COOLING FAN CONTROL
1. Mass air flow sensor
(with intake air temperature sensor)2. Engine coolant temperature sensor 3. Electric throttle control actuator
(with built in throttle position sensor,
throttle control motor)
4. PCV valve 5. Cooling fan motor 6. Resistor
7. Refrigerant pressure sensor
BBIA0724E
Page 2090 of 5883
COOLING FAN CONTROL
EC-741
< FUNCTION DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Intake valve timing control solenoid
valve2. Knock sensor 3. IPDM E/R
4. Fuel pump fuse 5. Fuel level sensor unit and fuel pump
harness connector
(view with inspection hole cover re-
moved)6. Fuel level sensor unit and fuel pump
7. Fuel pressure regulator 8. Fuel level sensor 9. Fuel tank temperature sensor
10. Ignition coil 11. Fuel injector
BBIA0735E
Page 2091 of 5883
EC-742
< FUNCTION DIAGNOSIS >[MR18DE]
COOLING FAN CONTROL
1. Heated oxygen sensor 1 2. Three way catalyst (Manifold) 3. Heated oxygen sensor 2
4. Three way catalyst (Under floor) 5. Muffler 6. Heated oxygen sensor 1 harness
connector
7. Heated oxygen sensor 2 harness
connector
BBIA0733E
Page 2092 of 5883
COOLING FAN CONTROL
EC-743
< FUNCTION DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
1. Crankshaft position sensor (POS) 2. Comshaft position sensor (PHASE) 3. EVAP canistor purge volume control
solenoid valve
4. ECM 5. Stop lamp switch 6. Accelerator pedal position sensor
PBIA9902J
Page 2093 of 5883
EC-744
< FUNCTION DIAGNOSIS >[MR18DE]
COOLING FAN CONTROL
Component Description
INFOID:0000000001161743
1. ASCD steering switch 2. MAIN switch 3. CANCEL switch
4. SET/COAST switch 5. RESUME/ACCELEATE switch 6. Stop lamp switch
7. ASCD brake switch 8. ASCD clutch switch 9. Cluch pedal
ALBIA0273ZZ
Component Reference
Camshaft position sensor (PHASE)EC-866, "
Description"
Crankshaft position sensor (POS)EC-862, "Description"
Cooling fan motorEC-737, "System Diagram"
Engine coolant temperature sensorEC-807, "Description"
Refrigerant pressure sensorEC-988, "Description"
Page 2094 of 5883
EVAPORATIVE EMISSION SYSTEM
EC-745
< FUNCTION DIAGNOSIS >[MR18DE]
C
D
E
F
G
H
I
J
K
L
MA
EC
N
P O
EVAPORATIVE EMISSION SYSTEM
System DiagramINFOID:0000000001161744
EVAPORATIVE EMISSION LINE DRAWING
