WIPER AND WASHER SYSTEM SYMPTOMS
WW-55
< SYMPTOM DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
Front wiper does not
stop.HI only Combination switch
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
Front wiper request signal
BCM
IPDM E/RIPDM E/R DATA MONITOR
"FR WIP REQ"
IPDM E/R —
LO only Combination switch
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
Front wiper request signal
BCM
IPDM E/RIPDM E/R DATA MONITOR
"FR WIP REQ"
IPDM E/R —
INT only Combination switch
BCMCombination switch
Refer to XX-XX, "*****"
.
Front wiper request signal
BCM
IPDM E/RIPDM E/R DATA MONITOR
"FR WIP REQ"
Front wiper does not
operate normally.Intermittent adjustment
cannot be performed. Combination switch
Harness between combination switch and BCM
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
BCM —
Intermittent control
linked with vehicle
speed cannot be per-
formed.Check the vehicle speed detection wiper setting.
Refer to WW-14, "
WIPER : CONSULT-III Function (BCM - WIPER)".
Wiper is not linked to
the washer operation. Combination switch
Harness between combination switch and BCM
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
BCM —
Does not return to stop
position (Repeatedly
operates for 10 sec-
onds and then stops
for 20 seconds. After
that, it stops the opera-
tion). IPDM E/R
Harness between IPDM E/R and front wiper
motor
Front wiper motorFront wiper auto stop signal
circuit
Refer to WW-22, "
Compo-
nent Function Check".
Front wiper auto op-
eration does not op-
erate. (If equipped)Any Light and rain sensor
Harness between combination switch and BCM
BCMLight and rain sensor
Refer to EXL-55, "
Diagnosis
Procedure".
IPDM E/R
Harness between IPDM E/R and front wiper
motor
Front wiper motorIPDM E/R
Refer to xxx.
BCM — Symptom Probable malfunction location Inspection item
Page 5858 of 5883

WW-56
< SYMPTOM DIAGNOSIS >
WIPER AND WASHER SYSTEM SYMPTOMS
Rear wiper does not
operate.ON only Combination switch
Harness between combination switch and BCM
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
INT only Combination switch
Harness between combination switch and BCM
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
ON and INT Combination switch
Harness between combination switch and BCM
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
BCM
Harness between rear wiper motor and BCM
Harness between rear wiper motor and ground
Rear wiper motorCombination switch
Refer to WW-28, "
Compo-
nent Function Check".
Rear wiper does not
stop.ON only Combination switch
BCMRear wiper motor circuit
Refer to WW-30, "
Compo-
nent Function Check".
INT only Combination switch
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
Rear wiper does not
operate normally.Wiper is not linked to
the washer operation. Combination switch
Harness between rear wiper motor and BCM
BCMCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
BCM —
Rear wiper does not
return to the Stop posi-
tion (Stops after a five-
second operation).BCM
Harness between rear wiper motor and BCM
Rear wiper motorRear wiper auto stop signal
circuit
Refer to WW-30, "
Compo-
nent Function Check". Rear wiper stops after
operating for five sec-
onds when ignition
switch is turned ON.
Headlamp washer
does not operate.Headlamp washer
does not operate with
the front washer when
headlamps are turned
ON. Combination switch
Harness between combination switch and BCM
BCM
Headlamp washer pumpCombination switch
Refer to BCS-55, "
Symptom
Ta b l e".
Fusible link
Harness between fusible link and headlamp
washer relay
Headlamp washer relay
Harness between headlamp washer relay and
IPDM E/R
IPDM E/R
Harness between headlamp washer relay and
headlamp washer pump
Harness between headlamp washer pump and
ground
Headlamp washer pumpHeadlamp washer circuit
Refer to WW-33, "
Compo-
nent Function Check".
BCM — Symptom Probable malfunction location Inspection item
Page 5859 of 5883
NORMAL OPERATING CONDITION
WW-57
< SYMPTOM DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
NORMAL OPERATING CONDITION
DescriptionINFOID:0000000001366641
FRONT WIPER MOTOR PROTECTION FUNCTION
IPDM E/R may stop the front wiper to protect the front wiper motor if any obstruction (operation resistance)
such as a large amount of snow is detected during the front wiper operation.
At that time turn OFF the front wiper and remove the foreign object. Then wait for approximately 20 seconds
or more and reactivate the front wiper. The wiper will operate normally.
REAR WIPER MOTOR PROTECTION FUNCTION
BCM may stop rear wiper to protect the rear wiper motor when the rear wiper is stopped for 5 seconds or
more due to a snowfall.
Rear wiper operates normally one minute after the obstacles are removed with rear wiper OFF.
Page 5860 of 5883

WW-58
< SYMPTOM DIAGNOSIS >
FRONT WIPER DOES NOT OPERATE
FRONT WIPER DOES NOT OPERATE
DescriptionINFOID:0000000001366642
The front wiper does not operate under any operation conditions.
Diagnosis ProcedureINFOID:0000000001366643
1. CHECK WIPER RELAY OPERATION
IPDM E/R AUTO ACTIVE TEST
1. Start IPDM E/R auto active test. Refer to PCS-10, "
Diagnosis Description".
2. Check that the front wiper operates at the LO/HI operation.
CONSULT-III ACTIVE TEST
1. Select "FRONT WIPER" of IPDM E/R active test item.
2. While operating the test item, check front wiper operation.
Is front wiper operation normal?
YES >> GO TO 5
NO >> GO TO 2
2. CHECK FRONT WIPER MOTOR FUSE
1. Turn the ignition switch OFF.
2. Check that the following fuse is not blown.
Is the fuse blown?
YES >> Replace the fuse after repairing the applicable circuit.
NO >> GO TO 3
3. CHECK FRONT WIPER MOTOR GROUND OPEN CIRCUIT
1. Disconnect front wiper motor.
2. Check continuity between front wiper motor harness connector
and ground.
Does continuity exist?
YES >> GO TO 4
NO >> Repair or replace harness.
4. CHECK FRONT WIPER MOTOR OUTPUT VOLTAGE
CONSULT-III ACTIVE TESTLO : Front wiper LO operation
HI : Front wiper HI operation
OFF : Stop the front wiper.
Unit Location Fuse No. Capacity
Front wiper motor IPDM E/R 39 30 A
Front wiper motor
GroundContinuity
Connector Terminal
E1 2 Yes
WKIA5488E
Page 5861 of 5883

FRONT WIPER DOES NOT OPERATE
WW-59
< SYMPTOM DIAGNOSIS >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
1. Disconnect front wiper motor.
2. Turn the ignition switch ON.
3. Select "FRONT WIPER" of IPDM E/R active test item.
4. With operating the test item, check voltage between IPDM E/R
harness connector and ground.
Is the measurement value normal?
YES >> Replace front wiper motor. Refer to WW-73, "Removal and Installation".
NO >> Replace IPDM E/R. Refer to xxx.
5. CHECK FRONT WIPER REQUEST SIGNAL INPUT
CONSULT-III DATA MONITOR
1. Select "FR WIP REQ" of IPDM E/R data monitor item.
2. Switch the front wiper switch to HI and LO.
3. With operating the front wiper switch, check the status of "FR WIP REQ".
Is the status of item normal?
YES >> Replace IPDM E/R. Refer to xxx.
NO >> GO TO 6
6. CHECK COMBINATION SWITCH
1. Perform the inspection of the combination switch. Refer to BCS-55, "
Symptom Table".
Is combination switch normal?
YES >> Replace BCM. Refer to BCS-57, "Removal and Installation of BCM".
NO >> Repair or replace the applicable parts.
Te r m i n a l s
Te s t i t e m
Voltage
(Approx.) (+) (−)
IPDM E/R
GroundFRONT WIP-
ER
Connector Terminal
E4532LOBattery
voltage
OFF 0 V
33HIBattery
voltage
OFF 0 V
ALLIA0368ZZ
Monitor item ConditionMonitor
status
FR WIP REQFront wiper switch HION HI
OFF STOP
Front wiper switch LOON 1LOW
OFF STOP
Page 5862 of 5883
WW-60
< SYMPTOM DIAGNOSIS >
HEADLAMP WASHER DOES NOT OPERATE
HEADLAMP WASHER DOES NOT OPERATE
DescriptionINFOID:0000000001366644
Headlamp washer does not operate linked to front washer operation.
Diagnosis ProcedureINFOID:0000000001366645
1. CHECK IPDM E/R
CONSULT-III DATA MONITOR
1. Turn the lighting switch to the 2ND position.
2. Select "HL WASHER REQ" of IPDM E/R data monitor item.
3. Operate the headlamp washer.
4. Check the status of "HL WASHER REQ".
Is the status of item normal?
YES >> Refer to WW-33, "Component Function Check".
NO >> GO TO 2
2. CHECK COMBINATION SWITCH
1. Perform the inspection of the combination switch. Refer to BCS-55, "
Symptom Table".
Is combination switch normal?
YES >> Replace BCM. Refer to BCS-57, "Removal and Installation of BCM".
NO >> Repair or replace the applicable parts.
Monitor item Condition Monitor status
HL WASHER REQ Headlamp washer Operating ON
Stopped OFF
Page 5863 of 5883

PRECAUTIONS
WW-61
< PRECAUTION >
C
D
E
F
G
H
I
J
K
MA
B
WW
N
O
P
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"
INFOID:0000000001538893
The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. Information necessary to service the system safely is included in the SR and SB section of
this Service Manual.
WARNING:
• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in
the event of a collision which would result in air bag inflation, all maintenance must be performed by
an authorized NISSAN/INFINITI dealer.
Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal
injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag
Module, see the SR section.
Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-
ness connectors.
Precaution for Procedure without Cowl Top CoverINFOID:0000000001366647
When performing the procedure after removing cowl top cover, cover
the lower end of windshield with urethane, etc.
PIIB3706J
