Page 5817 of 5883

NISSAN TIIDA 2007 Service Repair Manual DIAGNOSIS SYSTEM (BCM)
WW-15
< FUNCTION DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
ACTIVE TEST
FR WIPER HI
[OFF/ON]
Each switch status that BCM judges from the combination switch reading function. FR

Page 5818 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-16
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (IPDM E/R)
DIAGNOSIS SYSTEM (IPDM E/R)
Diagnosis DescriptionINFOID:0000000001366606
AUTO ACTIVE TEST
Refer to PCS IPDM E/R AUTO ACTIVE TEST.
CONSULT - III

WW-16
< FUNCTION DIAGNOSIS >
DIAGNOSIS SYSTEM (IPDM E/R)
DIAGNOSIS SYSTEM (IPDM E/R)
Diagnosis DescriptionINFOID:0000000001366606
AUTO ACTIVE TEST
Refer to PCS IPDM E/R AUTO ACTIVE TEST.
CONSULT - III Function (IPDM E/R)INFOID:0000000001366607
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with IPDM E/R.
SELF DIAGNOSTIC
Refer to PCS-28, "DTCIndex".
DATA MONITOR
Monitor item
ACTIVE TEST
Te s t i t e m
Diagnosis mode Description
ECU Identification Allows confirmation of IPDM E/R part number.
Self Diagnostic Result Displays the diagnosis results judged by IPDM E/R.
Data Monitor Displays the real-time input/output data from IPDM E/R input/output data.
Active Test IPDM E/R can provide a drive signal to electronic components to check their operations.
CAN Diag Support Monitor The results of transmit/receive diagnosis of CAN communication can be read.
Monitor Item
[Unit]MAIN
SIGNALSDescription
HL WASHER REQ
[Off/On]Displays the status of the headlamp washer request signal received from BCM via CAN
communication.
FR WIP REQ
[Stop/1LOW/Low/Hi]×Displays the status of the front wiper request signal received from BCM via CAN com-
munication.
WIP AUTO STOP
[STOP P/ACT P]×Displays the status of the front wiper auto stop signal judged by IPDM E/R.
WIP PROT
[Off/BLOCK]×Displays the status of the front wiper fail-safe operation judged by IPDM E/R.
IGN RLY
[Off/On]×Displays the status of the ignition relay judged by IPDM E/R.
IGN ON SW
[Off/On]Displays the status of the ignition switch judged by IPDM E/R.
Test item Operation Description
FRONT WIPEROff OFF
Lo Operates the front wiper relay.
Hi Operates the front wiper relay and front wiper high relay.
HEAD LAMP WASHER On Operates the headlamp washer relay for 1 second.
EXTERNAL LAMPSOff OFF
TAIL Operates the tail lamp relay.
Lo Operates the headlamp low relay.
HiOperates the headlamp low relay and ON/OFF the headlamp high relay at 1 sec-
ond intervals.
Fog Operates the front fog lamp relay.

Page 5819 of 5883

NISSAN TIIDA 2007 Service Repair Manual WIPER AND WASHER FUSE, FUSIBLE LINK
WW-17
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
COMPONENT DIAGNOSIS
WIPER AND WASHER FUSE, FUSIBLE LINK
DescriptionINFOID:0000000001366608
Fuse, fusib

Page 5820 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-18
< COMPONENT DIAGNOSIS >
FRONT WIPER MOTOR LO CIRCUIT
FRONT WIPER MOTOR LO CIRCUIT
Component Function CheckINFOID:0000000001366610
1. CHECK FRONT WIPER LO OPERATION
IPDM E/R AUTO ACTIVE TEST
1. S

Page 5821 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT WIPER MOTOR LO CIRCUIT
WW-19
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
1. Turn the ignition switch ON.
2. Select "FRONT WIPER" of IPDM E/R active test item.
3. While operating the

Page 5822 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-20
< COMPONENT DIAGNOSIS >
FRONT WIPER MOTOR HI CIRCUIT
FRONT WIPER MOTOR HI CIRCUIT
Component Function CheckINFOID:0000000001366612
1. CHECK FRONT WIPER HI OPERATION
IPDM E/R AUTO ACTIVE TEST
1. S

Page 5823 of 5883

NISSAN TIIDA 2007 Service Repair Manual FRONT WIPER MOTOR HI CIRCUIT
WW-21
< COMPONENT DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
1. Turn the ignition switch ON.
2. Select "FRONT WIPER" of IPDM E/R active test item.
3. While operating the

Page 5824 of 5883

NISSAN TIIDA 2007 Service Repair Manual WW-22
< COMPONENT DIAGNOSIS >
FRONT WIPER AUTO STOP SIGNAL CIRCUIT
FRONT WIPER AUTO STOP SIGNAL CIRCUIT
Component Function CheckINFOID:0000000001366614
1. CHECK FRONT WIPER (AUTO STOP) SIGNAL CHECK
CO
