page 964 of 5883
BUZZER (COMBINATION METER)
DLK-375
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
BUZZER (COMBINATION METER)
DescriptionINFOID:0000000001396846
Performs operation method guide and warning with buzzer.
Component Function CheckINFOID:0000000001396847
1.CHECK FUNCTION
With CONSULT-III
Check the operation with “INSIDE BUZZER” in “Active Test”.
Is the inspection result normal?
Yes >> Warning buzzer in combination meter is OK.
No >> Refer to DLK-375, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001396848
1.CHECK BUZZER (COMBINATION METER) CIRCUIT
Refer to XX-XX, "*****"
.
Is the inspection result normal?
Yes >> GO TO 2.
No >> Repair or replace buzzer (combination meter) circuit.
2.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
Test item Condition
INSIDE BUZZER:TAKE OUT Take away warning chime sounds
:KNOB Ignition knob switch warning chime sounds
:KEY Key warning chime sounds
Page 965 of 5883
DLK-376
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
KEY WARNING LAMP
KEY WARNING LAMP
DescriptionINFOID:0000000001530369
Performs operation method guide and warning together with buzzer.
Component Function CheckINFOID:0000000001530370
1.CHECK FUNCTION
With CONSULT-III
Check the operation with “INDICATOR” in “Active Test” mode.
Is the inspection result normal?
Yes >> Key warning lamp in combination meter is OK.
No >> Refer to DLK-376, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530371
1.CHECK KEY WARNING LAMP CIRCUIT
Refer to XX-XX, "*****"
.
Is the inspection result normal?
Ye s > > G O T O 2 .
No >> Repair or replace key warning lamp circuit.
2.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
Test item Condition
INDICATOR:BLUE ON Key warning lamp (green) illuminates
:RED ON Key warning lamp (red) illuminates
:BLUE IND Key warning lamp (green) flashes
:RED IND Key warning lamp (red) flashes
Page 966 of 5883
![NISSAN TIIDA 2007 Service Repair Manual LOCK WARNING LAMP
DLK-377
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
LOCK WARNING LAMP
DescriptionINFOID:0000000001530372
Performs operation method guide and war NISSAN TIIDA 2007 Service Repair Manual LOCK WARNING LAMP
DLK-377
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
LOCK WARNING LAMP
DescriptionINFOID:0000000001530372
Performs operation method guide and war](/manual-img/5/57395/w960_57395-965.png)
LOCK WARNING LAMP
DLK-377
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
LOCK WARNING LAMP
DescriptionINFOID:0000000001530372
Performs operation method guide and warning together with buzzer.
Component Function CheckINFOID:0000000001530373
1.CHECK FUNCTION
With CONSULT-III
Check the operation with “INDICATOR” in “Active Test” mode.
Is the inspection result normal?
Yes >> Lock warning lamp in combination meter is OK.
No >> Refer to DLK-377, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530374
1.CHECK COMBINATION METER OPERATION
Check the operation of the combination meter.
Does the combination meter operate normally?
Yes >> GO TO 2.
No >> Refer to MWI-3, "
Work Flow".
2.CHECK LOCK WARNING LAMP CIRCUIT
1. Engage the parking brake.
2. Turn ignition switch ON.
3. Depress the brake pedal and take the shift lever out of park.
4. With the shift lever out of park, attempt to turn ignition switch to the LOCK position.
Does the "LOCK" indicator illuminate?
Yes >> GO TO 3.
No >> Refer to MWI-3, "
Work Flow" in combination meter to diagnose the park/neutral position indicator
circuit.
3.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
Test item Condition
INDICATOR:KNOB ON Lock warning lamp illuminates
:KNOB IND Lock warning lamp flashes
Page 967 of 5883
DLK-378
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
HAZARD WARNING LAMPS
HAZARD WARNING LAMPS
DescriptionINFOID:0000000001530375
Performs answer-back for each operation with the number of blinks.
Component Function CheckINFOID:0000000001530376
1.CHECK FUNCTION
With CONSULT-III
Check hazard warning lamp “FLASHER” in “Active Test” mode.
Is the inspection result normal?
YES >> Hazard warning lamp circuit is OK.
NO >> Refer to DLK-378, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530377
1.CHECK HAZARD SWITCH CIRCUIT
Use the hazard warning switch circuit.
Do the hazard warning lamps operate normally?
YES >> GO TO 2.
NO >> Repair hazard warning lamps. Refer to BCS-9, "
System Diagram".
2.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
Page 968 of 5883
VEHICLE SPEED SIGNAL CIRCUIT
DLK-379
< COMPONENT DIAGNOSIS >[WITH I-KEY & SUPER LOCK]
C
D
E
F
G
H
I
J
L
MA
B
DLK
N
O
P
VEHICLE SPEED SIGNAL CIRCUIT
DescriptionINFOID:0000000001530378
Displays the vehicle speed signal received from combination meter as a numerical value (km/h).
Component Function CheckINFOID:0000000001530379
1.CHECK FUNCTION
Check that all doors are automatically locked at the vehicle speed of more than 12 km/h (7 MPH).
Is the inspection result normal?
YES >> Vehicle speed signal circuit is OK.
NO >> Refer to DLK-379, "
Diagnosis Procedure".
Diagnosis ProcedureINFOID:0000000001530380
1.CHECK VEHICLE SPEED SIGNAL CIRCUIT
Check vehicle speed signal “VEHICLE SPEED” in “Data Monitor” mode.
Is the inspection result normal?
YES >> GO TO 2.
NO >> Repair or replace vehicle speed signal circuit.
2.CHECK INTERMITTENT INCIDENT
Refer to @@@.
>> INSPECTION END
