NISSAN TIIDA 2007 Service Repair Manual SEC-88
< FUNCTION DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DATA MONITOR
ACTIVE TEST
THEFT ALM
THEFT ALM : CONSULT-III Function (BCM - THEFT ALM)INFOID:0000000001404167
APPLIC

SEC-88
< FUNCTION DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
DIAGNOSIS SYSTEM (BCM)
DATA MONITOR
ACTIVE TEST
THEFT ALM
THEFT ALM : CONSULT-III Function (BCM - THEFT ALM)INFOID:0000000001404167
APPLICATION ITEM
CONSULT-III performs the following functions via CAN communication with BCM.
DATA MONITOR
ACTIVE TEST
WORK SUPPORT
Diagnosis mode Function Description
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from Intelligent Key unit.
Monitor item Content
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
KEY ON SW Indicates [ON/OFF] condition of key switch.
Test item Description
THEFT IND This test is able to check security indicator operation [ON/OFF].
Diagnosis mode Function Description
WORK SUPPORT Changes the setting for each system function.
DATA MONITOR The BCM input/output signals are displayed.
ACTIVE TEST The signals used to activate each device are forcibly supplied from BCM.
Monitor Item Condition
IGN ON SW Indicates [ON/OFF] condition of ignition switch in ON position.
ACC ON SW Indicates [ON/OFF] condition of ignition switch in ACC position.
KEY ON SW Indicates [ON/OFF] condition of key switch.
KEYKESS LOCK Indicates [ON/OFF] condition of lock signal from key fob.
KEYLESS UNLOCK Indicates [ON/OFF] condition of unlock signal from key fob.
DOOR SW-DR Indicates [ON/OFF] condition of front door switch (driver side).
DOOR SW-AS Indicates [ON/OFF] condition of front door switch (passenger side).
DOOR SW-RR Indicates [ON/OFF] condition of rear door switch RH.
DOOR SW-RL Indicates [ON/OFF] condition of rear door switch LH.
BACK DOOR SW Indicates [ON/OFF] condition of back door switch.
CDL LOCK SW Indicates [ON/OFF] condition of door lock and unlock switch.
CDL UNLOCK SW Indicates [ON/OFF] condition of door lock and unlock switch.
Test item Description
THEFT IND This test is able to check security indicator operation [ON/OFF].
FLASHER This test is able to check flasher operation [LH/RH/OFF].

Page 4714 of 5883

NISSAN TIIDA 2007 Service Repair Manual DIAGNOSIS SYSTEM (BCM)
SEC-89
< FUNCTION DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
Test item Description
SECURITY ALARM SETVehicle security function mode can be chan

Page 4715 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-90
< COMPONENT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
U1000 CAN COMM CIRCUIT
COMPONENT DIAGNOSIS
U1000 CAN COMM CIRCUIT
DescriptionINFOID:0000000001404168
CAN (Controller Area Network) is a s

Page 4716 of 5883

NISSAN TIIDA 2007 Service Repair Manual U1010 CONTROL UNIT (CAN)
SEC-91
< COMPONENT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
U1010 CONTROL UNIT (CAN)
DTC LogicINFOID:0000000001404171
DTC DETECTION LOGIC
D

Page 4717 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-92
< COMPONENT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2190, P1614 NATS ANTENNA AMP.
B2190, P1614 NATS ANTENNA AMP.
DescriptionINFOID:0000000001532070
Performs ID verification through BCM and

Page 4718 of 5883

NISSAN TIIDA 2007 Service Repair Manual B2190, P1614 NATS ANTENNA AMP.
SEC-93
< COMPONENT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
Is the inspection result normal?
YES >> GO TO 4.
NO >> Repair or replace

Page 4719 of 5883

NISSAN TIIDA 2007 Service Repair Manual SEC-94
< COMPONENT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
B2191, P1615 DIFFERENCE OF KEY
B2191, P1615 DIFFERENCE OF KEY
DescriptionINFOID:0000000001404177
Performs ID verification through BCM whe

Page 4720 of 5883

NISSAN TIIDA 2007 Service Repair Manual B2192, P1611 ID DISCORD, IMMU-ECM
SEC-95
< COMPONENT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2192, P1611 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000001404180
B

B2192, P1611 ID DISCORD, IMMU-ECM
SEC-95
< COMPONENT DIAGNOSIS >[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
MA
B
SEC
N
O
P
B2192, P1611 ID DISCORD, IMMU-ECM
DescriptionINFOID:0000000001404180
BCM performs the ID verification with ECM that allows the engine to start. BCM starts the communication with
ECM if ignition switch is turned ON starts the engine if the ID is OK. ECM prevents the engine from starting if
the ID is not registered.
DTC LogicINFOID:0000000001404181
DTC DETECTION LOGIC
NOTE:
If DTC B2192 is displayed with DTC U1000, first perform the trouble diagnosis for DTC U1000. Refer to
SEC-90, "
DTC Logic".
If DTC B2192 is displayed with DTC U1010, first perform the trouble diagnosis for DTC U1010. Refer to
SEC-91, "
DTC Logic".
DTC CONFIRMATION PROCEDURE
1.PERFORM DTC CONFIRMATION PROCEDURE
1. Turn ignition switch ON.
2. Check “Self diagnostic result” with CONSULT-III.
Is DTC detected?
YES >> Refer to SEC-95, "Diagnosis Procedure".
NO >> INSPECTION END.
Diagnosis ProcedureINFOID:0000000001404182
1.PERFORM INITIALIZATION
Perform initialization with CONSULT-III. Re-register all ignition keys.
For initialization and registration of ignition key. Refer to CONSULT-III Operation Manual.
Can the system be initialized and can the engine be started with re-registered ignition key?
YES >> ID was unregistered.
NO >> GO TO 2.
2.PEPLACE BCM
1. Replace BCM. Refer to XX-XX, "*****"
.
2. Perform initialization with CONSULT-III. Re-register all ignition keys.
For initialization and registration of ignition key. Refer to “CONSULT-III Operation Manual.
Can the system be initialized and can the engine be started with re-registered ignition key?
YES >> BCM is malfunctioning.
NO >> GO TO 3.
3.PEPLACE ECM
1. Replace ECM.
2. Perform initialization with CONSULT-III. Re-register all ignition keys.
For initialization and registration of ignition key. Refer to “CONSULT-III Operation Manual.
Can the system be initialized and can the engine be started with re-registered ignition key?
YES >> ECM is malfunctioning.
NO >> GO TO 4.
4.CHECK INTERMITTENT INCIDENT
Refer to @@@.
DTC No.Trouble diagnosis
nameDTC detecting condition Possible cause
B2192
ID DISCORD BCM-
ECMThe ID verification results between BCM and ECM
are NG. The registration is necessary.BCM
ECM
P1611
